Operator's Manual
with Maintenance Information
First Edition
Second Printing
Part No. 82206

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS-3384 and is the answer not in the manual?

Questions and answers

Related Manuals for Genie GS-3384

Summary of Contents for Genie GS-3384

  • Page 1 Operator’s Manual First Edition Second Printing with Maintenance Information Part No. 82206...

  • Page 2: Table Of Contents

    First Edition: Second Printing, January 2003 Internet: http://www.genielift.com "Genie" is a registered trademark of e-mail: techpub@genieind.com Genie Industries in the U.S.A. and many other countries. "GS" is a trademark of Genie Industries. These machines comply with ANSI/SIA 92.6-1999. Printed on recycled paper Printed in U.S.A.

  • Page 3: Safety

    5 Only use the machine as it was intended. You read, understand and obey: Manufacturer's instructions and safety rules—safety and operator's manuals and machine decals employer's safety rules and worksite regulations applicable governmental regulations You are properly trained to safely operate the machine. Part No. 82206 Genie GS-3384...
  • Page 4 Phase to Phase Approach Distance Feet Meters 0 to 300V Avoid Contact 300V to 50KV 3.05 50KV to 200KV 4.60 200KV to 350KV 6.10 350KV to 500KV 7.62 500KV to 750KV 10.67 750KV to 1000KV 13.72 Genie GS-3384 Part No. 82206...
  • Page 5 Models without outriggers: Do not raise the platform unless the machine is on a firm, level surface. Maximum capacity - GS-3384 Maximum occupants Models with one platform extension Platform retracted...
  • Page 6 Do not place ladders or scaffolds in the platform or against any part of this machine. Genie GS-3384 Part No. 82206...
  • Page 7 Do not climb down from the platform when raised. Keep the platform floor clear of debris. Close the entry gate before operating. Do not operate the machine unless the guard rails are properly installed and the entry is secured for operation. Part No. 82206 Genie GS-3384...
  • Page 8 Do not operate a machine in the path of any crane or moving overhead machinery unless the controls of the crane have been locked out and/or precautions have been taken to prevent any potential collision. No stunt driving or horseplay while operating a machine. Genie GS-3384 Part No. 82206...
  • Page 9 Immediately tag and remove from service a damaged or malfunctioning machine. Be sure all maintenance has been performed as specified in this manual and the appropriate Genie service manual. Be sure all decals are in place and legible. Be sure the operator’s, safety and responsibilities manuals are complete, legible and in the storage container located in the platform.
  • Page 10 Operator's Manual First Edition • Second Printing SAFETY RULES Decal Legend Genie product decals use symbols, color coding and signal words to identify the following: Safety alert symbol—used to alert personnel to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.

  • Page 11: Legend

    12 Tilt alarm (behind ground 6 Platform guard rails 20 Safety arm (hidden from view) control panel) 7 Manual storage container 13 Entry ladder 8 Platform extension 14 Steer tire Part No. 82206 Genie GS-3384...

  • Page 12: Controls

    3 Engine start toggle switch 9 Red Emergency Stop button 4 High idle select toggle switch 10 Key switch for platform/off/ground control selection 5 Gasoline/LPG models: Fuel select switch Diesel models: Glow plug switch (option) Genie GS-3384 Part No. 82206...
  • Page 13 19 not used speed operation for inclines 13 Thumb rocker switch for steer 20 LPG operation button with 7 Generator select switch with function indicator light (Gasoline/LPG indicator light models) 14 Error indicator light Part No. 82206 Genie GS-3384...
  • Page 14 7 Outrigger and operation button 12 Function enable 18 Function enable/high machine on incline with indicator light switch speed select button button with indicator (Gasoline/LPG for up/down function light: Low speed models) operation for inclines Genie GS-3384 Part No. 82206...

  • Page 15: Pre-Operation Inspection

    Scheduled maintenance inspections shall be performed by qualified service technicians, according to the manufacturer's specifications and the requirements listed in the responsibilities manual. Part No. 82206 Genie GS-3384...
  • Page 16 Electrical components, wiring and electrical cables Hydraulic hoses, fittings, cylinders and manifolds Fuel and hydraulic tanks Drive motors Wear pads Tires and wheels Engine and related components Limit switches, alarms and horn Nuts, bolts and other fasteners Genie GS-3384 Part No. 82206...

  • Page 17: Maintenance

    Indicates that a cold engine is required -10° to 90°F / -23° to 32°C 10W-40 before performing this procedure. above -4°F / -20°C 15W-30 Engine oil should have properties of API classification CC/SE or CC/SF grades. Units ship with 10-40 CC/SG. Part No. 82206 Genie GS-3384...
  • Page 18 4 Remove the battery vent caps. 5 Check the battery acid level. If needed, replenish with distilled water to the bottom of the battery fill tube. Do not overfill. 6 Install the vent caps. Genie GS-3384 Part No. 82206...
  • Page 19 Result: The fluid level should be visible in the top of the radiator. Bodily injury hazard. Fluids in the radiator are under pressure and extremely hot. Use caution when removing cap and adding fluids. Part No. 82206 Genie GS-3384...

  • Page 20: Function Tests

    3 Turn the key switch to ground control. 4 Observe the diagnostic LED readout. Result: LED should look like the picture at right. 5 Start the engine. See Starting the Engine in the Operating Instructions section. Genie GS-3384 Part No. 82206...
  • Page 21 Result: The platform should lower. The descent alarm should sound while the platform is Result: The green power light should come on. lowering. Test the Horn 18 Push the horn button. Result: The horn should sound. Part No. 82206 Genie GS-3384...
  • Page 22 Emergency Stop button out to the on position. 27 Push and hold a function enable/speed select button. Activate the platform down function. Result: The platform should lower. The descent alarm will not sound. Genie GS-3384 Part No. 82206...
  • Page 23 Result: The drive function should not work in either direction. 43 Lower the platform and remove both pieces of wood. Part No. 82206 Genie GS-3384...

  • Page 24: Workplace Inspection

    It is the operator's responsibility to read and remember the workplace hazards, then watch for and avoid them while moving, setting up and operating the machine. Genie GS-3384 Part No. 82206...

  • Page 25: Operating Instructions

    Push in the red Emergency Stop button to the off position at the ground controls or the platform controls to stop all functions and turn the engine off. Repair any function that operates when either red Emergency Stop button is pushed in. Part No. 82206 Genie GS-3384...
  • Page 26 Emergency Stop buttons are pulled out to the Operation From Ground on position. 1 Turn the key switch to ground control. 2 Pull out both ground and platform red Emergency Stop buttons to the on position. 3 Start the engine. Genie GS-3384 Part No. 82206...
  • Page 27 2 Push the platform extension lock handle to extend the platform to the desired position. Do not stand on the platform extension while trying to extend it. 3 Lower the platform extension lock handle. Part No. 82206 Genie GS-3384...
  • Page 28 3 Activate the outrigger up/down toggle switch in the desired direction to level the machine. Positioning machine on a slope When setting the machine up on a slope, the steer- end outriggers must be lowered first. Genie GS-3384 Part No. 82206...
  • Page 29 If PFPE is required by job site or employer rules, the following shall apply: All PFPE must comply with applicable governmental regulations and must be inspected and used in accordance with the manufacturer’s instructions. Part No. 82206 Genie GS-3384...

  • Page 30: Decals

    Danger - General Safety Rules 72868 Label - Engine Tray Prop 43618 Label - Directional arrows 82210 Cosmetic - Genie GS-3384 43619 Label - Safety Arm 82211 Notice - Max Side Force, ANSI & CSA 43696 Danger - Electrocution Hazard...
  • Page 31 First Edition • Second Printing Operator's Manual DECALS Engine Side Ground Controls Side Shading indicates decal is hidden from view, i.e. under covers Part No. 82206 Genie GS-3384...

  • Page 32: Transport Instructions

    Use chains or straps of ample load capacity. Turn the key switch to the off position and remove the key before transporting. Inspect the entire machine for loose or unsecured items. Secure the fold-down rails before transporting. Genie GS-3384 Part No. 82206...

  • Page 33: Specifications

    (Machine weights vary with option configurations) Airborne noise emissions 80 dB Maximum sound level at normal operating workstations (A-weighted) Continuous improvement of our products is a Genie policy. Product specifications are subject to change without notice or obligation. Part No. 82206 Genie GS-3384...
  • Page 34 Genie North America Phone 425.881.1800 Toll Free USA and Canada 800.536.1800 425.883.3475 Genie Holland Genie Australia Pty Ltd. Phone + Phone + 31 70 51 78836 61 7 3375 1660 Fax + Fax + 31 70 51 13993 61 7 3375 1002...
