PAE
/ PAE WA Kp- GPE
AIR COOLED MULTIFUNCTION UNITS FOR 4-PIPE SYSTEMS
FOR OUTDOOR INSTALLATION
WITH SEMIHERMETIC RECIPROCATED COMPRESSORS AND AXIAL FANS
INSTALLATION, USE AND MAINTENANCE
TECHNICAL MANUAL
Multiple instructions:
the instructions before
the unit
MTEC.PAE/GPE.GB-1
PAE Kp/PAE WA Kp/GPE Kp
Rev. 1 03-2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAE Kp Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emicon PAE Kp Series

Summary of Contents for Emicon PAE Kp Series

  • Page 1 / PAE WA Kp- GPE AIR COOLED MULTIFUNCTION UNITS FOR 4-PIPE SYSTEMS FOR OUTDOOR INSTALLATION WITH SEMIHERMETIC RECIPROCATED COMPRESSORS AND AXIAL FANS INSTALLATION, USE AND MAINTENANCE TECHNICAL MANUAL Multiple instructions: the instructions before the unit MTEC.PAE/GPE.GB-1 PAE Kp/PAE WA Kp/GPE Kp Rev.
  • Page 2 PAE Kp / PAE WA Kp / GPE Kp Declaration of conformity MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...

  • Page 3: Table Of Contents

    PAE Kp / PAE WA Kp / GPE Kp INDEX 1. INTRODUCTION ................................................................................................................................................................................................................................................................................................................................................................................2. SAFETY .............................................................................................................................................................................. 3. TECHNICAL CHARACTERISTICS ................................................................3.2 Other versions ................................... 3.3 Options ....................................
  • Page 4 PAE Kp / PAE WA Kp / GPE Kp 6.5 Everest: ........................... 6.6 A ..............................6.7 T ................................................................6.9 I/O ..............................................................................................7. MAINTENANCE OF THE UNIT ........................................................................................................................................................................................................................... 8. DECOMMISSIONING ..................................... 8.1 Disconnect the unit ..........................................................

  • Page 5: Introduction

    PAE Kp / PAE WA Kp / GPE Kp 1. INTRODUCTION 1.1 Preliminary information these instructions. 1.2 Aim and content of the manual instructions. 1.3 How to store this manual user. 1.4 Manual Update 1.5 How to use this manual MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 6 PAE Kp / PAE WA Kp / GPE Kp 1.6 Potential Risks LOCATION OF POTENTIAL RISK METHOD OF INJURY PRECAUTIONS RISK Burns. severe burns. unit enclosure severe burns. severe burns. Entire unit Entire unit MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 7 PAE Kp / PAE WA Kp / GPE Kp 1.7 General Description of Symbols Used BANNED WARNING ACTION REQUIRED MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 8 PAE Kp / PAE WA Kp / GPE Kp 1.8 Safety symbols used GENERAL RISK ELECTRICAL HAZARD MOVING PARTS HOT SURFACES SHARP SURFACES EARTH CONNECTION READ AND UNDERSTAND THE INSTRUCTIONS RECOVER OR RECYCLE MATERIAL 1.9 Glossary 1.10 Limitations and prohibited use MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 9 PAE Kp / PAE WA Kp / GPE Kp TEL.+39 0543495611 FAX+39 0543 495612 NB 0948 B 0948 Via A.Volta 49 Meldola FC ITALY MODELLO ANNO DI COSTRUZIONE / PED CATEGORIA MODEL 2019 MANIFACTURE YEAR / PED CATEGORY MODèLE JAHR VON KONSTRUCT / PED KATEGORIE ED KAT MODEL ANNè...

  • Page 10: Safety

    PAE Kp / PAE WA Kp / GPE Kp 2. SAFETY 2.1 Warning on potentially dangerous toxic substances WARNING! The refrigerante R290 (PROPANE) is flammable and it must be handled only by competent and responsible operators, under the conditions spe- cified in the safety regulations in force.
  • Page 11 PAE Kp / PAE WA Kp / GPE Kp CHEMICAL COMPOSITION OF PROPAN USED AS A REFRIGERANT: Sulfur 2.1.3 Effects of discharges 2.1.4 Exposure controls and personal protection 2.1.5 Professional exposure limits MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 12 PAE Kp / PAE WA Kp / GPE Kp 2.2 Refrigerant handling 2.3 Prevent inhalation of high vapor concentration 2.4 Procedures to be adopted in the event of accidental release of refrigerant 2.5 Main Toxicological Information Regarding the Type of refrigerant used 2.5.1 Inhalation 2.5.2 Contact with skin 2.5.3 Contact with eyes...

  • Page 13: Technical Characteristics

    PAE Kp / PAE WA Kp / GPE Kp 3. TECHNICAL CHARACTERISTICS 3.1 Unit description 3.1.1 Frame 3.1.2 Compressors 3.1.3 Heat exchanger 3.1.4 Coils 3.1.5 Axial Fans 3.1.6 Cooling circuit 3.1.7 Hydraulic circuit MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 14 PAE Kp / PAE WA Kp / GPE Kp 3.1.8 Electrical board 3.1.9 Safety gas sensor MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...

  • Page 15: Other Versions

    PAE Kp / PAE WA Kp / GPE Kp 3.2 Other versions 3.2.1 Standard version MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...

  • Page 16: Options

    PAE Kp / PAE WA Kp / GPE Kp 3.3 Options Amperometer and voltmeter HRV2 High pressure double safety valve SNMP or TCP/IP Protocol serial interface: KG10 KGH5 KGH10 KGR5 KGR10 KP10 MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 17 PAE Kp / PAE WA Kp / GPE Kp Phase monitor: Handling brackets for forklift Remote display in case of multiple units MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 18 PAE Kp / PAE WA Kp / GPE Kp 3.4 Technical data Everest PAE 881 Kp Cooling Axial fans 35390 User side plate exchanger Pump group P1 Current Heating SCOP Axial fans 32480 User side plate exchanger Pump group P1 Current MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 19 PAE Kp / PAE WA Kp / GPE Kp Everest PAE 881 Kp Refrigerant data R290 18.3 Weights Dimensions Depth 1100 Sound data Power supply 400/3/50 + PE MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 20 PAE Kp / PAE WA Kp / GPE Kp Everest PAE 881 WA Kp Cooling SEER Axial fans 38770 User side plate exchanger Pump group P1 Current Heating SCOP Axial fans 32470 User side plate exchanger Pump group P1 Current MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 21 PAE Kp / PAE WA Kp / GPE Kp Everest PAE 881 WA Kp Refrigerant data R290 18.3 Weights Dimensions Depth 1100 Sound data Power supply 400/3/50 + PE MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 22 PAE Kp / PAE WA Kp / GPE Kp Everest GPE 881 Kp Cooling Axial fans 35070 Cold user side plate exchanger Pump group P1F Current Heating Axial fans 34120 Hot user side plate exchanger Pump group P1C Current Cooling while heating Hot user side plate exchanger MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 23 PAE Kp / PAE WA Kp / GPE Kp Everest GPE 881 Kp Pump group P1C Current Cold user side plate exchanger Pump group P1F Current Refrigerant data R290 18.3 Weights Dimensions Depth 1100 Sound data Power supply 400/3/50 + PE MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 24 PAE Kp / PAE WA Kp / GPE Kp 3.5 Operational limits 3.5.1 PAE Kp 3.5.2 PAE WA Kp 3.5.3 GPE Kp -30 -20 -10 -20 -10 0 10 20 30 40 50 MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 25 PAE Kp / PAE WA Kp / GPE Kp MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 26 PAE Kp / PAE WA Kp / GPE Kp 3.6 Correction tables 3.6.1 Operation with glycol Glycol percentage IPCF WFCF PDCF -3.2 0.985 1.02 1.08 -7.8 0.98 0.99 1.05 1.12 -14.1 0.97 0.98 1.09 1.22 -22.3 0.965 0.97 1.14 1.25 -33.8 0.955 0.965...

  • Page 27: Installation

    PAE Kp / PAE WA Kp / GPE Kp 4. INSTALLATION 4.1 General safety guidelines and and use of symbols tion. 4.2 Health and safety Considerations 4.3 Personal protective equipment MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.

  • Page 28: Inspection

    PAE Kp / PAE WA Kp / GPE Kp 4.4 Inspection In Case of Damage 4.5 Transport and handling MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 29 PAE Kp / PAE WA Kp / GPE Kp DO NOT SMOKE 4.6 Storage 4.7 Unpacking MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 30 PAE Kp / PAE WA Kp / GPE Kp 4.8 Lifting and handling MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 31 PAE Kp / PAE WA Kp / GPE Kp 4.9 Location and minimum technical clearances 4.9.1 ATEX minimum technical spaces MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 32 PAE Kp / PAE WA Kp / GPE Kp 4.9.2 Single unit minimum technical spaces 4.9.3 Modular system minimum technical spaces 4.9.3 Connecting and positioning multiple units H min MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 33 PAE Kp / PAE WA Kp / GPE Kp 4.10 Hydraulic connections • • • • • • MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 34 PAE Kp / PAE WA Kp / GPE Kp °C °C MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 35 PAE Kp / PAE WA Kp / GPE Kp 4.11 Hydraulic circuit User 1 User 2 MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 36 PAE Kp / PAE WA Kp / GPE Kp 4.12 Chemical characteristics of the water Table key Important Note: The following paratmeters can also influence the corrosion resistence + Good resistance under normal conditions Temperature: The data in the table are based water temperature of 20°C unless otherwise is stated.
  • Page 37 PAE Kp / PAE WA Kp / GPE Kp 4.13 User circuit minimum water content PAE 881 Kp PAE 881 WA Kp GPE 881 Kp 4.14 Filling the hydraulic circuit • • • • • 4.15 Emptying the installation • •...
  • Page 38 PAE Kp / PAE WA Kp / GPE Kp FROST PROTECTION MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 39 PAE Kp / PAE WA Kp / GPE Kp 4.16.1 Connection of power cables continue the service. Kit KP5 MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 40 PAE Kp / PAE WA Kp / GPE Kp 4.17 Connection of mains cables between multiple units present. Unit 1 Unit 2 Unit n to BMS MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 41 PAE Kp / PAE WA Kp / GPE Kp to BMS Kit KG5 Kit KP5 KG5 Kit MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 42 PAE Kp / PAE WA Kp / GPE Kp 4.18 Electric data The use of the unit with a power supply with higher variations than those indicated will invalidate the warranty. EVEREST290 PAE 881 Kp PAE 881 WA Kp GPE 881 Kp Power supply 400/3/50 + GDN 400/3/50 + GDN...

  • Page 43: Unit Start Up

    PAE Kp / PAE WA Kp / GPE Kp 5. UNIT START UP 5.1 Preliminary checks 5.1.1 Before start-up • • • • • • • • • • • • • 5.1.2 Commissioning MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 44 PAE Kp / PAE WA Kp / GPE Kp 5.1.3 Device and security Set-point Device Set-point Differential Reset ----- ----- ---- ----- ---- ---- 5.1.4 Controls during unit operation • • MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 45 PAE Kp / PAE WA Kp / GPE Kp 5.2 Safety valves people. 5.2.1 Connection to safety valves Outlet diameter Intervention pressure VS Low pressure MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 46 PAE Kp / PAE WA Kp / GPE Kp 10 m 5.3 Description of the control panel 5.3.1 Key function MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...

  • Page 47: Use

    PAE Kp / PAE WA Kp / GPE Kp 6. USE 6.1 Quick menu DOWN ON / OFF Info 6.2 ON / OFF Display DOWN ENTER once the ON / OFF M 18:15 12/04/23 READY User IN 9.2° C User OUT 22.2°...
  • Page 48 PAE Kp / PAE WA Kp / GPE Kp Info → Comp. Circ1 Qc003 Info → EEV circ.1 Qc004 49% 237 stp Set: Suction SH 6.8°C 6.7°C Info → Src. circ.1 Qc006 Ext. t: -25.0°C Coil t.: -3.2°C Status: Anti frost Evap.

  • Page 49: Set Point

    PAE Kp / PAE WA Kp / GPE Kp Info → Defrost circ.1 Start Defrost Delay: Missing Time to Next: Info → Plant Qc017 W Out t: 22.2°C W In t: 14.5°C P1: On Fl: Ok Set.: 8.0°C Req.: 100.0% 6.4 Set point DOWN ENTER once the SET...
  • Page 50 PAE Kp / PAE WA Kp / GPE Kp DOWN ENTER once the EVE M 18:15 12/04/23 PLANT REG. User IN 14.5° C User OUT 22.2° C HW IN 52.8° C HW OUT 44.6° C Info Modules Qe001 Process Temp. : 14.5°C Info Modules Qe003...
  • Page 51 PAE Kp / PAE WA Kp / GPE Kp 6.6 Access to the main menu M 13:09 26/04/23 READY User IN 14.5°C User OUT 22.2°C HW IN 52.8°C HW OUT 44.6°C DOWN ENTER User Password is 0001 Login Main menù 1 / 9 A.
  • Page 52 PAE Kp / PAE WA Kp / GPE Kp Source E0029 Source E0026 Defrost Ext. Coil thresholds Defrost Type: EVAP. & EXT COIL TEMP. Set: -2.5 °C Reset: -1.0 °C End: 10.0 °C 6.7 Time bands 6.7.1 Time bands settings Main menù...
  • Page 53 PAE Kp / PAE WA Kp / GPE Kp With UP DOWN ENTER Use UP DOWN ENTER Setpoint Ac001 Setpoint Ac002 COMFORT PRE-COMFORT DHW: 53.1°C DHW: 45.0°C Cooling: 10.0°C Cooling: 12.0°C Setpoint Ac003 ECONOMY DHW: 40.0°C Cooling: 14.0°C 6.8 Second Set Point from ID Press PRG ENTER DOWN...

  • Page 54: I/O

    PAE Kp / PAE WA Kp / GPE Kp 6.9 I/O 6.9.1 General Press PRG ENTER DOWN Main menù 6 / 9 Unit menù 2 / 4 D. Heater a. General E. Source/Def b. In/Out c. Scheduler F. Unit 6.9.2 Digital inputs DIGITAL INPUTS Fb001 Input/Outputs...
  • Page 55 PAE Kp / PAE WA Kp / GPE Kp 6.9.4 Analogue inputs ANALOG INPUTS Fb200 Input/Outputs Fb204 HD Values Analog Outputs 14.5°C 22.2°C User inlet temp. 52.8°C 17.7°C (B01) 44.6°C 11.2 b 5.5 b -3.2 °C Value: 14.5 °C -25.0 °C 6.9.5 Analogue outputs ANALOG OUTPUTS Fb300...
  • Page 56 PAE Kp / PAE WA Kp / GPE Kp 6.10 Module control functions 6.10.1 Intelligent working point control 6.10.2 Ventilation 6.10.3 Valves 6.10.4 Compressors 6.10.5 Double electronic expansion valve 6.10.6 Advanced defrost logic MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 57 PAE Kp / PAE WA Kp / GPE Kp 6.11 Multi-element control functions Press PRG ENTER DOWN then press ENTER Main menù 8 / 9 Settings menù 4 / 6 c. Language G. Alarm logs H. Settings d. Serial ports I.
  • Page 58 PAE Kp / PAE WA Kp / GPE Kp 6.11.2 Thermoregulation and pump management 6.11.3 Call priority and balancing or saturation logics • Balancing • Saturation 6.11.4 Standby rotation 6.11.5 Communication failure and unit alarm MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.

  • Page 59: Maintenance Of The Unit

    PAE Kp / PAE WA Kp / GPE Kp 7. MAINTENANCE OF THE UNIT 7.1 General warnings • • • MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 60 PAE Kp / PAE WA Kp / GPE Kp 7.2 Drive access MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 61 PAE Kp / PAE WA Kp / GPE Kp 7.3 Routine maintenance Sight Inspection CASE Pressure test Leak detection 7.4 Exceptional Maintenance 7.4.1 Procedure for Vacuum break and Refrigerant Charging MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 62 PAE Kp / PAE WA Kp / GPE Kp 7.4.2 Extraction of a unit from the modular system MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 63 PAE Kp / PAE WA Kp / GPE Kp MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 64 PAE Kp / PAE WA Kp / GPE Kp 7.5 Periodical checks 7.5.1 Electrical system and control devices Frequency Actions Once MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 65 PAE Kp / PAE WA Kp / GPE Kp 7.5.2 Condensing coils fans and cooling circuit Frequency Actions Once every three months 7.5.3 Compressor Frequency Actions Once MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 66 PAE Kp / PAE WA Kp / GPE Kp 7.5.4 Check and calibration of the refrigerant leak detector tions: • • • • 7.5.6 End of seasons hours. 7.5.7 Unit OFF MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev.
  • Page 67 PAE Kp / PAE WA Kp / GPE Kp 7.6 Refrigerant circuit repair Therefore: • • • • • • MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...

  • Page 68: Decommissioning

    PAE Kp / PAE WA Kp / GPE Kp 8. DECOMMISSIONING 8.1 Disconnect the unit • • • • • 8.2 Disposal, recovery and recycling MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...

  • Page 69: Dimensional Drawings

    PAE Kp / PAE WA Kp / GPE Kp 9. DIMENSIONAL DRAWING PAE 881 Kp PAE 881 WA Kp MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 70 PAE Kp / PAE WA Kp / GPE Kp GPE 881 Kp MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 71 PAE Kp / PAE WA Kp / GPE Kp MTEC.PAE/GPE.GB-1 Operation and maintenance manual PAE Kp/PAE WA Kp/GPE Kp series English Rev. 1 03-2023...
  • Page 72 EMICON AC SPA...
