Bromic Heating WATERBOY 7575150-VF Operation Manual

Congratulations on your purchase of your Bromic Waterboy
submersible Vortex sump pump.
This manual contains essential information on the installation,
operation and maintenance of the pump. Please read it thoroughly
and follow these instructions in order to install and use the pump
correctly. Failure to follow these instructions may result in motor
overcharging and other malfunctions. Bromic is not liable should
instructions not have been followed.
Specification
1. Maximum operating depth 5m below water level;
2. Continuous duty when fluid temperature under +40°C;
3. Value of PH in fluid 4~10;
4. Maximum kinematic viscosity: 7xl0
5. Maximum density: l.2xIO
Technical data (the data will be some change under
different voltage and frequency)
Power Voltage /
Discharge
Model Input Frequency
(mm)
(kw)
7575150-VF 0.34 40,32,25 220-240/50
Part View
2
1
3
4
5
6
7
~23x10 m /s;
-7 -6 2
kg/m
3 3
Max Max Max.
Weight
Flow Head Suspended
(kg)
(V/hz) (L/min) (m) Solid (mm)
Φ
133 7 15 9
2
9
5
8
10
3
4
11
12
13
14
15
16
17
18
19
35
20
36
21 22
23
24
25
26
13
27
28
47
29
30
Vortex Submersible Pump - 7575150-VF
Operation Manual
Performance Curve
Circuit Diagram
Packing (cm)
H x W x D
23.5x21.5x38.5
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
36
14
35
15
16
17
44
18
19
20
21
22
23
24
Description No. Description
Vertical float switch 25 Motor housing
Hex cap screw 26 Phillips screw
Cable flange 27 Motor protector
Cable protector 28 Stator
Phillips Screw 29 Wave washer
Vertical float bracket 30 Lower bearing
Self-tapping screw 31 Rotor
Handle 32 Lower bearing
Power cord 33 Seal washer
Cable clamp 34 Oil chamber
Cable gland 35 Button head screw
Hex head bolt 36 Seal washer
Spring washer 37 O ring
Washer 38 Mechnical seal
Capacitor cover 39 O ring
O ring 40 Oil chamber cover
Capacitor 41 Phillps screw
Phillips screw 42 Oil seal
Pressure plate 43 Impeller
Wire protector 44 Hexagonal nut
Seal washer 45 Outlet connector
Washer 46 O ring
Serrated lock washer 47 Pump casing
Phillips screw
06/2024 - V1.2
