  • Page 1 Z5047 MAX12 Horizontal bracket Mounting instructions...
  • Page 2: General Information

    Z5043 MAX Horizontal bracket References in the manual This refers to a potentially dan- WARNING! gerous situation which may lead to personal injury. This refers to a potentially danger- CAUTION! ous situation which may lead to equipment damage. This refers to a situation which may IMPORTANT! cause equipment...
  • Page 3: General Safety Advice

    General Safety and Installation Advice General safety advice d&b loudspeakers should only ever be flown or installed using WARNING! recommended d&b rigging accessories. The d&b rigging accessories described in the d&b rigging accessories manual and the specific mounting instructions are designed and manufactured to have a high load safety factor for their intended role.
  • Page 4: Safety Inspections

    Any wall, floor or ceiling to which a d&b loudspeaker is fixed or WARNING! attached using a d&b rigging accessory must be capable of safely and securely supporting the actual load. The rigging accessory used must be safely and securely fixed both to the loudspeaker and to the wall, floor or ceiling.
  • Page 5 Load safety factors Rigging accessories are safety critical components which can, by their failure, lead to injury or death. To maximise safety and to reduce the risk of the possible consequences of failure, there exist various recommendations which attempt to govern the safe design and construction of rigging components.
  • Page 6 A 12X load safety factor is therefore recommended for the following components: Chains − Steel wire ropes (for lifting and securing) − Shackles − Eyebolts etc. − In contrast, the EU Machinery Directive (EN292-2) specifies the following load safety factors for rigging components: Rigging component Safety factors Steel wire ropes...
  • Page 7: Load Ratings

    The d&b rigging accessories described in the d&b rigging accessories manual and specific mounting instructions are directly attached to d&b loudspeaker cabinets and are secured using either screws or bolts fastened to threaded inserts fitted in the loudspeaker cabinets. .or attaching rigging, d&b loudspeaker cabinets are fitted threaded inserts.
  • Page 8 Z5047 MAX12 Horizontal bracket Z5047 MAX12 Horizontal bracket Load safety information The maximum permitted safe working load (SWL) for WARNING! the MAX12 Horizontal bracket is 22 kg/48.5 lb (a single MAX12 cabinet) and this value must on no account ever be exceeded.
  • Page 9: Operation

    Operation Position Angle 22,5° 45° 67,5° 90° 112,5° 125° Z5047 MAX12 Horizontal bracket dimensions in mm " Z5047 MAX12 Horizontal bracket angle settings d&b audiotechnik AG, Eugen-Adolff-Str. 134, D-71522 Backnang, Germany, Phone +49-7191-9669-0, .ax +49-7191-95 00 00...
