Wavecom W 4010 User Manual page 8

The operation of the decoder via the keys is also possible during the remote operation. The software regis-
trates the manual settings. The changed parameters can be asked via the interface and be evaluated by the
PC.
But the user can also write his own software or even can steer the W 4010 from the WINDOWS terminal
program.
The configuration of the serial W 4010 Remote Control-interface always has to suit to the settings of the PC.
To that belong the baud rate, number of data- and stoppbit and the parity. The configuration of the W 4010
interface happens in a special mode via the keys at the front panel. The data are kept in a nonfluent memo-
ry (EEPROM) and even stay after a power lack.
The configuration menu becomes activated by pressing the key MODUL when the W 4010 is being switched
on. The setting possibilities are shown self-explaining on the monitor. To leave this mode, the decoder is
simply switched off.
Additionally to the known teletype modes, the W 4010 knows the switching to the new mode JV-FAX. The
data links will, like specified by JV-FAX, be switched to the W 4010 demodulator. With this, the W 4010 can
be used as a demodulator for black-white faxpictures. The command JV-FAX must only be given in DOS, due
to the switching of the data lines.
The communication between PC and the W 4010 occurs by a firm set of commands and answers. The con-
tent of all commands will be transmitted in ASCII.
CONFIGURATION OF THE REMOTE CONTROL INTERFACE
To enter the configuration menu, the MODUL key has to be pressed while switching the W 4010 on.
Key [F1] Baud rate
Key [F2] Length/Stoppbit
Key [F3] Parity
Key [F4] Stationaddress
Key [BU-ZI] Store Parameters
To leave this menu, switch the W 4010 off.
150 Baud
300 Baud
600 Baud
1200 Baud
2400 Baud
4800 Baud
9600 Baud
19200 Baud
7/1 7 Databits, 1 Stoppbit
7/2 7 Databits, 2 Stoppbits
8/1 8 Databits, 1 Stoppbit
8/2 8 Databits, 2 Stoppbits
none
even
odd
0 - 15
Storage of the configuration
- Page 8 -
no parity
Even parity
Odd parity
