- Page 1 Face Recognition Reader & Controller User’s Manual R71CF-311 R71CF-312 2024/05/16...
-
Page 2: Regulatory Information
2. This device must accept any interference received, including interference that may cause undesired operation. Now that the camera and the PC are both having their unique IP addresses and are under the same network segment, it is possible to use the Web browser of the PC to access the camera. www.acti.com... - Page 3 L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. www.acti.com...
-
Page 4: Safety Information
Dispose of used batteries according to the instructions • If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the device yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) www.acti.com... - Page 5 Indoor use. The device should be at least 2 meters away from the light, and at least 3 meters away from the window. • Outdoor use or use in environment exceeding the device temperature measurement will affect the temperature measurement accuracy. www.acti.com...
-
Page 6: Table Of Contents
Menu Settings ............17 Menu Page .................... 17 Menu Tree ..................... 17 Department Management ..............18 User ......................19 Manage User ..................19 Add Face Picture .................. 21 Add Card ....................21 Authentication Settings................. 22 Local T & A ..................... 23 www.acti.com... - Page 7 Attendance Report ................23 Platform Attendance ................23 System Settings ..................25 Communication Settings ............... 26 Biometric Parameters................27 Data ....................... 28 Maintenance ..................29 Tips in Picture Taking ..........30 Positions When Taking or Authenticating Face ........31 www.acti.com...
-
Page 8: Introduction
USER’S MANUAL Introduction Package Content Reader & Controller Wall Mount Base Bracket Power Adapter QIG & Wire Cable Screw Pack Mounting Screws Warranty Card Warranty Card www.acti.com... -
Page 9: Physical Description
USER’S MANUAL Physical Description Item Item Cameras Speaker IR Lights USB Port Touch Screen Tamper Key Card Sensor Cable Connector Debugging Port Lock Screw Hole (for service only) Ethernet Port www.acti.com... -
Page 10: Wiring
RS-485 Wiring Black Ground Green Wiegand Wiring 0 Wiegand White Wiegand Wiring 1 Black Ground White/Purple Lock Wiring (NC) White/Yellow Common White/Red Lock Wiring (NO) Door Lock Yellow/Green SEN (Sensor) Door Contact Black Ground Yellow/Gray BTN (Button) Exit Door Wiring www.acti.com... -
Page 11: Installation
Make sure the wall can bear three (3) times the weight of the device. • For accurate face recognition, the recognition distance should be greater than 30 cm. Wall Mounting 1. Mount a one-gang gang box inside the wall. NOTE: Gang box is not supplied; purchase separately. www.acti.com... - Page 12 4. Connect the cables to the device. 5. Align the device with the mounting plate to hang it, then push it down to lock the device in place. 6. Then attach the bundled lock screw on the bottom hole to secure the device. www.acti.com...
-
Page 13: Base Mounting
1. Align the base bracket on the back of the device. 2. Press the bracket with both hands on the bracket, then push up to lock the bracket to the device. 3. Route the cables through the bracket hole and connect them as nedeed. www.acti.com... -
Page 14: Initial Setup
Upload Pic. When Auth.: This function uploads the pictures captured when authetication to the platform automatically. • Save Pic. When Auth.: This function saves the pictures when authenticating to the device. • Save Registerd Pic.: The registered face picture will be saved to the system. www.acti.com... - Page 15 10. You can configure the face recognition or card access or both. Once either face or card has been configured, the system will go back to Add an Administrator first page. Repeat step 9 to add another access type or when all access has been configured, tap OK to complete setup. www.acti.com...
-
Page 16: Main Screen
1. Long tap the screen for 3 seconds and slide your finger left / right. 2. Authenticate the administrator’s face or swipe the card to enter the Main Menu page. 3. Once logged in, the Main Menu page appears. www.acti.com... -
Page 17: Menu Settings
Attendance Report Shows the attendance reports like total attendance, attendance record, summary, abnormal attendance, etc. A USB flash drive with the data must be connected to the device to display these reports on the device. www.acti.com... -
Page 18: Department Management
Instead, contact your sales agents or the customer help desk for assistance. Department Management This menu has preset departments where employees can be assigned to. Tap a submenu to access its contents and modify as needed. To create a new department, tap www.acti.com... -
Page 19: User
Authentication Settings: Select “Device Mode” to set the device as access control. Or, “Custom” to combine different authentication modes together according to your actual need. • Person Type: Select “Administrator” to set the employee as administrator or “Basic Person” as a general user. to complete add user. www.acti.com... - Page 20 2. Tap a username on the screen to enter the Personal Details page. 3. Tap to delete the user. 4. Tap OK to confirm. Search User 1. On the main menu page, tap User. 2. Type the name of the user on the search bar, then click www.acti.com...
-
Page 21: Add Face Picture
Tap Card, and then tap Configure the card number: you can enter the card number manually or hover the card towards the device to get the card number. NOTE: The card number cannot be empty and it cannot be duplicated. www.acti.com... -
Page 22: Authentication Settings
Available door locked time range: 1 to 255 seconds. • Authentication Interval: Set the device authentication interval. Available interval range: 0 to 65535 seconds. 3. Tap a menu item and then edit the items. www.acti.com... -
Page 23: Local T & A
The Platform Attendance menu allows you to set the attendance mode as check in, check out, break in, break out, overtime in and overtime out according to your actual situation. NOTE: Local Time & Attendance will be disabled when using Platform Attendance. www.acti.com... - Page 24 Manual and Auto: The system will automatically change the attendance status according to the configured schedule and at the same time, you can manually change the status after the authentication. 3. Enable and disable the Check in/out, Break in/out, Overtime in/out, as needed. www.acti.com...
-
Page 25: System Settings
You can customize face parameters to improve the face recognition performance. See Biometric Parameters on page Preference Allows you to select the screen theme and enable or disable shortcut keys. Password Allows you to modify the device password set during initial setup. www.acti.com... -
Page 26: Communication Settings
1. On System Settings page, tap Comm. > Wiegand. 2. Enable Wiegand. 3. Select a transmission direction: “Output”, the device can connect to an external access controller. 4. Select how the two devices will transmit the card no.: via Wiegand 26 or Wiegand 34. www.acti.com... -
Page 27: Biometric Parameters
Face with Mask & Face (1:1 ECO): Set the matching value when authenticating with face mask via ECO mode 1:1 matching mode. The larger the value, the smaller the false accept rate and www.acti.com... -
Page 28: Data
Data The Data menu allows you to import, export and delete user data on the device. For importing and exporting data, an external USB flash drive is required. On the main menu page, tap to access the Data page. www.acti.com... -
Page 29: Maintenance
USER’S MANUAL Maintenance The Maintenance menu allows you to view the system information, device capacity, reset or restore factory default settings and reboot device. On the main menu page, tap to access the Maintenance page. www.acti.com... -
Page 30: Tips In Picture Taking
• Keep expression natural. Expression • Do not wear hat, sunglasses and other accessories. • Do not allow hair to cover your eyes, ears, etc. • Do not use heavy makeup. Posture Face should be facing the camera. Size www.acti.com... -
Page 31: Positions When Taking Or Authenticating Face
USER’S MANUAL Positions When Taking or Authenticating Face www.acti.com... - Page 32 Copyright © 2021, ACTi Corporation All Rights Reserved 7F, No. 1, Alley 20, Lane 407, Sec. 2, Ti-Ding Blvd., Neihu District, Taipei, Taiwan 114, R.O.C. TEL : +886-2-2656-2588 FAX : +886-2-2656-2599 Email: sales@acti.com...
