14 C 1: I
HAPTER NTRODUCING THE
Minimum System
and Component
Requirements

Front Panel

A P
CCESS OINT
Your Access Point requires that the computer(s) and components in your
network be configured with at least the following:
A computer with an operating system that supports TCP/IP
networking protocols (for example Windows 95/98/NT/Me/2000/XP,
Unix, Mac OS 8.5 or higher).
An Ethernet 10Mbps or 10/100 Mbps or 10/100/1000 Mbps NIC.
An 802.11b, 802.11g or 802.11a wireless NIC.
A Web browser program that supports JavaScript, such as Netscape
4.7 or higher, Internet Explorer 5.0 or higher, or Mozilla 1.2.1 or
higher.
The front panel of the Access Point contains a series of indicator lights
(LEDs) that help describe the state of various networking and connection
operations.
Figure 2 Access Point - Front Panel
1 2
WLAN
Alert Power 11g 11a
1 Alert LED
Orange
Indicates a number of different conditions, as described below.
Off - The Access Point is operating normally.
Flashing quickly - Indicates one of the following conditions:
The Access Point has just been started up and is running a self-test
routine, or
The administrator has invoked the Reset to Factory Defaults
command, or
The system software is in the process of being upgraded
3 4
LAN Status
3CRWE454A72
OfficeConnect Wireless 11a / b / g Access Point
