  • Page 1 Operator’s Manual Second Edition Fifth Printing with Maintenance Information Part No. 82660 CE Models...

  • Page 2: Table Of Contents

    Industries in the U.S.A. and many other countries. "GS" is a trademark of Genie Industries. These machines comply with ANSI/SIA 92.6- 1999. Printed on recycled paper Printed in U.S.A. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...

  • Page 3: Safety

    You read, understand and obey employer's safety rules and worksite regulations You read, understand and obey all applicable governmental regulations You are properly trained to safely operate the machine. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...

  • Page 4: Electrocution Hazards

    Do not operate the machine during lightning or storms. Do not use the machine as a ground for welding. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 5 Do not replace items critical to machine stability with items of different weight or specification. Do not drive the machine on or near uneven terrain, unstable surfaces or other hazardous conditions with the platform raised. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 6 Do not contact adjacent structures with the platform. Do not tie the platform to adjacent structures. Do not place loads outside the platform perimeter. Do not operate the machine with the chassis trays open. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 7 Do not use the machine as a ground for welding. the platform controls and platform decal plate for drive and steer functions. No stunt driving or horseplay while operating a machine. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 8 All compartments must Green—used to indicate operation remain closed and secured during operation. or maintenance information. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 9 The battery tray should remain open during the entire charging cycle. Do not contact the battery terminals or the cable clamps with tools that may cause sparks. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...

  • Page 10: Legend

    21 Platform guard rails 15 Brake release pump knob and 6 Platform extension release knob 7 Tilt alarm (under cover) 16 Entry ladder/transport tie-down 8 Transport tie-down 9 Steer tire Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...

  • Page 11: Controls

    3 Lift function select button with indicator light 9 Power light 4 Drive function select button with indicator light 10 Battery level indicator 5 Red Emergency Stop button 6 Function enable switch Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 12 Second Edition • Fifth Printing CONTROLS Ground Control Panel 7 amp breaker for electrical circuits Key switch for platform/off/ground selection Hour meter Platform up/down toggle switch Red Emergency Stop button Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...

  • Page 13: Pre-Operation Inspection

    Scheduled maintenance inspections shall be performed by qualified service technicians, according to the manufacturer's specifications and the requirements listed in the responsibilities manual. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 14 Nuts, bolts and other fasteners Platform entry chain or gate Beacon and alarms (if equipped) Brake release components Platform overload components Safety arm Pothole guards Platform extension Scissor pins and retaining fasteners Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...

  • Page 15: Maintenance

    Indicates that tools will be required to perform this procedure. Indicates that new parts will be required to perform this procedure. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 16 5 Check the battery acid level of each battery. If needed, replenish with distilled water to the bottom of the battery fill tube. Do not overfill. 6 Install the vent caps. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...

  • Page 17: Function Tests

    6 Push in the ground red Emergency Stop button to the off position. Result: No functions should operate. 7 Pull out the red Emergency Stop button to the on position. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 18 20 Slowly move the control handle in the direction indicated by the blue arrow. Result: The platform should raise. The pothole guards should deploy. 21 Release the control handle. Result: The platform should stop raising. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 19 26 Depress the thumb rocker switch in the direction identified by the yellow triangle on the control panel. Result: The steer wheels should turn in the direction that the yellow triangle points on the control panel. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 20 Result: The drive function should not work in either direction. 38 Lower the platform and remove both pieces of wood. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...

  • Page 21: Workplace Inspection

    It is the operator's responsibility to read and remember the workplace hazards, then watch for and avoid them while moving, setting up and operating the machine. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...

  • Page 22: Operating Instructions

    Push in the red Emergency Stop button to the off position at the ground controls or the platform controls to stop all functions. Repair any function that operates when either Emergency Stop button is pushed in. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 23 2.1 m from the ground. Be sure the area below the platform is clear of personnel and obstructions before continuing. To continue lowering, release the control handle, wait 5 seconds, then move the control handle again. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 24 4 Step on the platform extension release pedal and pull to retract the platform to the mid- position stop. Step again to fully retract the platform. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 25 7 The charger will indicate when the battery is fully charged. 8 Check the battery acid level when the charging cycle is complete. Replenish with distilled water to the bottom of the fill tube. Do not overfill. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...

  • Page 26: Decals

    Danger - Manual Force, 400 N 82487 Notice - Operating Instructions 133239 Label - Maximum Capacity, GS-1530 and GS-1532 82488 Notice - Error Indicator Light 133240 Label - Maximum Capacity, GS-1930 and GS-1932 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 27 Second Edition • Fifth Printing Operator's Manual DECALS Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...

  • Page 28: Transport And Lifting Instructions

    Towing the Genie GS-1530, the GS-1930, the GS-1532 and the GS-1932 is not recommended. If the machine must be towed, do not exceed 2 mph / 3.2 km/h. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 29 1 inch / 2.5 cm holes on the front of the machine and two holes in the ladder for lifting. Adjust the rigging to prevent damage to the machine and to keep the machine level. Y Axis X Axis Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 30 Inspect the entire machine for loose or unsecured items. Use chains or straps of ample load capacity. Use a minimum of 2 chains or straps. Adjust the rigging to prevent damage to the chains. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...

  • Page 31: Specifications

    >70 dB Maximum sound level at normal operating workstations (A-weighted) Continuous improvement of our products is a Genie policy. Product specifications are subject to change without notice or obligation. Part No. 82660 Genie GS-1530 and GS-1930 and GS-1532 and GS-1932...
  • Page 32 >70 dB Maximum sound level at normal operating workstations (A-weighted) Continuous improvement of our products is a Genie policy. Product specifications are subject to change without notice or obligation. Genie GS-1530 and GS-1930 and GS-1532 and GS-1932 Part No. 82660...
  • Page 33 Genie North America Phone 425.881.1800 Toll Free USA and Canada 800.536.1800 Fax 425.883.3475 Genie Australia Pty Ltd. Phone +61 7 3375 1660 Fax +61 7 3375 1002 Genie Scandinavia Genie China Phone +46 31 575100 Phone +86 21 53852570 Fax +46 31 579020...
