- Page 1 EN 50131-1 EN 50131-4 DS100 Self-powered sounder/flasher for outdoor instal- lation Installation and programming manual...
-
Page 2: Table Of Contents
Table of contents 1. Description of DS100 1.1 Description of parts 1.2 Terminal board 1.3 Technical specifications of DS100 2. Sounder/flasher functions 2.1 Types of signalling 2.2 Sounder/flasher activations 3. Installation of DS100 3.1 Connection to control panel 3.2 Connecting the battery 4. Programming of DS100 4.1 Programming from DS100 4.2 Programming menu 5. General information 5.1 About this manual 5.2 Manufacturer's details 5.3 Warranty 5.4 Limited warranty 5.5 Documents for the users 5.6 Disposal of the product Installation and programming manual- 110... -
Page 3: Description Of Ds100
System status LED signals 13.8 Vdc operating voltage Houses 12V, 2.1 Ah backup battery Thermal probe for regulating the charging process Spirit level for installation Open-enclosure tamper protection Tamper-protection device Anti-foam protection Protection against blow-torch tamper and freezing Degree of protection IP34 4 programmable tones 4 programmable timers (3, 6, 9, 12 minutes) Courtesy lights Package contents DS100 sounder/flasher Drilling pattern Installation guide DS100 | © 2023 Inim Electronics S.r.l. -
Page 4: Description Of Parts
1. Description of DS100 1.1 Description of parts Installation and programming manual- 110... -
Page 5: Terminal Board
TAMPER Voltage-free terminals of the relay 1.3 Technical specifications of DS100 Warning device type For outdoor use, self-powered, type Z Power supply voltage nominal 13.8 V range from 9 to 16 V 12V - 2.1Ah Backup battery UL94-HB flame class Current absorption during standby 50 mA for battery recharge 50÷180 mA maximum 220 mA DS100 | © 2023 Inim Electronics S.r.l. - Page 6 1. Description of DS100 Acoustic output type tones Sound pressure at 1m 105 dB(A) Carrier frequency 2÷3 KHz Flash rate per minute Maximum alarm-time 12 min Operating environmental conditions Temperature from -25 to +60 °C Relative humidity f93 % without condensation Degree of protection IP34 Security grade Environmental class Dimensions (W x H x D) 218 x 237 x 53 mm...
-
Page 7: Sounder/Flasher Functions
The two ancillary LEDs, reveal the device status and guide you through the programming operations (Description of parts, [E] and Description of parts, [F]). The Red status LED signals: in the programming phase, with the light on solid, the LED signals the programming status in pro- gress with the casing open during the programming phase, with an intermittent light, the LED signals exit from the programming menu and the period of insensitivity from external stimuli at the end of which the device resumes nor- mal operation during normal operation, the LED is activated by a signal generated by the <START= terminal, if so programmed The green status LED, during normal operation: " is activated via the <LED= terminal, if so programmed. " it is activated on signal generated by the <START= terminal, if so programmed. Programming LED The LEDs (Description of parts, [G]) indicate the current programming phase and the eventual saving of selected settings. DS100 | © 2023 Inim Electronics S.r.l. -
Page 8: Sounder/Flasher Activations
2. Sounder/flasher functions Audible signalling The two speakers emit an audible signal which is programmable for the sound type (selectable from 4 tones). FAULT output Open-collector output normally closed or in stand-by status. TAMPER Output These are the contacts of a free-exchange relay that can be used for signalling the sounder/flasher events to external devices, normally closed during stand-by. 2.2 Sounder/flasher activations The DS100 sounder can be activated by signals from the control panel, depending on the wiring method used as well as by events generated by the device itself. Signalling will cease when one of the following conditions occurs: the alarm condition clears the maximum alarm time expires (in this case, only the audible signalling will cease); Control-panel event activations The occurrence of control-panel events (activations or resets) can activate a sounder/flasher and generate signalling. Each event can be associated with one or more sounder/flashers, configured as <Outputs= during the event programming phase. Sounder/flasher events The DS100 sounder processes signals detected by its components in such a way as to generate events to which one or more signals can be associated. The Ivy unit can generate the following events: Power failure Low battery ... -
Page 9: Installation Of Ds100
2. Remove all electrical power. 3. Remove the cover. 4. Pull the connection wires through the cable entry (Description of parts, [P]). 5. Using the appropriate holes and screws provided, attach the base to the wall. 6. If enablement of the anti-dislodgement device is required (Description of parts, [R]), insert the screw in the appropriate hole. 7. Locate the battery in its housing (Description of parts, [T]), then connect it by means of the battery wires. Ensure that the battery polarity is correct. 8. Complete the device wiring. During this phase, the red STATUS LED remains On. DS100 | © 2023 Inim Electronics S.r.l. -
Page 10: Connection To Control Panel
3. Installation of DS100 9. Check that the programming default settings are appropriate to needs, if not, make any necessary changes (Programming). 10. Close the casing and secure the appropriate screw (Description of parts, [O]). The tamper microswitch closes and the red LED blinks at intervals of 2 seconds for a total of 15 seconds. 11. The red LED will stop flashing and the sounder/flasher will be ready to operate. 3.1 Connection to control panel Below are all the possible connection types between an DS100 sounder and an anti-intrusion control panel. All connections involve the terminals on the motherboard (Description of parts, [A]). 2 wire connection +12V This standard wiring method activates the alarm signal by means of a positive-power-removed signal. 3 wire connection +12V In this connection mode, it is possible to activate both the external sounder and any internal sounder at the same time through the voltage- free <COM- NC- NO= relay of the control panel. Switching the relay dis- connects the <+= terminal of the external sounder and at the same time connects the <+= of the internal ... -
Page 11: Connecting The Battery
Take care to respect the battery polarity during the installation phase (red=positive; black=negative). The material used for the backup-battery casing must have a HB flammability class rating or superior. The battery powers the sounder/flasher in the event of tamper or failure of the mains power supply to the sys- tem connection line. This must always be present, since, in the event of an alarm, it provides the power required to generate the expected sound and to power the flasher. In the case of low battery status with a voltage lower than 10.5 V the sounder/flasher interrupts the pro- duction of the audible signals while maintaining the visual signals. Battery recharging is optimized by adjusting the necessary voltage based on the temperature detected by the thermal probe with which the sounder/flasher is equipped. DS100 | © 2023 Inim Electronics S.r.l. -
Page 12: Programming Of Ds100
4. Programming of DS100 4. Programming of DS100 DS100 sounders can be programmed by means of their buttons and LEDs, through their own programming menu. 4.1 Programming from DS100 To change its programming, the DS100 sounder provides a programming menu indicated by blinking on its LEDs; it is possible to navigate the menu by means of the programming buttons. This programming is possible only after a first powerup; therefore you must first make sure that: all power sources to the Ivy unit (mains and battery) are disconnected; the tamper protection is open; the anti-intrusion control panel is operating in a mode that acknowledges sounder tamper without trig- gering an alarm (e.g. control panel in programming mode) 1. Remove the cover. 2. Power-up the sounder; the red LED lights up solid. 3. By holding down the <P1= button (Description of parts, [B]) the programming LEDs (Description of parts, [G]) blink until the button is released to indicate access to the programming phase. They remain on, in binary sequence, to indicate the current programming section. - Page 13 Activation of the Red status LED Green status LED Flasher Sounder START input Power failure FAULT output TAMPER output Flasher Sounder Tamper signalling FAULT output TAMPER output Flasher Sounder Green status Green status LED LED Input Courtesy lights and courtesy lights Restore default LED Off LED On solid Flashing LED grey Option at default DS100 | © 2023 Inim Electronics S.r.l.
-
Page 14: General Information
5. General information 5. General information 5.1 About this manual Manual code: DCMIINE0DS100 Revision: 110 Copyright: The information contained in this document is the sole property of Inim Electronics S.r.l.. Copy- ing, reprinting or modification of this document, in part or as a whole, is not permitted without prior autho- rization in writing from Inim Electronics S.r.l.. All rights reserved. 5.2 Manufacturer's details Manufacturer: Inim Electronics S.r.l. Production plant: Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP), Italy Tel.: +39 0735 705007 Fax: +39 0735 734912 E-mail info@inim.it Web: www.inim.it The persons authorized by the manufacturer to repair or replace the parts of this system have authorization to work only on devices marketed under the brand Inim Electronics. 5.3 Warranty Inim Electronics S.r.l.. (Seller, Our, Us) warrants the original purchaser that this product shall be free from defects in materials and workmanship under normal use for a period of 24 months. As Inim Electronics does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;Inim Electronics does not warrant against loss of quality, degradation of performance of this product or actual damage that results from the use of products, parts or other repla- ceable items (such as consumables) that are neither made nor recommended by Inim Electronics. Seller obligation and liability under this warranty is expressly limited to repairing or replacing, at Seller's option, any product not meeting the specifications. In no event shall Inim Electronics be liable to the purchaser or any other person for any loss or damage whether direct of indirect or consequential or incidental, including ... -
Page 15: Limited Warranty
5.6 Disposal of the product Informative notice regarding the disposal of electrical and electronic equipment (applicable in countries with differentiated waste collection systems) The crossed-out bin symbol on the equipment or on its packaging indicates that the product must be disposed of correctly at the end of its working life and should never be disposed of together with gene- ral household waste. The user, therefore, must take the equipment that has reached the end of its working life to the appropriate civic amenities site designated to the differentiated collection of electrical and elec- tronic waste. As an alternative to the autonomous-management of electrical and electronic waste, you can hand over the equipment you wish to dispose of to a dealer when purchasing new equipment of the same type. You are also entitled to convey for disposal small electronic-waste products with dimensions of less than 25cm to the premises of electronic retail outlets with sales areas of at least 400m2, free of charge and without any obligation to buy. Appropriate differentiated waste collection for the subsequent recycling of the discarded equipment, its treatment and its environmentally compatible disposal helps to avoid possible negative effects on the environment and on health and favours the re-use and/or recycling of the materials it is made of. DS100 | © 2023 Inim Electronics S.r.l. - Page 16 Inim Electronics S.r.l. Via dei Lavoratori 10, Loc. Centobuchi 63076 Monteprandone (AP) I TALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.it _ www.inim.it DCMIINE0DS100-110-20230905...
