  • Page 1 PASLODE IMPULSE TRIMMASTER 14/16G STRAIGHT BRADDER MANUAL IMPORTANT! Updated maintenance ANZ Product Code B20711 schedule instructions...
  • Page 2: Table Of Contents

    TOOL MAINTENANCE ..................11 TOOL SPECIFICATIONS ..................12 SCHEMATICS ....................13 REGISTER MY TOOL Register your Paslode tool today to ensure your details are kept safe and you maximise the benefits of your Paslode Warranty. Why it’s important to register your tool: • Lost or stolen tool?
  • Page 3: General Safety Instructions

    GENERAL SAFETY INSTRUCTIONS Congratulations on the purchase of your new Paslode Impulse Trimmaster 14/16G Straight Bradder. MAINTENANCE The Impulse system consists of: tool, fuel cell, battery, charger and fasteners. In the interests of operator Restrict Field Maintenance to the following:...
  • Page 4: Tool Safety Instructions

    REMOVING FASTENERS. ALWAYS REMOVE THE THE MANUFACTURER. FUEL CELL AND BATTERY BEFORE CHECKING THE TOOL. 22. ONLY USE PASLODE SPECIFIED CONSUMABLES, BATTERIES AND FUEL CELLS. CONSUMABLES, NEVER OPERATE THE IMPULSE TRIMMASTER BATTERY AND FUEL CELLS ARE A COMBINED IF PARTS ARE LOOSE, DAMAGED OR MISSING.
  • Page 5: Battery Safety & Charging

    Puncture or attempt to open battery case packaging. Please also observe possibly more detailed or cells. national regulations. For the transport of Paslode fuel cells use UN Code Store battery where it will be subjected to UN3478. temperatures above 49°C (120°F).
  • Page 6: Fuel Cell Safety

    Skin contamination should be removed with soapy water. FUEL CELL CHECK Paslode Impulse fuel cells are marked with If symptoms persist, seek medical assistance. a “Best Use Before” date on the bottom of the can. For maximum performance use fuel before the “Best Use Before”...
  • Page 7: Tool Overview

    TOOL OVERVIEW QUICK RELEASE - BYPASS FOLLOWER NOSE PLATE ASSEMBLY ND 2MM (14G) C 1.6MM (16G) SWAP-N-LOCK VERSION SOFT RUBBER TRIGGER SOFT GRIP HANDLE REAR LOAD MAGAZINE TOOL REST FIXTURE NO MAR WORK CONTACT TIP FLASHING GREEN = CHARGED FLASHING RED = NEEDS CHARGING DEPTH OF DRIVE ADJUSTMENT ADJUSTABLE BELT HOOK - RAFTER HOOK...
  • Page 8: Fuel Cell Loading Procedure

    FUEL CELL AND FASTENERS WHEN SERVICING OR CLEARING A JAM. ONLY USE PASLODE’S SPECIALLY FORMULATED FUEL, FAILURE TO DO SO MAY DAMAGE YOUR TOOL, CAUSE MISFIRES AND VOID WARRANTY. STRAIGHT BRADS ARE ONLY TO BE USED IN THIS TOOL. Load...
  • Page 9: Correct Tool Operating Procedures

    CORRECT TOOL OPERATING PROCEDURES ND Series 37 Nail per Strip, 2 strips per Load 2mm (14g) Smooth Shank Length - 40 to 62mm C Series Steel Framing Brad, 50 Brads per Strip, 2 strips per load 1.7mm (15g) 1.6mm Smooth Shank Smooth Shank Lengths - 25 to 65mm Length 38 to 45mm...
  • Page 10: Preparing And Use Of Tool

    PREPARING AND USE OF TOOL 49° ALWAYS WEAR EYE AND HEARING PROTECTION ADJUSTING THE DEPTH OF DRIVE - THUMB WHEEL ROTATION Note: When fixing Fibre Cement Sheets, its important to keep the Depth of Drive adjustment Shallow or Flush to material surface. Counter Counter Sunk...
  • Page 11: Troubleshooting

    TROUBLESHOOTING 49° ALWAYS REMOVE BATTERY, FUEL CELL AND FASTENERS WHEN SERVICING OR CLEARING A JAM. FIRING THE TOOL Tool Working Correctly Fan starts - Tool Fires PROBLEM: No fan and SOLUTION: does not fire • Check for flat battery • Remove and reinsert battery to reset tool •...
  • Page 12: Tool Maintenance

    TOOL MAINTENANCE 49° ALWAYS REMOVE BATTERY, FUEL CELL AND FASTENERS WHEN SERVICING OR CLEARING A JAM. TIP: It may be easier to clear a nail jam by first returning the driver blade to top rest position with a small diameter punch. Then remove the nail.
  • Page 13: Tool Specifications

    TOOL SPECIFICATIONS PASLODE IMPULSE TRIMMASTER 16A ANGLED BRADDER MAX FIRE RATE FIRE RATE TEMPERATURE RANGE hours seconds Celcius 1000 2 - 3 nails per second 40°F (5°C) to 120°F (49°C) TOOL TOOL MAGAZINE NAIL COLLATION SHANK TYPE OF DURABILITY SIZE...
  • Page 14: Schematics

    SCHEMATICS IM250SLi MK2 14/16 Gauge ◼ ⚫ Straight Bradder ⚫ TrimMaster B20711 ⚫ ⚫ ⚫ SERVICE KIT 009998 ⚫ ⚫ ⚫ ◼ Block not in kit 47 ◼ ◼ ◼ ◼ Torque Values (in/lb) Item Torque Item Torque 30-35 45-50 20-35 45-50 15-20...
  • Page 15 SCHEMATICS cont. PARTS LEGEND PASLODE IMPULSE IM250ALi MK2 16 GAUGE ANGLED BRADDER B20722 916222 Grill 900708 Screw SHC 8-32 x 1/2 (Red) 900648 Filter 900754 Screw SHC 8-32 x 1/2 (Yellow) 901064 Screw SHC 8-32 x 1-3/8 900726 Slide Switch Assembly...
  • Page 16 Carry Case 905640 9/64” Hex Key Maintenance tool 900736 Paslode Impulse Lubricating Oil B20544F Specially formulated for use in Paslode Impulse tools Impulse Tool Cleaner/Degreaser B20544L Recommended cleaner for Paslode Impulse tools No Mar Tips (3 pack) 902473 ND 2mm (14G) Nose Plate 916588 C 1.6mm (16G) Nose Plate...
