CONFIGURATION EXAMPLE FOR THE WINDOWS-TERMINAL PROGRAM
In the menu "settings" following data have to be programmed under TERMINAL-SETTINGS and DATA
TRANSMISSION. This data have, of course, to suit to that of the W 4010.
Data transmission
Terminal emulation
Terminal settings
The configuration of the serial RS-232 interface and the presetting of the unit`s address can be effected at
the configuration menu.
The software of the W 4010 does not answer with an echo sign to the host. When operating with the termi-
nal program (on a PC) the terminal should be configured at
After the receipt of the string "PORTxx=ON<CR>" the W 4010 switched to mode REMOTE. The expres-
sion "xx" stands for the unit's address from "0" to "15".
All the keys are in function further on. The W 4010 registrates all manual inputs.
After the receipt of the string "PORTxx=OFF<CR>" the W 4010 does not answer any more. The software
only answers to commands after the receipt of the command PORTxx=ON. So it is possible to use several
units at the same RS-232 interface or to use the PC-interface itself for several times.
Each command string from the PC to the W 4010 has to be acknowledged by 'Carriage Return'. The 'Car-
riage Return' is shown as <CR> in the above example. The W 4010 works the sign string down, executes
the necessary actions and answers with a ">" at the PC (the apostrophes do not get transmitted).
If the command is not defined or there is an error in it, the W 4010 transmits the sign '?>'. The software
works with capital and/or short letter.
By adding a question-mark at the end of a command the PC can ask all settings from the W 4010. The W
4010 transmits the corresponding setting to the PC after the questioning, respectively finished by <CR> and
the last sign '>'.
As an answer to a still not defined settings question the software answers with the message "UNDEF<CR>".
The command "DATA" steers the output of the received teletype data from the decoder over the remote in-
terface to the PC.
At the command "DATA" following has to be noticed:
after transmission of the command "PORTxx=OFF", also the output of the data stops.
when switching between "PORTxx=OFF" to "PORTxx=ON" the output of the data continues, if
"DATA=ON" Has been set before.
Connection to COM 1
Transmission rate to 9600 Baud
Databits to 7
Stoppbits to 1
Parity none
Hardware record or no record
TTY (common)
Terminal-Modi X
X local echo
CR ---> CR/LF X
column to 80
PC transmits <––––––––––––––––> W 4010 answers
–––––––––––––––––––––––––––––––––––––––––––
"MODE = ARQ-E <CR>"
"MODE? <CR>"
- Page 9 -
line formatting
Receipt and transmission
AUTO—ECHO
.
" > "
"ARQ-E <CR>"
