Summary of Contents for baby&child Cabin Twin Loft Bed 355-81
- Page 1 baby&child TION ESTO ARDWARE All Restoration Hardware bunk beds are designed to meet the highest safety standards and comply with all U.S. and Canadian Bunk Bed regulations. Page 1 of 10...
-
Page 2: Customer Service
Assembly Instructions Cabin Twin & Full Loft Bed baby&child TION ESTO ARDWARE Restoration Hardware Baby & Child 11640 Harrel St, Suite B Mira Loma CA 91752 rhbabyandchild.com Made in Vietnam Model No: Distributed in the U.S.A by: #355-81 Cabin Twin Loft Bed Restoration Hardware 11640 Harrel St, Suite B Mira Loma #355-82 Cabin Full Loft Bed... - Page 3 C A B I N T W I N & F U L L L O F T B E D IMPORTANT SAFETY INFORMATION FOR BUNK BED: 1. Follow the information on the WARNINGS appearing on the upper bunk end structure and on the carton.
- Page 4 C A B I N T W I N & F U L L L O F T B E D Parts Identification Please note, Headboard and Footboard are interchangeable and can be installed on either end of bunk. (A) Bed Front (x1 piece) (B) Bed Back (x1 piece) (C) Ladder (x1 piece) (D) Bottom Side Rails (x2 pieces)
-
Page 5: Tools Needed
C A B I N T W I N & F U L L L O F T B E D TOOLS NEEDED: HARDWARE INCLUDED: Phillips Head Screwdriver ITEM DESCRIPTION QTY. (Not included) 5/16”x2-1/2” Long Bolt 2 pcs. 8 pcs. 5/16”x1-1/2”... - Page 6 C A B I N T W I N & F U L L L O F T B E D STEP 2: Install the Top Side Rails (E) securely into the metal brackets on the Posts of Bed Front (A) & Bed Back (B), (refer to Detail "BB").
- Page 7 C A B I N T W I N & F U L L L O F T B E D STEP 4: Lay the 4 Short Stretcher Bars (I) in between the Bed Front (A) and Bed Back (B), then tighten using Long Screws (5) and Phillips head screwdriver (refer to Detail "DD").
- Page 8 C A B I N T W I N & F U L L L O F T B E D STEP 6: Attach the Long Stretcher Bar (H) onto the top of Top Side Rails (E) by using Long Bolt (1), Spring Washer (3), Flat Washer (4) and Allen Key (6) to tighten.
- Page 9 C A B I N T W I N & F U L L L O F T B E D STEP 8: Attach Roof (G) to the Top Side Rail (E) by using Short Bolt (2), Spring Washer (3), Flat Washer (4) and Allen Key (6) to tighten.
- Page 10 C A B I N T W I N & F U L L L O F T B E D STEP 10: INSTALL BEDDING BEDDING SPECIFICATIONS FOR TOP BUNK: The following size mattress and Foundation are specified for use with this Bunk bed. MATTRESS DIMENSION SPECIFICATIONS FOR TOP BUNK: Twin - over - twin Bunk: (74"...
