Familiarising yourself with your appliance
4 Familiarising yourself with your appliance
4.1 Control elements
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
Note: On certain models, specific details such as col-
our and shape may differ from those pictured.
2
1 Buttons and display
The buttons are touch-sensitive surfaces. To se-
lect a function, simply press lightly on the relev-
ant field.
The display shows symbols for active functions
and the time-setting options.
→ "Buttons and display", Page 7
4.3 Types of heating and functions
To ensure that you always find the right type of heating to cook your food, we explain the differences and applica-
tions below.
Symbol Type of heating
3D hot air
3
1
What it's used for and how it works
Bake or roast on one or more levels.
The fan distributes the heat from the ring heating element in the back wall
evenly around the cooking compartment.
Familiarising yourself with your appliance en
Function selector
2
Use the function selector to set the types of
heating and other functions.
You can turn the function selector clockwise or
anti-clockwise from the zero setting .
Depending on the appliance, the function se-
lector can be pushed in. Press on the function
selector to click it into or out of the zero set-
ting .
→ "Types of heating and functions", Page 7
3 Temperature selector
Use the temperature selector to set the temper-
ature for the type of heating and select settings
for other functions.
You can turn the temperature selector clock-
wise or anti-clockwise from the zero setting .
Depending on the appliance, the temperature
selector can be pushed in. Press on the tem-
perature selector to click it into or out of the
zero setting .
→ "Temperature and setting levels", Page 8
4.2 Buttons and display
You can use the buttons to set various functions for
your appliance. The display shows the settings.
If a function is active, the corresponding symbol lights
up on the display. The clock symbol
when you change the time.
Symbol Function
Select the time , timer , cooking
time and end time
To select the individual time-setting op-
tions, press the
→ "Time-setting options", Page 12
Decrease the setting values.
Increase the setting values.
Select a weight for the programmes.
→ "Programmes", Page 14
To activate or deactivate the childproof
lock, press and hold for ap-
prox. 3 seconds.
→ "Childproof lock", Page 16
only lights up
⁠ .
button several times.
