If replacing any parts, use only genuine replacement parts purchased from WEN Products. Use of replacement
parts not sold by WEN Products will void your warranty and could lead to decreased performance or injury.
TOOLS NEEDED
•
Phillips-head screwdriver
•
Flat-head screwdriver
•
10mm socket or wrench
•
Gasoline storage container
ENSURE THAT THE ENGINE IS COOL BEFORE BEGINNING ANY MAINTENANCE OR REPAIR WORK. FOLLOW
ALL SAFETY PROCEDURES LISTED IN YOUR OWNER'S MANUAL. USE COMMON SENSE. AVOID INJURY.
NOTICE: WEN PRODUCTS AND GREAT LAKES TECHNOLOGIES, LLC ALWAYS RECOMMEND THAT THE
HIGH-ALTITUDE KIT FOR YOUR GENERATOR BE INSTALLED BY A QUALIFIED MECHANIC. REFER TO THE
OWNER'S MANUAL INCLUDED WITH YOUR GENERATOR FOR MORE INFORMATION. WEN PRODUCTS
AND GREAT LAKES TECHNOLOGIES, LLC SHALL NOT BE HELD LIABLE FOR ANY GENERATOR DAMAGE
OR DECREASE IN PERFORMANCE, OR INJURY TO ANY PERSON, ARISING OUT OF ANY SITUATION IN
WHICH A HIGH-ALTITUDE KIT IS NOT INSTALLED BY QUALIFIED PERSONNEL. CALL 1-847-429-9263 M – F,
8 – 5 CST FOR MORE INFORMATION. FOLLOW ALL APPLICABLE SAFETY PRECAUTIONS.
REMOVING THE OLD JET
1. Shut off the generator and allow it to cool to ambient temperature before proceeding. Turn off the fuel valve to
stop the flow of fuel from the gas tank. Refer to the instructions in your manual. Make sure the 4-in-1 knob is
turned to the "OFF" position.
2. Disconnect the battery quick-connectors as instructed in your owner's manual.
3. Remove the side panel as instructed in the Maintenance section of your manual (Figs. 1 & 2).
This is a guide to replacing the carburetor jet or installing a high altitude kit
WEN 56477i or 56480iX Inverter Generator. This guide is best used in conjunction with the
56477i or 56480iX manual, included as a physical copy with your unit and available on the
WEN website page for each model (56477i link here, 56480iX link here), by clicking "Click
here to view the product manual".
If at any point you need assistance, have questions, or want to order parts, call WEN customer
service at 1-847-429-9263, M-F, 8-5 Central Time, or email techsupport@wenproducts.com.
Tools needed
Removing the old jet
Installing the new jet
TABLE OF CONTENTS
•
Latex or chemical-resistant gloves
•
Paper towels or shop towels
•
Needle-nose pliers (optional)
•
Magnetic pickup tool (optional)
1
1
6
Date last modified: 2023/06/21
for
your
Advertisement
Related Manuals for Wen 56477i
Summary of Contents for Wen 56477i
- Page 1 1-847-429-9263, M-F, 8-5 Central Time, or email techsupport@wenproducts.com. If replacing any parts, use only genuine replacement parts purchased from WEN Products. Use of replacement parts not sold by WEN Products will void your warranty and could lead to decreased performance or injury. TABLE OF CONTENTS...
- Page 2 Fig. 1: Remove the screws, then the panel. Fig. 2: Panel has been removed. 4. Optional – if desired, you can remove the recoil starter cover for additional room to work. Remove the two Phillips-head screws shown in Fig. 3 below, then gently pull the panel out (you may have to gently pull the recoil starter handle out) and set it down.
- Page 3 5. Prepare an approved gasoline-storage container. Drain the carburetor as instructed in the Maintenance section of your manual, using a Phillips-head screwdriver to loosen the drain screw (Fig. 4). Fig. 4: Carburetor drain screw. 6. Remove the air filter cover and air filter element as instructed in your owner’s manual (Figs. 5 & 6). Fig.
- Page 4 Fig. 7: Intake cover mounting bolts (2). Fig. 6: Air filter element removed. 7. Use a Phillips-head screwdriver to remove the 5 mounting screws shown in Fig. 6 and a 10mm socket to remove the 2 mounting bolts shown in Fig. 7. Then pull the air filter housing and intake cover outwards. 8.
- Page 5 9. Pull the carburetor outwards to access the carburetor bowl bolt. Prepare gloves and a paper towel. When you remove the carburetor bowl bolt, a small amount of gasoline will likely come out of the bowl. 10. Remove the carburetor bowl bolt, bolt gasket, bowl gasket, and bowl from the bottom of the carburetor using a 10mm socket.
-
Page 6: Questions? Problems
Fig. 12: Make sure tabs line up with slots when reassembling. 15. Verify that all fasteners are tight and all components have been replaced. Test the generator to ensure it operates properly. QUESTIONS? PROBLEMS? Contact WEN Customer Service at 1-847-429-9263, M-F, 8-5 CST, or email techsupport@wenproducts.com Date last modified: 2023/06/21...
