Options - D-Link DKVM-IP1 Manual

Click Ok, the new device icon will be changed as below,
1. Drive Redirection is only possible with Windows 2000 and the latter version.
2. The Drive Redirection works on a low SCSI level and the SCSI protocol cannot recognize
partitions; therefore the whole drive selected will be shared instead of any particular
partition.
3. While connecting to a legacy KVM switch, please select PS/2 mouse for
Keyboard/Mouse setting from webpage. Otherwise you will be not be able to use
Hot-key.

6.2.4 Options

Set this option to disable the mass storage emulation (and hide the virtual drive) if no image
file is currently loaded. If unset, and no file image will be found it may happen that the host
Figure 5-21. Drive Redirection finished
Warning
Figure 6-5. Seleting Options
Figure 6-5. USB mass storage option
40
