Introduction
Purpose
This document provides installation instructions for Gasboy
C07057 Single/Dual Pulse out or C07092 RS485 Communications.
Table of Contents
Topic
Introduction
Important Safety Information
Installation of the Gasboy 9820 Pump Interface Kit
Pulse-out I/F Board (M06587A001) Jumper Settings
Required Tools
The following tools are required for the installation of the kit:
• Flat-tip Screwdriver
• Cross-tip Screwdriver
• Standard Socket set
Parts List
The following table lists the parts included in the Pump Interface Kits,
Sr. No. Description
1
2
3
4
5
6
7
8
MDE-4864B Gasboy® 9820 Pump Interface Kits Installation Instructions · March 2022
PCA, Atlas 9800 Pulse Out Interface W/Totalizer
PCA, Atlas 9800 RS-485 Interface
Standoff, M/F #6-32 X 3/4" Lg
Washer, Lock #6 Ext. Tooth
Screw, Sems Ph Phil 6-32 X 3/8 Stl Zn Pl
Cable Assy, Opt.Comm TB-9820RR
Screw, Mh Pnh Phl 8-32 X .625 Stl Zn Pl
Washer, Lk #8 Reg Sst
Gasboy
9820 Pump Interface Kits
®
Installation Instructions
9820 Pump Interface Kits,
®
Page
1
3
5
8
Quantity
Part Number
C07057
M06587A001
1
M06725A001
-
C08381
2
G068843
2
Q12083-13
2
C06678
1
Q11270-55
2
K73278-33
2
MDE-4864B
March 2022
C07057 and C07092:
C07092
-
1
2
2
2
1
2
2
Page 1
Advertisement
Table of Contents
Related Manuals for Gasboy 9820
Summary of Contents for Gasboy 9820
- Page 1 Screw, Sems Ph Phil 6-32 X 3/8 Stl Zn Pl Q12083-13 Cable Assy, Opt.Comm TB-9820RR C06678 Screw, Mh Pnh Phl 8-32 X .625 Stl Zn Pl Q11270-55 Washer, Lk #8 Reg Sst K73278-33 MDE-4864B Gasboy® 9820 Pump Interface Kits Installation Instructions · March 2022 Page 1...
-
Page 2: Related Documents
Printed Circuit Board Submersible Turbine Pump Technical Assistance Center Warranty For information on warranty, refer to MDE-4255 Gasboy’s Warranty Policy Statement. If you have any warranty-related questions, contact Gasboy’s Warranty Department at its Greensboro location. Page 2 MDE-4864B Gasboy® 9820 Pump Interface Kits Installation Instructions · March 2022... -
Page 3: Important Safety Information
1-800-444-5529. It is imperative to your safety and the safety of DEF is non-flammable. Therefore, explosion and fire safety others to understand the procedures before beginning work. warnings do not apply to DEF lines. MDE-4864B Gasboy® 9820 Pump Interface Kits Installation Instructions · March 2022 Page 3... - Page 4 Subpart S of 29 CFR Part for these requirements. 1910 - Electrical Hazards, 29 CFR Part 1910.333 contains specific Lockout/Tagout provision for electrical hazards. Page 4 MDE-4864B Gasboy® 9820 Pump Interface Kits Installation Instructions · March 2022...
- Page 5 9120K & 9820K Series AST Pumps Installation and Operation Manual, and your Fuel Management System Installation Manual before proceeding. To install the Gasboy 9820 Pump Interface Kit, proceed as follows: Turn off the circuit breakers that supply power to the MICRO and PUMP feeds.
- Page 6 Note down the wiring or tag all the wires that are connected to the terminal blocks. Remove all the wires from the terminal blocks. If the model 9820 Pump contains a battery-backed power supply, pull the connector off P1 on the power supply. After a few seconds, reconnect P1.
- Page 7 Connect the new field wiring to the new terminal block. For more information refer to MDE-4567 9120K & 9820K Series AST Pumps Installation and Operation Manual. Turn on the MICRO and FEED circuit breakers. MDE-4864B Gasboy® 9820 Pump Interface Kits Installation Instructions · March 2022 Page 7...
- Page 8 Check JP1 - JP3 jumpers and change them, if necessary. The jumper settings must be changed only when power to the pump/dispenser is removed, to protect the circuit that they are connected to. In the model 9820 Pump, the P3 Connector is not connected. Jumper Settings Single-channel, Dual/Single-hose ...
-
Page 9: Remote Register
Pulse-out I/F Board (M06587A001) Jumper Settings Jumpers JP4 and JP5 When this board is used in a model 9820 Pump/Dispenser, jumpers JP4 and JP5 are set to the Q/A position. Figure 5 illustrates the proper output for using a Pump I/F Board (M06587A001), jumpered to provide two isolated pulse outputs from a single pulser. - Page 10 © 2022 GASBOY 7300 West Friendly Avenue · Post Office Box 22087 Greensboro, North Carolina 27420 Phone 1-800-444-5529 · http://www.gasboy.com · Printed in the U.S.A. MDE-4864B Gasboy® 9820 Pump Interface Kits Installation Instructions · March 2022...
