- Page 1 EVEREST CONNECTIVITY INSTALLATION AND USE TECHNICAL MANUAL Read and understand Multiple instructions: the instructions before Consult the specific part undertaking any work on the unit MTEC.EVEREST 290 CONNECTIVITY.GB-1 English Manual Rev. 1 07-2023 Original Instructions...
- Page 2 EVEREST 290 CONNECTIVITY Reproduction, data storage and transmission, even partial, of this publication, in any form, without the prior written authorisation of the Company, is prohibited. The Company can be contacted for all inquiries regarding the use of its products. The Company follows a policy of continuous product development and improvement and reserves the right to modify specifications, equip- ment and instructions regarding use and maintenance at any time, without notice.
-
Page 3: Table Of Contents
EVEREST 290 CONNECTIVITY INDEX 1. EVEREST CONNECTIVITY ..................................2. INTRODUCTION ..................................... 2.1 KG5/KG10 kit installation ..............................2.2 KGR5/KGR10 and KGH5/KGH10 kit installation ....................... 2.3 KTA kit installation ................................3. ACTIVATION AND USE ................................... 3.1 Local Wi-Fi ..................................3.2 Tablet .................................... -
Page 4: Everest Connectivity
EVEREST 290 CONNECTIVITY 1. EVEREST CONNECTIVITY Remote Web connection with RMS option Ethernet Cable Local Wi-Fi Switch (KG5/KG10) Tablet (KTA) Router (KGR5/KGR10) Router + HiWeb (KGH5/KGH10) MTEC.EVEREST 290 CONNECTIVITY.GB-1 English Manual Rev. 1 07-2023... - Page 5 EVEREST 290 CONNECTIVITY Software Hardware Interfaces Possible communications Interfaces Customer’ Tablet Communication of proxi- Remote WEB connection c-field HiWeb smartphone/tablet/pc kit KTA mity (local network) with RMS accessory √ √ √ KGR5 √ √ √ √ √ √ √ √ KGH5 √...
-
Page 6: Introduction
EVEREST 290 CONNECTIVITY 2. INTRODUCTION The PLC control on each module contains a user interface program that can be used on devices connected to a local Wi-Fi network or via the Web (upon internet connection of the unit). This programs allows to access all the functions present in the basic graphic display installed onboard the machine (PGD) and it allows to interact with the PLC control of each module that make up the unit in a simple and fast way. -
Page 7: Kgr5/Kgr10 And Kgh5/Kgh10 Kit Installation
EVEREST 290 CONNECTIVITY 3. Bring the power supply to the sockets following the wiring diagram provided (A). 4. Connect to the ethernet ports of the switches: • the network cables coming from all the modules that make up the modular system (B); •... -
Page 8: Kta Kit Installation
EVEREST 290 CONNECTIVITY 3. Fix the external antenna to the side panel by opening the specific sheet precut (A) and connect 3 cables (LTE MAIN, LTE AUX and WI-FI MAIN) of the antenna (B) to the router (C) as shown in the images. 2.3 KTA kit installation It is mandatory to install the KTA kit on the same module in which the KGH5/KGH10 kit or the KGR5/KGR10 kit is present 1. -
Page 9: Activation And Use
EVEREST 290 CONNECTIVITY 3. ACTIVATION AND USE The methods for activating and using the local Wi-Fi network and activating and using an Internet connection for remote management of the modules are described below. 3.1 Local Wi-Fi If the modular system is equipped with a router accessory (KGR5/KGR10 or KGH5/KGH10), it is possible to access locally, with a smartphone or tablet device with a Web browser, the local Wi-Fi network that the router automatically creates. -
Page 10: Tablet
EVEREST 290 CONNECTIVITY 3.3 RMS Using the router present in the KGR5/KGR10 or KGH5/KGH10 accessory, this function allows remote access to the unit and to HiWeb (if present) via Internet connection. Once the router is connected to the Internet in a stable manner in one of the ways described below, con- tact the manufacturer who will provide for the activation of the remote connection. - Page 11 EVEREST 290 CONNECTIVITY 4. Proceed in the Network - Wireless menu and scan the area to find existing network. 5. Select the desired network from the list. Press the “JOIN NETWORK” button 6. Continue the steps with the connection by entering the password of the chosen existing Wi-Fi network. 7.
- Page 12 EMICON AC SPA Via A. Volta, 49 ▪ cap 47014 ▪ Meldola (FC) Tel. +39 0543 495611 ▪ Fax +39 0543 495612 emicon@emiconac.it ▪ www.emiconac.it P.IVA e C.F 03402390409 ▪ R.E.A. 299199 Technical data shown in this booklet are not binding.
