A S S E M B L Y
Step 1
Attach the back rail legs(H) to the
Back Rail Bottom (G) using wood
dowels(R) & 3 1/4" Bolts(L) & Barrel
Nuts(P). See Figure 1.
Model shown is example only.
Styles may vary.
P
L
LaJobi Industries. - 257 Prospect Plains Rd. Cranbury,NJ 08512-Phone: 888-266-2848
Bulletin No. A-RTAUPS01-00
I N S T R U C T I O N S (continued)

Crib Assembly

L
H
L
F
R
Figure 2
R
P
G
P
Step 2
Q
Attach the Back Rail Middle(F) to the
L
back rail using wood dowels (R), then
insert 3 1/4" bolts(L) ,through the
back rail legs into the threaded insets
onto the back rail middle as shown in
Figure 2.
Model shown is example only.
Styles may vary.
6
L
R
H
P
L
P
Figure 1
Q
