- Page 1 V-Cover INSTALLATION +44(0)1622 792006 sales@transcover.com www.transcover.com...
-
Page 2: Table Of Contents
INSTALLATION INSTRUCTIONS CONTENTS Introduction Safety Symbols Checklist Housing Spring Mount & Assembly Primary arm Rear Rest Crossbar Primary arm - Drill Arm Pivot Secondary Arm Tarp Install - Crossbar Buffer Install Tarp Install - Housing Electric Install Tower Option Tower - Electrics Tower Leg - Pneumatics Tower - Control Box ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) -
Page 3: Introduction
INSTALLATION INSTRUCTIONS INTRODUCTION Thank you for purchasing a Transcover ground level covering system. It has been designed and manufactured by Transcover to provide years of trouble-free operation. Please read and understand this Installation Manual before installing your V-Cover. Correct installation is a requirement for correct operation. Please pay particular attention to the stability of the installation and to the safety indication symbols in the document. -
Page 4: Safety Symbols
INSTALLATION INSTRUCTIONS SAFETY SYMBOLS Wear Head Protection Use lifting equipment Switch On Wear High Visibility Clothing Caution, can cause injury Switch Off Wear safety goggles Do NOT operate in high winds Tarp Out Wear Protective Gloves Do NOT climb Tarp In Wear a Welding Mask Caution Weld... -
Page 5: Checklist 1/3
INSTALLATION INSTRUCTIONS CHECKLIST 1/3 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... - Page 6 INSTALLATION INSTRUCTIONS CHECKLIST 2/3 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
- Page 7 INSTALLATION INSTRUCTIONS CHECKLIST 3/3 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
- Page 8 INSTALLATION INSTRUCTIONS PAGE TITLE GROUND A - B = ....... - 300mm = HOUSING LEG LENGTH ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
-
Page 9: Housing
INSTALLATION INSTRUCTIONS HOUSING LEG - CUTTING STANDARD KIT INSTALL. PAGE 26 FOR TOWER FITTING FABRICATE X 2 LEGS LEG BOX B LEG BOX A REQUIRED LENGTH - 10MM* * ALLOWING FOR 2 X 5MM PLATES ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... - Page 10 INSTALLATION INSTRUCTIONS HOUSING LEG - INSTALLATION HEADBOARD DRILLING GUIDE 13Ø M12 x 50 Bolt M12 Nut LEG INSTALL M12 Washer x 16 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
- Page 11 INSTALLATION INSTRUCTIONS HOUSING LEG - INSTALLATION HOUSING UNDERSIDE M12 x 50 Bolt M10 x 30 DOME BOLT M12 Nut U-34SH-01 U-EXRB-01 U-34B-01 M12 Washer x 16 VC-HOUSD-02 VC-HOUSC-01 MOTOR BOLT VC-HOUSE-02 VC-HOUSE-01 5.8 SELF FIXING SCREW VC-HOUSC-02 M16 X 30 U-MOTOR-01 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
-
Page 12: Spring Mount & Assembly
INSTALLATION INSTRUCTIONS SPRING INSTALLATION M12 x 30 Bolt x 24 M12 Nut x 24 M12 Washer x 24 M14 x 40 Bolt M14 Nut x 16 M14 Washer ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... - Page 13 INSTALLATION INSTRUCTIONS SPRING MOUNT POSITIONING APPROXIMATE MOUNT POSITION LARGEST BIN ADJUST UNTIL MOUNT IS POSITIONED CENTRALLY NOTE C ON PAGE 11 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
- Page 14 INSTALLATION INSTRUCTIONS SPRING MOUNT POSITIONING POSITION MOUNT ON OPPOSING SIDE WELD OR DRILL 13 Ø ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
-
Page 15: Primary Arm
INSTALLATION INSTRUCTIONS PRIMARY ARM INSTALLATION 35mm PRIMARY ARM SET VC-ARM-01 *SEE PAGE 10 CODE VC-ARM-01 • LOOSELY ATTACH ARM ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 16: Rear Rest
INSTALLATION INSTRUCTIONS REAR REST INSTALLATION VC-ARM-01 ........................U-BUFF-04 VC-SRR-01B VC-SRR-01A UNDERSIDE ONLY ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 17: Crossbar
INSTALLATION INSTRUCTIONS CROSSBAR DIMENSION MEASUREMENT B MEASUREMENT A ALLOW CLEARANCE ALLOW CLEARANCE BOOM ARM BOOM ARM MEASUREMENT A CROSSBAR LENGTH ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... - Page 18 INSTALLATION INSTRUCTIONS CROSSBAR INSTALLATION U-CB-01 VC-ARM-01 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
-
Page 19: Primary Arm - Drill
INSTALLATION INSTRUCTIONS ARMS - DRILLING PRIMARY ARM Drill point 1 Drill point 2 45° 62mm ................................................SECONDARY ARM Drill point 1 Drill point 2 45° 45mm ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 20: Arm Pivot
INSTALLATION INSTRUCTIONS SECONDARY ARM DIMENSION MARK +30MM PAST ARM MARK VC-PIVOT-02 MARK VC-PIVOT-01 VC-PIVOT-03 8Ø ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 21: Secondary Arm
INSTALLATION INSTRUCTIONS SECONDARY ARM INSTALLATION 19MM SECONDARY ARM SET - 32mm = *see page 14 VC-PIVOT-01 CODE SECONDARY ARM • DO NOT DRILL ARMS YET ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... - Page 22 INSTALLATION INSTRUCTIONS ARMS - FIXING M8 x 60 Bolt M8 Nut M8 Washer LEAVE UNATTACHED FOR TARP INSTALLATION ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
-
Page 23: Tarp Install - Crossbar
INSTALLATION INSTRUCTIONS TARP - INSTALLATION ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 24: Buffer Install
INSTALLATION INSTRUCTIONS BUFFER - INSTALLATION U-BUFF-03 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 25: Tarp Install - Housing
INSTALLATION INSTRUCTIONS TARP - INSTALLATION VC-HOUS-01 ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 26: Electric Install
INSTALLATION INSTRUCTIONS WIRING ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 27: Tower Option
INSTALLATION INSTRUCTIONS TOWER INSTALLATION - HEIGHT ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... - Page 28 INSTALLATION INSTRUCTIONS TOWER INSTALLATION - CENTRE REAR VIEW ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
- Page 29 INSTALLATION INSTRUCTIONS TOWER INSTALLATION - SUPPORT DIAGRAMS FOR ILLUSTRATION PURPOSES ONLY • FABRICATE SUITABLE SUPPORT PLATES ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
- Page 30 INSTALLATION INSTRUCTIONS TOWER INSTALLATION - SUPPORT DIAGRAMS FOR ILLUSTRATION PURPOSES ONLY ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
- Page 31 INSTALLATION INSTRUCTIONS TOWER INSTALLATION - SUPPORT ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022...
-
Page 32: Tower - Electrics
INSTALLATION INSTRUCTIONS TOWER INSTALLATION - WIRING U-SUSI-01 U-RB-01 U-80F-01 +24V - NEG CONNECT ONLY WHEN ALL WIRING IS COMPLETE ORIGINAL DOCUMENT WRITTEN IN ENGLISH (UK) V2 - REVISED 2022... -
Page 33: Tower Leg - Pneumatics
INSTALLATION INSTRUCTIONS TOWER - PNEUMATICS • RECOMENDED CONFIGURATION HANDBRAKE SIGNAL RECOMMENDED + 24V NEGATIVE - 5 AMP FUSE • VENT • RAISE (UP) • LOWER (DOWN) • AIR IN CONTROL BOX HAS A 3 MIN DROP DOWN FUNCTION ENABLED BY DEFAULT. TO CHANGE SETTING, REFER TO PAGES XX-XX •... -
Page 34: Tower - Control Box
INSTALLATION INSTRUCTIONS CONTROL BOX - SETTINGS • RECOMENDED CONFIGURATION • NEGATIVE - + 24V IGNITION - LIVE / 5 AMP FUSE • NÉGATIF - + 24V ALLUMAGE / FUSIBLE DE 5 AMPÈRES • NEGATIV - + 24V ZÜNDUNG / 5 AMPERE SICHERUNG ...................................... - Page 35 www.transcover.com...
