- Page 1 GASBOY Model 124 Quart Stroke Pump Operation / Parts Manual MDE-4419 (formerly 031590)
- Page 2 Company Programs and Documentation All Gasboy computer programs (including software on diskettes and within memory chips) and documentation are copyrighted by, and shall remain the property of, Gasboy. Such computer programs and documents may also contain trade secret information. The duplication, disclosure, modification, or unauthorized use of computer programs or documentation is strictly prohibited, unless otherwise licensed by Gasboy.
-
Page 3: Important Warnings And Safeguards
Check with Gasboy Technical Services for compatibility of liquids with pump materials. TURN OFF AND LOCK OUT ALL POWER TO PUMP BEFORE PERFORMING SERVICE, MAINTENANCE OR IN THE EVENT OF A FUEL SPILL. - Page 4 It features a swing return drain and a heavy-duty stainless steel twist rod to ensure positive drain return. Model 124 dimensions are 17" high with 15" clearance between the nozzle and the drum. 1/2" PVC suction pipe is provided. Model 124 is sealable by Weights and Measures.
-
Page 5: Basic Operation
Turn crank 1-1/2 turns clockwise to dispense product. Repeat Steps 1 through 4 if filling several containers. When container is removed, swing drain rotates back into position. MDE-4419 Model 124 Quart Stroke Pump Operation / Parts Manual • March 2005 Page 3... - Page 6 GASBOY QUART STROKE PUMP MODEL 124 MDE-4419 Model 124 Quart Stroke Pump Operation / Parts Manual • March 2005 Page 4...
- Page 7 Hex Nut 068891 Lock Washer 033010 Knob Assembly (consists of items 26-29) 064897 Telescoping Suction Assy. 045730 Piston & Rack Assy. (consists of items 3 -9) MDE-4419 Model 124 Quart Stroke Pump Operation / Parts Manual • March 2005 Page 5...
-
Page 8: General Exclusions
• Gasboy will supply new or rebuilt parts to replace parts which are found to be defective within the warranty period. Parts returned to Gasboy must be shipped with transportation charges paid and will be replaced with parts with transportation charges prepaid by Gasboy.
