baby&child HAVEN Assembly Instructions

WARNING: ADULT ASSEMBLY ONLY OWING TO THE PRESENCE OF SMALL
PARTS, SHARP POINTS AND EDGES
Customer Service - If you are missing parts or have any questions about this product,
please contact us at : 1-800-762-1751
PART LIST
A [1] HEADBOARD
B [1] FOOTBOARD/ STORAGE BASE
C [3] TOP PLATFORM PANELS
TOOLS NEEDED
- Phillips head screwdriver (not included)
HARDWARE LIST
1
2
3
4
5
ASSEMBLY INSTRUCTIONS :
Note: Bed can be assembled by one person rather easily, but if two people are available
it is easier and the operation will require less preparation. The instructions are
written assuming one person is assembling the bed.
1. Carefully pull out the drawers from the Storage Base (B) using force, but being careful not to
damage the drawers.
2. Headboard and footboard are interchangeable, allowing you to position the bed against the
wall with drawers facing out and the headboard on either end of the bed. If you wish to attach
the Headboard (A) to the right end of the bed, first remove the footboard & re-attach to the
left end of the Storage Base (B).
3. Attach the Headboard (A) to the Storage Base (B) by using Flat Washer (1), Lock Washer (2),
and Bolts (3). Use Allen Key (4) to tighten.
4. Lay the Top Platform Panels (
Wood Screws (5) with Philips head screwdriver (not included).
5. Carefully, re-insert drawers into the Storage Base (B). Assembly is now complete.
5/16" x 2" Bolt
4mm Allen Key
C ) on top of the Storage Base (B) and attach using Qty.18
4pcs
4pcs
4pcs
1pc
18pcs
