Fireray 2000 EExd Installation Manual

Hazardous area smoke detector

Advertisement

Quick Links

Hazardous Area Smoke Detector
 KEY FEATURES
 Flameproof Receiver and Transmitter
 Standard Fireray Controller Unit
 High Coverage - up to 1500
 Low Cost
 Beam Range 10 metres to 100 metres
 12 Volts dc to 24 Volts dc operation
 Selectable Alarm Thresholds
 Low Current Consumption
 Manual or Automatic Fire Alarm Reset
 Automatic Fault Alarm Reset
 Ground Level Electronics
 Extremely Rugged
 Easy installation
 Low maintenance
DESCRIPTION
The FIRERAY 2000 EExd SMOKE DETECTOR SYSTEM is designed primarily to protect EExd, IIB
hazardous areas.
It consists of a standard Fireray 2000 Controller/Analyser, combined with highly rugged flameproof
Transmitter and Receiver heads.
The Transmitter and Receiver Heads are designed to be mounted within the protected hazardous area,
whilst the Analyser is housed outside it. Using the Standard Analyser unit in this way allows a
significant cost reduction when compared to a system utilising flameproof enclosures for all component
parts. The maximum lateral beam coverage is 15m per Fireray System installed.
Once installed, the Transmitter Head projects a modulated Infra-Red Beam across the protected area, to
the Receiver head mounted opposite. The received signal strength is monitored and analysed in the
Ground Level Controller. Should the beam strength fall below the preset threshold for more than 8 -10
seconds, a Fire Alarm is signalled to the Control Equipment. The analyser also incorporates monitoring
for cable breaks or loss of function at the Transmitter or Receiver. If the signal strength is reduced
suddenly (<5 seconds) by greater than 93% a Fault Alarm is indicated to the Control equipment. The
Fire and Fault Alarm outputs are provided via two sets of Voltage-Free change-over relay contacts.
The Fire Alarm Relay may be set for latched or auto-reset operation as desired. The Fault Alarm is
designed to auto-reset once the signal is returned to serviceable limits.
The system may be used with 'intelligent' or 'non-intelligent' systems. Due to the very low current
consumption, back-up battery life is extended and the system may be powered from alarm loop supplies
in most cases.
1 x Transmitter Head (With Clear Lens)
1 x Receiver Head (With Dark Lens)
1 x Controller/Analyser Unit
1 x Adjustable Head Mounting Bracket
1 x Bag of Bracket Fixings
FIRERAY 2000 EExd
Installation Guide
2
m per system
PARTS LIST
Page 1 of 12
 APPLICATIONS
 Ex II 2 G Environments
 Refineries
 Mills
 Munitions Factories
 Munitions Stores
 Flammable Liquid Stores
 Flammable Gas Stores
 Flammable Powder Stores
 Industrial Plants
 Power Stations
 Warehouses
 Applications requiring highly rugged
detector heads
1 x Test Filter
1 x Installation Guide (This document)
2 x Allen keys (5mm & 10mm)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2000 EExd and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fireray 2000 EExd

  • Page 1  Easy installation detector heads  Low maintenance DESCRIPTION The FIRERAY 2000 EExd SMOKE DETECTOR SYSTEM is designed primarily to protect EExd, IIB hazardous areas. It consists of a standard Fireray 2000 Controller/Analyser, combined with highly rugged flameproof Transmitter and Receiver heads.
  • Page 2: Statement Of Intended Use

    STATEMENT OF INTENDED USE This system is intended for use as a Smoke Detector only, in EExd IIB, or lower grade areas. It must not be used in areas with a greater hazard rating. It must be installed and tested by approved, competent personnel, in accordance with all regulatory and local codes of practise.
  • Page 3: Principle Of Operation

    WARNING The area into which the Fireray parts are to be fitted must be made safe before attempting any work on the system. It must also be checked thoroughly prior/during/after commissioning, to ensure it cannot compromise the safety of the area in which it is fitted. Note that only the Transmitter and Receiver parts may be installed in the hazardous area, NOT the Controller Unit.
  • Page 4  By de-powering the system for 1 second, then re-powering. Following a reset the system takes 50 seconds to self-calibrate. During this time the Fireray adjusts it’s 100% signal reference level and so must have a clear unobstructed beam. No tests should be carried out until this initialisation period has elapsed.
  • Page 5  During installation, no threshold switch set at the Controller Unit (One switch only must be set). Possible Causes Of FIRE And FAULT Alarms Together  AGC at limit of compensation, COMP switch OPEN (UK installations only) and beam strength reduced by more than the set threshold.
  • Page 6 screws, between the Receiver Case and the mounting surface. (Some applications may require fabrication of angled mounting brackets etc, in order to cope with awkward wall positions etc. These are not supplied). Install all required cabling to the defined positions for each system part. (See wiring diagram on following page, for a typical installation).
  • Page 7: Testing The System

    TESTING THE SYSTEM Following installation, test the system as follows :- First ensure that the system is running and has been allowed time to calibrate (50 seconds after power- up or reset). Fire Alarm  Place the striped end of the test filter over the Receiver lens. ...
  • Page 8: Non-Hazardous Area

     Typical installation shown (See text). Rx EXTERNAL CASE RELAY WIRING, EARTH (SEE TEXT)  Do not omit any Earth connections. CONNECT AS REQUIRED  MICC cable recommended for all cabling. TO INDICATING EQUIPMENT  Approved, EExd glands must be used at the Rx and Tx, and at the interface partitioning the METAL EExd hazardous and non-hazardous areas.
  • Page 9 VIEW INSIDE TRANSMITTER UNIT WITH TOP WINDOW SECTION REMOVED SHOWING TERMINALS AND SETTINGS ETC note: some components not shown for clarity External Earth terminal will be found in one of these two positions Do not use this hole for cable entry REF: (EExd blanking plug fitted at factory) Range switch shown set to 100m.
  • Page 10 VIEW INSIDE RECEIVER UNIT WITH TOP WINDOW SECTION REMOVED SHOWING TERMINALS AND SETTINGS ETC note: some components not shown for clarity External Earth terminal will be found in one of these two positions Do not use this hole for cable entry (EExd blanking plug fitted at factory) User wiring terminals.
  • Page 11 This page left intentionally blank Page 11 of 12...
  • Page 12 FIRERAY 2000 EExd - SYSTEM SUPPLY CURRENT Control/Rx (Normal) 7.5mA @ all ranges SPECIFICATION Control/Rx (Alarm) 13.5mA @ all ranges 1.6mA @10m to 5.6mA max @100m SUPPLY RIPPLE SYSTEM TYPE 0.5V p-p min, sine, 50-100Hz @11.5Vdc Transmitter (TX) Rugged for EExd IIB areas - IP67...
