baby&child ASHER Manual

Canopy bed

W A R N I N G : ADULT ASSEMBLY ONLY OWING TO THE PRESENCE OF SMALL PARTS, SHARP

POINTS AND EDGES

Customer Service- If you are missing parts or have any questions about this product, please contact us

at : 1-800-762-1751

P A R T L I S T

A [1] HEADBOARD PANEL

B [2] SHORT CANOPY POSTS

C [2] LONG CANOPY POSTS

D [1] FOOTBOARD PANEL

E [2] SIDE RAILS

F [1] SLAT ROLL

G [4] CANOPY RAILS

H [4] CONNECTION BLOCK

K [4] CANOPY FINIALS

H A R D W A R E L I S T

A S S E M B L Y I N S T R U C T I O N

Note: Two adults are recommended to assemble this bed.

1. Place the headboard panel (A) upright in the position you wish the bed to be in when fully

assembled. The headboard bedfast hardware should be facing the inside, toward the mattress. Place

the hooks in the Headboard panel (A) into the slots in the Short canopy posts (B).

A S H E R C A N O P Y B E D

Curved slotted washer

- Page 1 of 3 -

Table of Contents

Need help?

Do you have a question about the ASHER and is the answer not in the manual?

Page 1 A S H E R C A N O P Y B E D W A R N I N G : ADULT ASSEMBLY ONLY OWING TO THE PRESENCE OF SMALL PARTS, SHARP POINTS AND EDGES Customer Service- If you are missing parts or have any questions about this product, please contact us at : 1-800-762-1751 P A R T L I S T A [1] HEADBOARD PANEL...
Page 2 2. Let the Footboard panel (D) lay flat on smooth surface like packing foam. Secure the threaded rod (3) to the Long canopy posts (C) and place the rod into the Footboard panel (D) at the bore holes’ position, insert Curved slotted washer(4), hex nuts (1) and tighten hex nuts using wrench (7). Repeat the procedure with other side.
Page 3 5. Insert connecting bolts (5) to the Connection block (H). Then secure the Canopy rails (G) to the Connection block (H). Place cam lock wheel (6) into the holes inside of the canopy rails by aligning the arrow sign of the cam lock wheel to the connecting bolt and twist to tighten by counter clockwise direction using Phillip head screwdriver (not provided).
