- Page 1 ™ OwNERs MANUAL Model No. 45-0404 HEAVY DUTY POLY DUMP CART CAUTION: • Assembly Read Rules for • Operation Safe Operation • Maintenance and Instructions • Repair Parts Carefully the fastest way to purchase parts www.speedepart.com PRINTED IN USA FORM NO. 40146 (4/26/07)
-
Page 2: Carton Contents
sAFETY RULEs Remember, any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution at all times when using power equipment. CAUTION: VEHICLE BRAKING AND LOOK FOR THIs sYMBOL TO POINT OUT sTABILITY MAY BE AFFECTED wITH THE IMPORTANT sAFETY PRECAUTIONs. -
Page 3: Hardware Pack
HARDWARE SHOWN FULL SIZE Not Shown Full Size HARDwARE PACK REF. QTY. DEsCRIPTION REF. QTY. DEsCRIPTION Hex Bolt, 5/16" x 4" Nylock Nut, 3/8" Hex Bolt, 1/4" x 1-3/4" Cotter Pin, 1/8" x 1-1/2" Hex Bolt, 1/4" x 3/4" Flat Washer, 1/4" Hex Bolt, 3/8"... -
Page 4: Tools Required For Assembly
AssEMBLY INsTRUCTIONs 4. Hook the short end of the spring into the hole in the latch lock lever. Use the spring puller tool to hook the long end of the spring into the square hole in the tongue. The spring puller tool can be stored when finished. See TOOLs REQUIRED FOR AssEMBLY figure 2. - Page 5 7. Assemble the axle and drawbar tongue to the wheel 9. Assemble the latch stand plate and the latch stand support, with the open side of tongue facing away from bracket to the bottom of the poly tray using four 1/4" the wheel support.
-
Page 6: Operation
OPERATION MAINTENANCE CAUTION: VEHICLE BRAKING AND 1. At the beginning of each season, using a light machine sTABILITY MAY BE AFFECTED wITH THE oil, lubricate the latch, the latch pivot bolt, and the area ADDITION OF AN ACCEssORY OR AN of the axle where the draw bar tongue pivots . - Page 7 NOTEs...
- Page 8 REPAIR PARTs FOR HEAVY DUTY POLY DUMP CART MODEL 45-0404...
- Page 9 REPAIR PARTs FOR HEAVY DUTY POLY DUMP CART MODEL 45-0404 REF. PART QTY. DEsCRIPTION 47019 Poly Tray 25886 Axle, 1" 46272 Wheel 24758 Draw Bar Tongue 24386 Latch Stand Plate 24497 Latch Stand Bracket 24527 Wheel Support 24498 Latch Lock Lever 47407 Hex Bolt, 5/16-18 x 4"...
-
Page 11: Slope Guide
sLOPE GUIDE (Keep this sheet in a safe place for future reference.) Use this guide to determine if a slope is safe for the operation of your tractor and cart. Refer also to the instructions in your vehicle owners manual. -
Page 12: Repair Parts
Agri-Fab, Inc. Unauthorized uses and/or reproductions of this manual will subject such unauthorized user to civil and criminal penalties as provided by the United States Copyright Laws.
