4. Device Installation
4.1. Installing the unit
The Mini AB has to be oriented to the bow taking as reference the
mark that appears on the side (as shown in the image on the right).
It can be used with a tripod and even with a phone adapter.
5. App Installation
1. Make sure your device is BLE compatible.
· Ultrasonic Portable works with Android 4.3 and beyond or iOS devices (4s, iPad2 or beyond).
2. Download and install Anemotracker App on your device from Google Play or Apple Store.
download here!
3. Once the App is installed start it and open the settings menu by sliding the screen to the right.
4. Press the" Scan" button and all Ultrasonic Portable Mini AB devices within the range should show
up at screen.
5. Select your device and connect.
If your device connects with the Ultrasonic Portable Mini AB correctly, continue with the normal
installation.
Further information:
Your device is compatible but you can not connect?
1. Make sure BT (Bluetooth) mode is running on your smartphone, Tablet or PC.
2. Make sure Ultrasonic Portable Mini AB is not in Off mode. It is in Off mode when the unit does not
have sufficient battery level. There will be no battery level shown when trying to connect to the device
in Anemotracker App.
3. Make sure no other device is linked to your Ultrasonic Portable Mini AB.
Each unit can only be connected to one device at a time. As soon as it gets disconnected, Ultrasonic
Portable Mini AB is ready to link to any other device with the Anemotracker app installed.
For further information please contact Calypso Technical Support.
6
Ultrasonic Portable Mini AB
User manual
