Paslode tetraGRIP tG100CSN Operating Manual And Schematic

Coil siding nailer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IMPORTANT!
DO NOT DESTROY
It is the customerʼs responsibility to have all
operators and service personnel read and
understand this manual.
© 2017 Illinois Tool Works Inc.
515448-1
04/17
OPERATING MANUAL AND
SCHEMATIC
1
MODEL tG100CSN

Advertisement

Table of Contents
loading

Related Manuals for Paslode tetraGRIP tG100CSN

Summary of Contents for Paslode tetraGRIP tG100CSN

  • Page 1 MODEL tG100CSN IMPORTANT! OPERATING MANUAL AND DO NOT DESTROY SCHEMATIC It is the customerʼs responsibility to have all operators and service personnel read and understand this manual. © 2017 Illinois Tool Works Inc. 515448-1 04/17...

  • Page 2: Table Of Contents

    INTRODUCTION The Paslode tetraGRIP™ 0º coil siding nailer is a quality-built tool designed for use ® in residential siding, exclusively with James Hardie Fiber Cement Siding products. This tool will deliver efficient, dependable performance when used according to the manufacturerʼs guide lines.

  • Page 3: Tool And Fastener Specifications

    TOOL AND FASTENER SPECIFICATIONS TOOL SPECIFICATIONS MODEL NO. tG100SCN (Part# 515400) 11.5” HEIGHT 6” WIDTH LENGTH 12.25" WEIGHT 4.9 lbs. OPERATING PRESSURE 80 to 120 psi (5.5 to 8.3 bar) 0 Degree, Plastic Coil MAGAZINE TYPE FASTENER SPECIFICATIONS NAIL LENGTH 1.125”...

  • Page 4: Safety Instructions

    CONTACTING ELEMENT Use only parts and fasteners specifically designed and This tool is equipped with a safety mechanism, called a recommended by Paslode for use in the tool and for ® a work contacting element, to help prevent accidental work to be done. Using unauthorized parts and fasteners firing.

  • Page 5: Tool Installation And Operation

    6. If this tool does not work when it is first connect- Step No. 4- Close the magazine cover and then ed, do not try to make repairs. Call your Paslode ® the gate making sure the gate is latched securely.
  • Page 6 Use only fasteners that meet Paslode specifications. ® charge. Use of fasteners that do not meet Paslode specifica- ® tions can result in damage to the tool or injury to the operator or bystanders.

  • Page 7: Air Systems

    -Be certain that: Filter/Regulator/Lubricator Units • Filter/regulator/lubricator units that can supply All pipes supplying air have a large enough enough air and protection for Paslode tools ® inside diameter to ensure adequate air supply. must meet the following specifications: •...
  • Page 8 For example, given a 20 hp electric compressor the operating requirements for the tools. supplying approximately 80 cfm of air at 120 psi Paslode tools are designed to operate and a main supply pipe length of 350 feet, we see ®...

  • Page 9: Features And Benefits

    tG100SCN FEATURES AND BENEFITS Adjustable Exhaust Cap Deflects air away from user. Comfort Grip Ergonomic design provides greater comfort. Metal Belt Hook Sequential Trigger (Gray) Adjustable Depth of Drive Lightweight Design 4.9 Lbs. Clear View, High Capacity Magazine No-Mar Work Contact...

  • Page 10: Exploded View And Spare Parts List

    PARTS LEGEND tG100CSN 515400 tetraGRIP™ 0º Coil Siding Nailer 502996 BHCS M5 x 10mm-P30 Precoat 515422 Indicator 502997 Flat Washer 515423 Spring 502969 Air Deflector 515424 Wave washer, 41 x 52mm 511065 515425 Set Screw ▲ 502998 Hex.SOC.HD.Bolt, M5 x 20mm 515445 Hex.SOC.HD.Bolt, M4 x 10 515447...
  • Page 11 CAP ASSEMBLY 515401 MODEL tG100CSN DRIVER Part# 515400 ASSEMBLY 515403 BODY W/THREAD INSERTS 515407 OPTIONAL TRIP FIRE TRIGGER ASSEMBLY (ORANGE) 502986 TRIGGER VALVE ASSEMBLY 515410 SEQUENTIAL CYLINDER TRIGGER ASSEMBLY ASSY. 515405 503055 (GRAY) DEPTH OF DRIVE ASSEMBLY 502993 ADJ. SAFETY UPPER WORK TIP ASSY.

  • Page 12: Maintenance

    Ensure that the required safety information on the tool ❑ is legible. Reduce the regulated air pressure to 30 psi. ❑ Use only Paslode approved fasteners in the tool, and ❑ Remove all fasteners from the tool. ❑ ensure that they are correct for the application.
  • Page 13 Use Chemplex grease, Part Assure long life and proper ® Lubricate "O" rings that are No. 403734. operation of tool. replaced. Use only Paslode replacement Order any repacement parts ® Keep tool operating efficiently parts. needed from Paslode Dealer. and maintain Paslode tool ®...

  • Page 14: Troubleshooting

    Fasteners drive too deeply into wood. Reduce air pressure. Make sure correct fasteners are being used. Use fasteners that meet Paslode specifications ® Tools skips during operation - no fasteners are only.

  • Page 15: Warranty

    90-DAY LIMITED WARRANTY Paslode's sole liability hereunder will be to replace any part or accessory which proves to be defective within the specific A 90-day warranty will apply to all parts, except time period.

  • Page 16: Accessories

    To purchase parts and accessories, visit www.itwconstructionparts.com. An Illinois Tool Works Company 155 Harlem Avenue Glenview, IL 60025 ® PASLODE is a registered trademarks of ITW. tetraGrip™ is a trademark of ITW. All other trademarks are property of their respective owners.
