- Page 1 Atlas 9120K and 9820K Series AST Pumps ® Recommended Spare Parts List PT-1959B...
- Page 2 Computer Programs and Documentation All Gasboy computer programs (including software on diskettes and within memory chips) and documentation are copyrighted by, and shall remain the property of, Gasboy. Such computer programs and documents may also contain trade secret information. The duplication, disclosure, modification, or unauthorized use of computer programs or documentation is strictly prohibited, unless otherwise licensed by Gasboy.
-
Page 3: Table Of Contents
Table of Contents Table of Contents 1 – Introduction Purpose ............... . 1-1 How to Use This Manual . - Page 4 Table of Contents This page is intentionally left blank. ® Page ii PT-1959B Atlas 9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021...
-
Page 5: Introduction
Part Number The part number column indicates the current Gasboy part number for each item. Where Used The where used column helps to identify specific units or areas where a part is used and avoid ordering of parts already in stock. -
Page 6: Remanufactured Board Express
Metrology Printed Circuit Assembly Printed Circuit Board Terminal Block Warranty For information on warranty, refer to MDE-4255 Gasboy Warranty Policy Statement. If you have any warranty-related questions, contact Gasboy’s Warranty Department at its Greensboro location. ® Page 1-2 PT-1959B Atlas... -
Page 7: Commercial Parts
Base and Motor Shaft Commercial Parts 2 – Commercial Parts Base and Motor Shaft Distributor Part Description Part Number Where Used Critical Motor 3/4HP 220/380V (3 Phase, 50/60 M01068B303 High Hz) 220V Relay Belt Adjustable (45” Length) M07022B003 High Electric Motor (1 Phase, 50 Hz) R14213-33 All 50 Hz Applications High... -
Page 8: Reset/Register Module
Reset/Register Module Commercial Parts Reset/Register Module Distributor Part Description Part Number Where Used Critical Drive Register Assembly 9120 Gallon G022834 Mechanical Medium Drive Register Assembly 9120 Liter G022835 Mechanical Medium 9120K Reset Assembly Elec Unli 115/60 Hz M09919A101 Mechanical High 9120K Reset Assembly Elec Unli 230/50 Hz M09919A201 Mechanical... -
Page 9: 9823 Totalizer
9823 Totalizer Commercial Parts 9823 Totalizer Distributor Part Description Part Number Where Used Critical Kit-Totalizer 9820 Liter Factory G025936 9823K Liter Kit-Totalizer 9820 Gallon Factory G025934 9823K Gallon Where Used key: All = all unit models Mechanical = all models with a mechanical computer or non-computer Electronic = all units with an electronic readout I/F Option Only = optional Pulser Interface Board Pumps = all units with pumping units... -
Page 10: Remote Register Chassis Assembly
Remote Register Chassis Assembly Commercial Parts Remote Register Chassis Assembly Distributor Part Description Part Number Where Used Critical Weld Assembly, Chassis C35584 Electronic Cable Assembly, DC Power C06679 Electronic Medium Printed Circuit Board M15579K001 Electronic High (PCB) Assembly, Power Supply without Battery, 115 V C35538 Electronic Medium... - Page 11 Index Index Numerics M04920K102 2-1 M04920K104 2-1 9123K 2-3 M04920K105 2-1 9123K and 9823K Windows 2-3 M04920K107 2-1 9823 Totalizer 2-3 M04920K109 2-1 M04920K110 2-1 M04920K116 2-1 Base and Motor Shaft 2-1 M04920K117 2-1 M04920K118 2-1 M06333K9800AQ 2-4 M06587A001 2-4 C01383 2-4 M06725A001 2-4 C06372 2-4...
- Page 12 © 2021 GASBOY 7300 West Friendly Avenue · Post Office Box 22087 Greensboro, North Carolina 27420 Phone 1-800-444-5529 · http://www.gasboy.com · Printed in the U.S.A. ® PT-1959B Atlas 9120K and 9820K Series AST Pumps Recommended Spare Parts List · March 2021...
