Digi-Wave 400 Series Contents Safety Warnings and Recycling Instructions ..............................3 System Overview ..........................................4 DLR 400 ALK Differences ........................................4 DLT 400 Controls and Connectors .................................... 5 DLR 400 RCH Controls and Connectors ................................5 General Operation ..........................................6 Before Programming the Digi-Wave™ System ..............................7 The Main Screen ..........................................9...
NOT dispose of batteries in the household trash. Please take the batteries to a retail or community collection point for recycling. Product Recycling: Please do NOT dispose of your Williams AV equipment in the household trash. Please take the equipment to an electronics recycling center or return the product to the factory for proper disposal.
Backwards Compatibility The Digi-Wave 400 Series is backward compatible with the 300 series with limited features. It is not backward compatible with any earlier transceivers or receivers (DLT 100, DLT 100 2.0, DLR 50, DLR 60, and DLR 60 2.0).
Digi-Wave 400 Series DLT 400 Controls and Connectors Headphone and Microphone Jack Charging LED Volume Adjust Up and Down Buttons Talk Button Power Button Menu/Select Internal Charging Contacts Microphone (For CHG 412) USB-C Charging Port DLR 400 RCH Controls and Connectors...
Digi-Wave 400 Series General Operation Button Functions Power Button · Press and hold for power On/Off · Press quickly to navigate back a step when using the menu. Volume Control Buttons (on side) · Adjust the headset’s volume. Talk Button ·...
Use the USB-C located on the bottom of DLT transceiver or the DLR 400 RCH Receiver, to charge the battery. Charge by either using a USB-C cable or using an approved, compatible Williams AV charging station. Full charging time is approximately 5 hours. The charging LED flashes red while charging. The charging LED will turn to a steady green light when the battery is charged.
Page 8
Digi-Wave 400 Series Hearing Assistance Hearing Assistance mode is appropriate when using the device to amplify spoken communication between users. The Tone Control in Hearing Assistance mode is automatically elevated, allowing the user to hear more clearly. Users with transceivers can be allowed to speak, which may be useful in a classroom setting.
• Each DLT transceiver must have its own address and the address cannot be duplicated within a group. • Each group must be assigned its own group number. Williams AV recommends a maximum of four groups using the system simultaneously within the same area to prevent interference.
Digi-Wave 400 Series To change any of these settings, hold down the menu button. For instructions on configuring the Digi-Wave system, see “Basic Settings” on page 11. Signal Strength Indicator When a Master 1 is available on the group or channel, the signal strength indicator on DLR Receivers and Guests will indicate how strong the signal is.
Digi-Wave 400 Series the Master 1 device, once a connection is established. If a group or channel is locked by a PIN, the device will prompt for the PIN at this time. The device will be unable to join the group or channel without this PIN.
Digi-Wave 400 Series Advanced Settings Advanced Settings are usually available regardless of the mode selected, but some Advanced Settings may be missing from certain modes, or with certain configurations. Number of Microphones (DLT 400 only) In modes where multiple speakers are available, the number of speakers at one time can be limited. The maximum number of speakers is 6, the minimum is 2 when this option is available.
Page 13
Digi-Wave 400 Series In-First-Out order continues each time a member pushes their Talk button who is not a part of the speaking group. Talk Mode: Push-to-Talk and Push-n-Latch (DLT Master 2 and Guest Only) On a DLT transceiver, the Master 2 or Guest Talk Mode can be changed to Push and Latch or Push to Talk.
Page 14
Digi-Wave 400 Series Sleep Mode “No sleep mode” is default. This setting means that the DLT 400 or DLR 400 RCH display will always stay on. There are three options for sleep – after 30 seconds, 1 minute or 5 minutes. If one of those options are chosen, then the display or the DLT 400 or DLR 400 RCH unit will turn blank after the prescribed time.
Digi-Wave 400 Series 1. Go through the menu system until you are prompted if you would like to use a PIN code. 2. Select “NO PIN CODE.” The existing PIN will be removed. Allow Join Group The Master 1 can prevent other devices from seeing the group as available to join. Disabling Join Group will prevent available groups from being listed under the Join Group menu.
Digi-Wave 400 Series Repeater Broadcast Mode Repeater mode can be entered by selecting it as the Broadcast Type during setup. An additional DLT 400 can be set-up as a repeater to increase the range of each channel. When repeater mode is used, the Repeater is configured as the Master 1, and all units sync to this Master Repeater.
Page 17
Digi-Wave 400 Series This mode eliminates the need for the interpreter to physically switch between 2 DLT transceivers programmed to fixed channels. The interpreter can easily switch between which channel is being broadcast by using the up or down arrow under each channel listed.
Digi-Wave 400 Series Relay Mode Relay Mode allows the interpreter to quickly switch Presenter between listening to the Floor on Channel 0 or the (Floor) Relay on Channel 1. Ch 0 Japanese For example, the floor is speaking Japanese. The...
Court Mode is only available for DLT 400 transceivers and DLR 400 RCH receivers. It is not available for DLR 400 ALK units or for backwards compatibility with the Digi-Wave 300 Series. For older Digi-Wave 400 series units, a firmware update may be required to use Court Mode. Group Selection A Master unit can only be in one group and cannot toggle between groups.
Digi-Wave 400 Series Saving and Replacing Profiles After settings have been configured, you will have the option to save your settings as a profile, or replace an existing profile. This is only available if Advanced Settings have been adjusted. If you choose to not save your profile, the device will still use the settings but they cannot be loaded again if the settings are later changed.
To check if your DLT is the AIM variant, check if the word “AIM” is present under the battery symbol on the display. Contact your local Williams AV representative regarding possible upgrade paths to the DLT 400- AIM variant.
Page 22
Digi-Wave 400 Series Scenarios for Q&A Mode 1. Scenario 1: Presentation with Interpreted Audience Questions The interpreter listens to CH01 and CH02 consecutively and can speak to the presenter on CH01 and interpret what they hear to the audience on CH02 or the interpreter is listening...
Page 23
Digi-Wave 400 Series Simultaneous listening The interpreter will listen to the audio feed from both CH01 and CH02 simultaneously. The interpreter will toggle their output between CH01 and CH02 depending on which language they are currently interpreting in. Switching channels To switch channels, the Interpreter hits the up or down arrow;...
Page 24
Digi-Wave 400 Series 3. MASTER/GUEST: Master 1. This selection is usually recommended for the interpreter. Every Q&A system requires exactly one Master 1. Master 2 is optional. 4. GROUP #: Choose a group number. All DLTs and DLRs in the Q&A system need to be connected to the same group.
Page 25
Digi-Wave 400 Series 3. MASTER/GUEST: MASTER 2. This selection is usually recommended for the presenter. Master 2 is optional, but it enables the presenter to always have their TALK button on without risking being bumped off if there are too many open mics in the system.
Page 26
Digi-Wave 400 Series • This selection is usually recommended for audience Q&A DLT. Depending on the event, you may choose to designate a DLT for audience questions as MASTER 2. If the audience question DLT is programmed as Master 2, it enables this DLT to always have their TALK button on when desired without risking being bumped off if there are too many open mics in the system.
Page 27
Digi-Wave 400 Series programming language. (Reminder the power button can be used as a back function for mistakes.) 2. SET UP: JOIN GROUP 3. Mode: Select Q&A INTP 4. SELECT GROUP: Choose the same group number as the interpreter. 5. The DLR will be on channel 01.
Page 28
Digi-Wave 400 Series You may assign a presenter DLT to channel 01 and another presenter DLT to channel 02 and give presenters in different languages different DLT units. The DLTs may easily be identified by different color silicon skins (optional accessory CCS 061 BK, GR, RD or BL). In a similar manner, you may have two different DLTs for questions from the audience.
Page 29
Digi-Wave 400 Series 4. GROUP #: Choose a group number. All DLTs and DLRs in the Q&A system need to be connected to the same group. 5. BROADCAST TYPE: INTERPRETER 6. CLOCK MODE: As desired (12 HOUR or 24 HOUR) 7.
Page 30
Digi-Wave 400 Series 5. BROADCAST TYPE: PARTICIPANT. 6. CHANNEL SELECTION. Choose Channel 01 for the delegation 1 language or Channel 02 for delegation 2 language. 7. CLOCK MODE: As desired (12 HOUR or 24 HOUR) 8. ADVANCED SETTINGS: In most cases, there is no need to go into advanced settings. If you choose NO, then the programming is done.
Page 31
Digi-Wave 400 Series 4. Channel: The DLR will be on channel 01. Participant can choose to listen to delegation 1 or delegation 2 language. Use the arrow up button to go to CH 02 if desired. Scenario 3: Bilingual Two-Way Tour Q&A Mode can be utilized in bilingual two-way tours to enable all participants to freely ask questions in their...
Page 32
Digi-Wave 400 Series 3. MASTER/GUEST: Master 1. This selection is usually recommended for the interpreter. Every Q&A system requires exactly one Master 1. Master 2 is optional. 4. GROUP #: Choose a group number. All DLTs and DLRs in the Q&A system need to be connected to the same group.
Page 33
Digi-Wave 400 Series • We recommend programming the Tour Leader Tour as Master 2. Master 2 is optional, but it enables the tour leader to always have their TALK button on without risking being bumped off if there are too many open mics in the system.
Page 34
Digi-Wave 400 Series 3. MASTER/GUEST: GUEST or MASTER 2. • When to choose: Master 2 or Guest: Choose Master 2 if VIP guest who may need to control the mic, Choose Guest for participants in general. • Typically, Tour Participant DLTs would be programmed as GUEST units. However, VIP participant DLTs may be programmed as Master 2.
Page 35
Digi-Wave 400 Series programming language, then select new settings. (Reminder the power button can be used as a back function for mistakes.) 2. MODE: Q&A INTP 3. MASTER/GUEST: GUEST or MASTER 2. • Typically, Tour Participants would be programmed as GUEST units. However, VIP participant DLTs may be programmed as Master 2.
Digi-Wave 400 Series 7. CLOCK MODE: As desired (12 HOUR or 24 HOUR) 8. ADVANCED SETTINGS: In most cases, there is no need to go into advanced settings. If you choose NO, then the programming is done. For more information on Advanced Settings, reference page 12 of the User Manual for more information.
Page 37
Digi-Wave 400 Series Devices required for 24-channel mode 1. 1 x DLT 400-AIM for Interpreter: Broadcast Type: Interpreter – Master Channel 01 2. 1 or more x DLT 400-AIM for Interpreters languages 02-24: Broadcast Type: Interpreter – Master – Channel 02-24 3.
Page 38
Digi-Wave 400 Series 5. BROADCAST TYPE: INTERPRETER. Repeater units can be added to add range. Max. 1 repeater unit per channel is allowed. 6. CHANNEL: 01. Choose channel 01 for the first channel. Additional interpreter DLTs will be on channels 02- 7.
Digi-Wave 400 Series Control Function A DLT 400-AIM device can be programmed is a CONTROL unit. This enables channel naming and sub-groups to be set up offline. The control function makes it possible to make changes to a Digi-Wave® system without interrupting an ongoing event.
Page 40
Digi-Wave 400 Series 3. Make sure you choose the same mode as the MASTER unit of the Digi-Wave® system. If the modes aren’t the same, then the Control unit will not be able to synchronize with the Master unit. 4. MASTER/GUEST?: CONTROL.
Digi-Wave 400 Series If you choose ISO CODE, Then, the next screen is: CH01 REGION: WORLD, EUR/AM, INDIA/SA. Choose region and then 3-letter language code for desired language. If you choose CUSTOM, • Then the next screen is LETTER 1-5: Choose between the letters in the English Alphabet, blank and 0-9.
Page 42
Digi-Wave 400 Series separate spaces. You can also utilize sub-groups to limit the number of channels visible on the receivers. For example, if only channels 01-16 are active in 24-channel mode, then you could set up a subgroup for channels 01-16 and program the DLRs to be in that subgroup for the receivers to avoid seeing non-active channels.
Page 43
Digi-Wave 400 Series • CH 01-CH24 for INTP24. You must choose a higher number for the last channel than the first channel. 7. SUBGROUP 2 - 1ST CHANNEL: CH 00-CH 14 for standard interpretation, CH 01-CH24 for INTP24. You must program at least two subgroups in order to use the sub-group feature.
Page 44
Digi-Wave 400 Series Programming DLR (Listen Only) units for Sub-Groups 1. Enter programming mode by holding the menu/select button for three seconds, choose your programming language, then select new settings. 2. MODE: INTERPRET, INTP24 or Q&A INTP. 3. GROUP #: Choose the same group number as the MASTER unit.
LEAD 1 03 17 Compatibility • DLR 400 RCH units on firmware version 1.4.1 or higher are compatible. Contact your Williams AV representative to upgrade your firmware. • DLR 400 ALK units are not compatible with the special ACM features.
Digi-Wave 400 Series Advanced Comms Mode Advanced Comms mode facilitates efficient and flexible communication between a Leader and several teams. In the Advanced Comms mode, a Leader (LEAD 1 communication role and optionally, the LEAD 2 role) can quickly and seamlessly switch between up to 4 teams (sub-groups). The sub-groups can be named using a standard list of commonly used team functions or with a custom name of up to six characters.
Page 47
Digi-Wave 400 Series Operating an Advanced Comms System Switching subgroups To switch subgroups, LEAD 1 or (or LEAD2 as applicable) can hit the up or down arrows to switch into each subgroup and participate in that discussion. All subgroups (up to 4) are available to the LEAD 1 communication roles.
Page 48
Digi-Wave 400 Series 1. Hold down the talk button to activate All-Call. The DLT 400-ACM-ACM units in the same group as the activated DLT 400-ACM will now be muted. 2. The DLT 400-ACM and DLR 400 units in the same group will display the word ALL and the DLT 400-ACM ACM units talk buttons will be flashing.
Page 49
Digi-Wave 400 Series LEAD 1 SUBGROUP 1 SUBGROUP 2 SUBGROUP 3 SUBGROUP 4 LEAD 2 LEAD 2 GUEST GUEST GUEST GUEST GUEST GUEST GUEST GUEST GUEST DLR 400 RCH Listen Only Receivers Most commonly, an Advanced Comms system will consist of only transceiver units. However, it could be appropriate and helpful in certain circumstances to include DLR 400 RCH listen only receivers.
Page 50
Digi-Wave 400 Series Sync Role: MAIN SYNC Exactly 1 DLT 400-ACM must be designated as MAIN SYNC. The system synchronizes to this unit, so it determines the coverage range. Most aspects of the system set-up are programmed on the MAIN SYNC unit (or an optional CONTROL unit) with other units in the system acting according to permissions set-up in the MAIN SYNC.
Page 51
Digi-Wave 400 Series Programming Instructions Scenario 1: The Leader or a Team Member is MAIN SYNC MAIN SYNC GUEST SUBGROUP 1 SUBGROUP 2 SUBGROUP 3 SUBGROUP 4 STAGE AUDIO CAMERA LIGHTS GUEST LEAD 2 LEAD 2 LEAD 2 GUEST GUEST...
Page 52
Digi-Wave 400 Series A. MAIN SYNC DLT Programming MAIN SYNC Programming determines the set-up for the entire system. As such, it is much more detailed than programming the other units in a system. 1. Enter programming mode by holding the menu/select button for three seconds, choose your programming language, then select new settings.
Page 53
Digi-Wave 400 Series 3. Initiate all-call: LEAD 1 only is the default setting. It is possible to allow all LEAD 2 units to initiate all-call. It s not possible to allow GUEST units to initiate all-call. INITIATE ALL-CALL LEAD 1 ONLY LEAD 1 AND LEAD 2 3.
Digi-Wave 400 Series Subgroup Naming The subgroup name can be chosen from a list of common teams, or you can create a custom 6-character name (letters, numbers, blank). Subgroup naming is done on the DLT programmed as MAIN SYNC (or an optional Control unit).
Page 55
Digi-Wave 400 Series 3. At the end of the custom naming process, the created name will be shown (in this example “TEAM 1”) and there is a choice to accept this or not. If YES is pushed, then you will be taken to the next step in the process.
Page 56
Digi-Wave 400 Series D. Programming Optional DLR 400 RCH Units The following steps are for DLRs to be used as listen only units for those who do not need to communicate with the group. Only DLR 400 RCH (not DLR 400 ALK) units can be used in Advanced Comms mode.
Page 57
Digi-Wave 400 Series Programming of Scenario 2: MAIN SYNC is mounted in a Fixed location In many situations, having the MAIN SYNC in a fixed location provides the best coverage possible for your system. We recommend using a Digi-Wave Connect DWD 401 with the fixed DLT 400-ACM to supply it with constant power and to provide flexible mounting options.
Page 58
Digi-Wave 400 Series A. Programming a Control Unit A DLT 400-ACM device can be programmed is a CONTROL unit. This enables all settings to be set up offline. The control function makes it possible to make changes to a Digi-Wave® system without physically accessing a MAIN SYNC unit and without interrupting an ongoing event.
Digi-Wave 400 Series Troubleshooting Problem Cause What to Do Power does not turn-on Dead battery Charge the battery, replace battery Power turned off Master device can’t be found Turn on Master unit automatically Press reset button on the back of device (DLT Power doesn’t turn off...
Digi-Wave 400 Series Specifications - DLT 400, DLT 400-AIM, & DLT 400-ACM Transceiver Dimensions 2.60”W x 4.22”H x 0.50”D (66 mm x 107.3 mm x 12.6 mm) Weight 3.3 oz (94 g) including battery Color Black/Silver (Front/Back) Case Material Black ABS plastic Battery type Lithium Polymer with smart charge built into transceiver;...
Digi-Wave 400 Series Specifications - DLR 400 RCH Receiver Dimensions 2.60”W x 4.22”H x 0.50”D (66 mm x 107.3 mm x 12.6 mm) Weight 3.3 oz (94 g) including battery Color Black Battery type Lithium Polymer with smart charge built into transceiver; 1800 mAH...
Digi-Wave 400 Series Specifications - DLR 400 ALK Receiver Dimensions: 2.36” W x 3.54” H x 0.63” D (60 mm x 90 mm x 16 mm) Weight: 1.7 oz. (47 g) without batteries. Frequency Band: 2.4 GHz (ISM band) Modulation:...
Regulatory Statements FCC ID: CNMDLT400 FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 64
European Union Hereby, Williams AV declares that the transciever is in compliance with Directive 2014/53/EU and other Union harmonization as applicable. The full text of the EU declaration of conformity is available by contacting Williams AV at the following email address: regulatory@williamsav.com...
Williams AV shall not be liable to any person or entity for any medical expenses or any direct, incidental or consequential damages caused by any use, defect, failure or malfunctioning of the product, whether a claim for such damages is based upon warranty, contract, tort or otherwise.
