GMR™ 18/24 xHD and 18 HD+
Field Service Manual
The GMR 18/24 xHD and 18 HD+ radar generates and transmits non-ionizing
radiation. The radar must be turned off before approaching the scanner for
service. Avoid looking directly at the scanner while it is transmitting, as the
eyes are the most sensitive part of the body to electromagnetic radiation.
Failure to properly turn off the radar may expose the service technician to
harmful electromagnetic radiation that can result in personal injury or death.
The GMR 18/24 xHD and 18 HD+ radar contains high voltages. The scanner
must be turned off before the covers are removed. While servicing the unit, be
aware high voltages are present and take the necessary precautions. The high
voltages in the scanner can take some time to decay. Failure to adhere to this
warning can result in personal injury or death.
The GMR 18/24 xHD and 18 HD+ radar contains a magnetron. Persons
with a cardiac pacemaker should not perform any service to the radar that
may place them in close proximity to the magnetron. If a person with a
cardiac pacemaker fails to adhere to the warning, there is a danger that the
pacemaker may experience abnormal operation or failure.
Repairing and performing maintenance on Garmin electronics is complex
work that can result in serious personal injury or product damage if not done
correctly.
Use care when working near a magnetron with ferrous instruments. The
strong magnetic force of the magnetron will attract ferrous instruments, and
any contact with the magnetron could damage the magnetron. If possible, use
stainless steel or titanium instruments when working near the magnetron. If
specialty instruments are not available, use cardboard or a similar material to
act as a shield between the magnetron and a ferrous instrument.
Garmin is not responsible for, and does not warrant, the work that you or a
non-authorized repair provider perform on your product.
Important Information Regarding Field Service of the
GMR 18/24 xHD and 18 HD+ Radar
• Before performing any service to the radar, ensure that the system
software is up to date. If it is not, go to
latest software version and update the radar using an SD card. Proceed
with the service only if the software update does not resolve the issue.
• Record the serial number of your radar. You will need the serial number
when you order replacement parts.
Contacting Garmin Product Support
Replacement parts are available only through Garmin Product Support.
• For dealer specific support, call 1-866-418-9438
• Go to
www.garmin.com/support
support information.
• In the USA, call (913) 397.8200 or (800) 800.1020.
• In the UK, call 0808 2380000.
• In Europe, call +44 (0) 870.8501241.
WARNING
NOTICE
www.garmin.com
to download the
and click Contact Support for in-country

Table of Contents

Getting Started ������������������������������������������������������������������������������������
.....................................................................................................2
.....................................................................................2
....................................................................................2
Troubleshooting ���������������������������������������������������������������������������������
...............................................................................................3
...............................................................................3
...................................................................................3
..................................................................................3
............................................................................3
...............................................................................7
Major Component Locations �������������������������������������������������������������
Radar Disassembly ����������������������������������������������������������������������������
..........................................................................................9
.......................................................................................9
......................................................................................9
....................................................................................9
................................................................................10
........................................................................................10
.............................................................................................11
Connector Locations ������������������������������������������������������������������������
................................................................................................13
................................................................................................13
.........................................................................13
Service Parts �������������������������������������������������������������������������������������
..........................................................................................14
............................................................................................15
.......................................................................................................16
.............................................................................................................16
.......................................................................3
.............................................................3
......................................................................3
..................................................................3
...............................................4
.......................4
2
3
.................4
....................5
8
9
13
14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMR 18 xHD and is the answer not in the manual?

Questions and answers

Summary of Contents for Garmin GMR 18 xHD

  • Page 1: Table Of Contents

    Reinstalling the Antenna ..................9 Replacing the Magnetron ................10 Garmin is not responsible for, and does not warrant, the work that you or a Replacing the Motor ..................10 non-authorized repair provider perform on your product. Replacing a PCB .....................11...
  • Page 2: Getting Started

    Simulator for at least four Radar Software Update seconds. Before using this manual to troubleshoot a problem, ensure that all Garmin A menu item for Radar appears at the bottom of the list. devices on the boat, including the chartplotter and the GMR 18/24 xHD/18...
  • Page 3: Troubleshooting

    If the problem persists, replace the processor PCB (page 11). Examine the Garmin Marine Network cable and connections on the radar and the chartplotter or GMS™ 10 1006 - Heater Voltage Low • If the cable is damaged or a connection is corroded, replace the cable 1007 - Heater Voltage High or clean the connection.
  • Page 4: 1017 - Modulator Status Fault, Modulator Is Not Responding 1026 - Modulator Power Fault, Could Not Power Up The Modulator

    1017 - Modulator Status Fault, Modulator is Not Responding 1026 - Modulator Power Fault, Could Not Power Up the Modulator Perform the universal troubleshooting steps (page Remove the dome (page Open the processor and modulator boxes (page 11). Remove the cable between P8000 on the processor PCB and J200 on the Modulator PCB (page 13).
  • Page 5: 1019 - Spin Up Time Out, Speed Did Not Reach Specified Rpms 1025 - Transmit Speed Lost, Could Not Maintain Rotation Speed

    1019 - Spin Up Time Out, Speed Did Not Reach Specified RPMs 1025 - Transmit Speed Lost, Could Not Maintain Rotation Speed Perform the universal troubleshooting steps (page If the problem persists, use this flow chart for further troubleshooting: Remove the dome (page Move to a safe distance, turn on the radar, and begin transmitting.
  • Page 6 Examine the antenna rotary joint, Continued from page checking the screws that fasten Yes, the antenna rotates. the roatary joint to the base. Are the Tighten or reinstall the screws loose or screws.. missing? 1. Open the processor PCB box (page 11).
  • Page 7: Failure With No Error Code

    Failure With No Error Code Symptom Possible Cause Determination Radar does not appear on the chartplotter 1. Network connection Inspect network cable from the radar for damage at both network list ends. If possible, check the cable for continuity. If damaged, repair or replace as needed.
  • Page 8: Major Component Locations

    Major Component Locations                   Item Description Antenna rotary joint   Antenna   Antenna drive gear   Motor   Processor PCB housing ...
  • Page 9: Radar Disassembly

      The GMR 18 xHD/18 HD+ radar has eight screws, and the GMR 24 xHD Tighten the 6 mm hex screws on the bottom of the radar. radar has ten screws. The screws stop turning when fully tightened. You cannot overtighten the ...
  • Page 10: Replacing The Magnetron

      Installing a New Magnetron A replacement magnetron is paired with a modulator PCB at Garmin before it   is shipped. When you install a new magnetron, you must also install the paired modulator PCB. Failure to install both components may result is poor radar ...
  • Page 11: Replacing A Pcb

    Reinstall the modulator PCB cover, and fasten it to the modulator PCB A replacement modulator PCB is paired with a magnetron at Garmin before it is shipped. When you install a new modulator PCB, you must also install the housing using the six #2 Phillips screws you removed in step 4 paired magnetron.
  • Page 12 Remove the processor PCB cover and disconnect the cables connected to the processor PCB. Remove the seven #1 Phillips screws that attach the processor PCB     to the processor PCB housing , and remove the processor PCB. ...
  • Page 13: Connector Locations

    Connector Locations Modulator PCB P101 P100 J200 P204 Processor PCB P2001 J6002 Antenna Position Sensor PCB P100 GMR 18/24 xHD and 18 HD+ Radar Field Service Manual...
  • Page 14: Service Parts

                  Item Description Kit Number Number GMR 18 HD+ GMR 18 xHD GMR 24 xHD Top cover (dome) S00-00800-02 S00-00470-00 S00-00486-00   Bottom S00-00800-01 S00-00471-00 S00-00487-00 ...
  • Page 15: Pcb-Related Parts

              Item Description Kit Number Number GMR 18 HD+ GMR 18 xHD GMR 24 xHD Processor PCB housing (two parts) S00-00483-00 S00-00483-00 S00-00483-00   Modulator PCB housing (two parts) S00-00482-00...
  • Page 16: Magnetron

    Magnetron       Item Description Kit Number - All Models Number Magnetron (and paired modulator PCB) S00-00477-00   Hex drive screw (M4) Not Included in the modulator PCB/   magnetron kit. Take care to save these screws. Hex drive screw (M4) Not Included in the modulator PCB/ ...
  • Page 17 GMR 18/24 xHD and 18 HD+ Radar Field Service Manual...
  • Page 18 © 2015-2024 Garmin Ltd. or its subsidiaries All rights reserved. Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of Garmin. Garmin reserves the right to change or improve its products and to make changes in the content of this manual without obligation to notify any person or organization of such changes or improvements.
