  • Page 1 User’s manual FLIR GF77a...
  • Page 2 Important note Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers. Důležitá poznámka Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte se jimi.
  • Page 3: Table Of Contents

    Table of contents Disclaimers ..................1 Legal disclaimer ............... 1 U.S. Government Regulations............1 Patents ................... 1 Quality assurance ..............1 Third-party licenses..............1 Usage statistics ................ 1 Copyright ................1 Safety information ................2 Notice to customer ................4 Calibration................4 Accuracy ................4 Disposal of electronic waste ............
  • Page 4 Ethernet connector and cable ............ 25 11.2 Power/Digital I/O connector and cable ......... 26 11.3 RS232/RS485 connector............27 Software supporting FLIR GF77a series cameras ........ 28 Mechanical drawings ............... 29 EU Declaration of conformity ............32 Indicator LEDs and factory reset button ..........34 15.1 Power/error indicator LED and factory reset button ......
  • Page 5: Disclaimers

    1.7 Copyright © 2021 FLIR Systems, Inc. All rights reserved worldwide. No parts of the software in- cluding source code may be reproduced, transmitted, transcribed or translated into any language or computer language in any form or by any means, electronic, magnetic, opti- cal, manual or otherwise, without the prior written permission of FLIR Systems.
  • Page 6: Safety Information

    WARNING Applicability: Digital devices subject to 15.21. NOTICE: Changes or modifications made to this equipment not expressly approved by FLIR Systems may void the FCC authorization to operate this equipment. WARNING Applicability: Digital devices subject to 2.1091/2.1093/KDB 447498/RSS-102.
  • Page 7 Safety information CAUTION The surface of the camera becomes hot. Use protective equipment when handling the camera in ambi- ent temperatures higher than +40°C (+122°F). CAUTION Do not apply solvents or equivalent liquids to the camera, the cables, or other items. For cleaning, refer to 16 Cleaning the camera.
  • Page 8: Notice To Customer

    To access the latest manuals, translations of manuals, and notifications, go to the Down- load tab at: http://support.flir.com In the download area you will also find the latest releases of manuals for our other prod- ucts, as well as manuals for our historical and obsolete products.
  • Page 9: Important Note About This Manual

    Notice to customer 3.6 Important note about this manual FLIR Systems issues generic manuals that cover several cameras within a model line. This means that this manual may contain descriptions and explanations that do not apply to your particular camera model.
  • Page 10: Customer Help

    • The communication protocol, or method, between the camera and your device (e.g., SD card reader, HDMI, Ethernet, USB, or FireWire). • Device type (PC/Mac/iPhone/iPad/Android device, etc.). • Version of any programs from FLIR Systems. • Full name, publication number, and revision number of the manual. 4.3 Downloads...
  • Page 11: Introduction

    Introduction 5.1 Optical gas imaging of methane The FLIR GF77a is an infrared camera for optical gas imaging (OGI) that allows oil and gas operators and other industrial markets a solution for continuous and autonomous leak detection. The FLIR GF77a is used in industrial settings such as natural gas proc- essing plants, biogas and power generation plants and helps to protect the environment by tracing leaks of methane.
  • Page 12: Camera Parts

    Camera parts Figure 6.1 View from the rear Figure 6.2 View from the front 1. Power/error indicator LED (blue/red). For details, see section 15 Indicator LEDs and factory reset button, page 34. 2. Ethernet communication indicator LED (green). 3. Ethernet/PoE connector, X-coded. 4.
  • Page 13: Camera Installation

    Connect the PoE cable to the camera, and then to a PoE switch on the same net- work as the computer. 3. The camera is set to use DHCP. On the computer, use FLIR IP Config to identify the camera on the network and change IP settings, if necessary.
  • Page 14: Mechanical Installation

    For further information regarding mounting recommendations, contact FLIR Systems. #T810484; r. AB/75034/75034; en-US...
  • Page 15: Rtsp Streams

    RTSP Streams It is possible to establish streaming sessions with the FLIR GF77a camera. The following URLs can be used: • rtsp://<IP>/avc/ • rtsp://<IP>/mpeg4/ • rtsp://<IP>/mjpg/ • rtsp://<IP>/avc/ch1 • rtsp://<IP>/mpeg4/ch1 • rtsp://<IP>/mjpg/ch1 The section after IP address refers to the encoding: •...
  • Page 16: Camera Web Interface

    Type the IP address of your camera into the address bar of a web browser. This displays the login view. 2. When logging in for the first time, log in with the username admin and the default ad- ministrator password provided by FLIR (available on the camera calibration certificate). Note •...
  • Page 17: Camera Tab

    Camera web interface 1. Tabs Available tabs depend on user type; • An admin sees the Camera, Administration, Settings, and Library tabs. • A user sees the Camera, Settings, and Library tabs. • A viewer sees the Camera tab. 2. Live image This is where the live image is presented of what the camera is currently targeting.
  • Page 18 Camera web interface 4. In the Action section, select which actions the camera will perform when an alarm is triggered: Digital OUT Outputs a digital pulse. Also, type a pulse length (in millisec- onds) in the Pulse time box. E-mail Automatically sends the captured Image, Result, or Video to the recipients defined in Settings >...
  • Page 19: Changing Object Parameters

    Camera web interface 5. In the Action section, select which actions the camera will perform when an alarm is triggered: Digital OUT Outputs a digital pulse. Also, type a pulse length (in millisec- onds) in the Pulse time box. E-mail Automatically sends the captured Image, Result, or Video to the recipients defined in Settings >...
  • Page 20: Working With Image Modes

    2. Change the parameter to the desired value, and then press Enter or click anywhere on the screen. 3. To reset the global parameters to the default values provided by FLIR, click Reset. 10.4.3 Working with image modes The camera captures both thermal and visual images at the same time. By your choice of image mode, you select which type of image to display on the screen.
  • Page 21: Colorizing The Image

    Camera web interface 2. Select one of the available image modes. 10.4.4 Colorizing the image 10.4.4.1 Palette You can change the palette that the software uses to display the different temperatures within an image. A different palette can make it easier to analyze the image. The most suitable palette for a certain application depends on many different factors, such as the target temperature and emissivity, the ambient temperature, and the distance to the tar- get.
  • Page 22: Using The Camera Lamp

    Camera web interface 2. Click one of the options: Option Calibration is automatically carried out: Auto when needed. Every 10 min approximately every 10 minutes. Every 30 min approximately every 30 minutes. Every 60 min approximately every 60 minutes. Every [type your value] at any set interval.
  • Page 23: Flipping The Image

    Camera web interface 10.4.10 Flipping the image The image can be flipped horizontally or vertically. Normal Horizontal flip Vertical flip Horizontal + vertical flip To change the flip setting, follow this procedure: 1. On the toolbar and in the View modes section, click to flip the image horizontally or click to flip the image vertically.
  • Page 24: Camera Presets

    Camera web interface 2. To show any hidden overlay graphics, click Show overlay. 10.4.15 Camera presets It is possible to save the current camera setup. The zipped file with the presets is saved to disk in your Downloads folder. It can later on be uploaded and applied. 10.4.15.1 Saving a preset To save the current camera setup, follow this procedure: 1.
  • Page 25: User Management

    Note When altering the network settings, the address of the camera might change. Make sure your settings are correct before saving them or the camera might not be reachable afterwards. If this occurs, you can use FLIR IP Config to locate the camera again or reset the camera to its default settings.
  • Page 26: System And Firmware

    Camera web interface To connect the camera to an existing network, follow this procedure: 1. In the navigation pane, click Network settings. 2. Click Client mode. 3. Click Scan networks. 4. Select one of the Available networks in the list, and then click Connect. 5.
  • Page 27: Alarm Recipients

    Camera web interface 10.6.1.1 Camera ID Type the preferred camera ID in the Device label box. Select the Display in status bar check box to show the camera ID on the active tab of the web browser and in the upper part of saved images.
  • Page 28: Library Tab

    Camera web interface To schedule actions, follow this procedure: 1. In the navigation pane, click Scheduler. 2. Click the check boxes to select which Scheduled actions to use. 3. In the schedule, click the Active check box for the days that the action will run: •...
  • Page 29: Pin Configurations

    Pin configurations 11.1 Ethernet connector and cable Configuration Figure 11.1 Female X-coded M12 Ethernet connector Figure 11.2 Ethernet cable M12 to RJ45 #T810484; r. AB/75034/75034; en-US...
  • Page 30: Power/Digital I/O Connector And Cable

    Pin configurations 11.2 Power/Digital I/O connector and cable Configuration EXTPWR_RTN EXTPWR_IN FAULT_A FAULT_B DIGOUT1A DIGOUT1B DIGOUT2A DIGOUT2B DIGIN1 DIGIN2 Not Connected DIGIN_RTN Figure 11.3 Male A-coded M12 Power/Digital I/O connector Section A—A Wire colour Black Green Purple Yellow Pink Orange Figure 11.4 Cable M12 to pigtail Brown White...
  • Page 31: Rs232/Rs485 Connector

    Pin configurations 11.3 RS232/RS485 connector Configuration RS232_TXD alt RS485A RS232_RXD alt RS485B Chassie GND Not Connected Figure 11.5 Male A-coded M8 RS232/RS485 connector #T810484; r. AB/75034/75034; en-US...
  • Page 32: Software Supporting Flir Gf77A Series Cameras

    Software supporting FLIR GF77a series cameras The following table explains which software supports FLIR GF77a series cameras: Software Support Comment FLIR IP Config • Detecting FLIR GF77a series cam- eras on the network. Note Use FLIR IP Config ver- •...
  • Page 33: Mechanical Drawings

    Mechanical drawings [See next page.] #T810484; r. AB/75034/75034; en-US...
  • Page 36: Eu Declaration Of Conformity

    EU Declaration of conformity [See next page] #T810484; r. AB/75034/75034; en-US...
  • Page 37 SE-187 15 Täby, Sweden This declaration of conformity is issued under the sole responsibility of the manufacturer. The object of the declaration: FLIR A4XX-, A5XX, A7XX-series and GF7Xa (Product Model Name FLIR- A8590). The object of the declaration described above is in conformity with the relevant Union harmonisation...
  • Page 38: Indicator Leds And Factory Reset Button

    Indicator LEDs and factory reset button For location of the indicator LEDs and the factory reset button, see Figure 6.1 View from the rear, page 8. 15.1 Power/error indicator LED and factory reset button Note Do not hold down the factory reset button when connecting the camera to power. Factory reset button Indicator LED status Explanation...
  • Page 39: Cleaning The Camera

    Cleaning the camera 16.1 Camera housing, cables, and other items Use one of these liquids: • Warm water • A weak detergent solution Equipment: • A soft cloth Follow this procedure: 1. Soak the cloth in the liquid. 2. Twist the cloth to remove excess liquid. 3.
  • Page 40: About Calibration

    17.3 Camera calibration at FLIR Systems Without calibration, an infrared camera would not be able to measure either radiance or temperature. At FLIR Systems, the calibration of uncooled microbolometer cameras with a measurement capability is carried out during both production and service. Cooled cam- eras with photon detectors are often calibrated by the user with special software.
  • Page 41: The Differences Between A Calibration Performed By A User And That Performed Directly At Flir Systems

    The calibration information, no matter if the calibration is done by FLIR Systems or the user, is stored in calibration curves, which are expressed by mathematical functions. As...
  • Page 42: Non-Uniformity Correction

    About calibration Calibration is also a prerequisite for adjustment, which is the set of operations carried out on a measuring system such that the system provides prescribed indications corre- sponding to given values of quantities to be measured, typically obtained from measure- ment standards.
  • Page 43: About Flir Systems

    • Extech Instruments (2007) Figure 18.1 Patent documents from the early 1960s FLIR Systems has three manufacturing plants in the United States (Portland, OR, Boston, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a manufacturing plant in Tallinn, Estonia.
  • Page 44: More Than Just An Infrared Camera

    18.1 More than just an infrared camera At FLIR Systems we recognize that our job is to go beyond just producing the best infra- red camera systems. We are committed to enabling all users of our infrared camera sys- tems to work more productively by providing them with the most powerful camera–...
  • Page 45: Supporting Our Customers

    18.3 Supporting our customers FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equipment and expertise to solve it within the shortest possible time.
  • Page 46 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T810484...
