TOSHIBA Thermal Printer
B-SA4T SERIES
Option Installation Manual
Document No. EO15-33001
Original
Jul., 2005
(Revised
)
PRINTED IN JAPAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B-SA4T Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Toshiba B-SA4T Series

Summary of Contents for Toshiba B-SA4T Series

  • Page 1 TOSHIBA Thermal Printer B-SA4T SERIES Option Installation Manual Document No. EO15-33001 Original Jul., 2005 (Revised PRINTED IN JAPAN...
  • Page 2 Wireless LAN Module: B-SA704-WLAN-QM ------------------------------------------------------------- 3- 1 Serial Interface Board: B-SA704-RS-QM-R -------------------------------------------------------------- 4- 1 CAUTION! 1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA TEC. 2. The contents of this manual may be changed without notification.

  • Page 3: Cutter Module: B-Sa204-Qm/B-Sa204-Qm-R

    INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 1. Cutter Module: B-SA204-QM-R INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT WARNING! 1. Turn the printer power off and disconnect the power cord before installing an optional equipment. 2. Be careful not to pinch your fingers or hands with the covers. 3.
  • Page 4 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 1. Cutter Module: B-SA204-QM-R 2. Open the Front Cover wider. Remove the Front Cover by lifting it to disengage the hinge pins from the hinge. The Front Cover cannot be removed unless it is opened at an angle of over 100 degrees as the stoppers of the hinge prevent disengagement.
  • Page 5 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 1. Cutter Module: B-SA204-QM-R Connect the Cutter Harness to the connector at the front of the printer. Screw Connector Screw Cutter Harness Close the Cutter Unit and secure it to the printer with the Set Screw. Set Screw Cutter Unit 7.

  • Page 6: Strip Module: B-Sa904-H-Qm-R

    INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 2. Strip Module: B-SA904-H-QM-R 2. Strip Module: B-SA904-H-QM-R Packing List The following parts are supplied with the kit. Make sure you have all items shown below. Strip Unit (1 pc.) Strip Module Cover (1 pc.) SMW-3x6 Screw (4 pc.) Ground Wire (1 pc.) Installation Manual (1 copy)
  • Page 7 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 2. Strip Module: B-SA904-H-QM-R 2. Open the Front Cover wider. Remove the Front Cover by lifting it to disengage the hinge pins from the hinge. The Front Cover cannot be removed unless it is opened at an angle of over 100 degrees as the stoppers of the hinge prevent disengagement.
  • Page 8 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 2. Strip Module: B-SA904-H-QM-R 5. Secure the Strip Unit to the printer with the two screws. Make sure that the Feed Roller Gear rotates smoothly. Strip Unit Feed Roller Gear SMW-3x6 Screw 6. Close the Strip Unit. Strip Unit 7.
  • Page 9 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 2. Strip Module: B-SA904-H-QM-R Close the Strip Module Cover. Perform an operation check for a proper strip issue. Media loading procedure------------- Owner’s Manual, Section 2.3 Operation check------------------------ Owner’s Manual, Section 2.9 System mode setting------------------ System Mode Manual Cleaning --------------------------------- Owner’s Manual, Section 4.1.4 2- 4...

  • Page 10: Wireless Lan Module: B-Sa704-Wlan-Qm

    INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 3. Wireless LAN Module: B-SA704-WLAN-QM 3. Wireless LAN Module: B-SA704-WLAN-QM Packing List The following parts are supplied with the kit. Make sure you have all items shown below. Wireless LAN Board (1 pc.) Antenna Cover (1 pc.) SMW-3x6 Screw (4 pcs.) Installation Manual (1 copy)
  • Page 11 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 3. Wireless LAN Module: B-SA704-WLAN-QM Installation Procedure 1. Remove the two SMW-3x6 screws from the back of the printer. Side Panel SMW-3x6 2. Open the Top Cover and Front Cover. Top Cover Front Cover 3.
  • Page 12 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 3. Wireless LAN Module: B-SA704-WLAN-QM 5. Remove the two SMW-3x6 screws to detach the Blind Plate. Blind Plate SMW-3x6 6. Remove the SMW-3x8 screw to detach the Cable Clamp. SMW-3x8 Cable Clamp 7. Put the Antenna of the Wireless LAN Board out of the opening in the printer back. Care must be taken not to hit the Antenna against the printer frame, as damaged antenna may affect the performance.
  • Page 13 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 3. Wireless LAN Module: B-SA704-WLAN-QM 8. As the following picture shows, secure the Wireless LAN Board to printer back with the two of the enclosed SMW-3x6 screws. Also, secure the Wireless LAN Board to the PCB Support Plate with the SMW-3x6 screw, together with the Cable Clamp removed in Step 6.
  • Page 14 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 3. Wireless LAN Module: B-SA704-WLAN-QM Fit the Antenna Cover to the back of the printer. Secure it with the SMW-3x6 screw. SMW-3x6 Screw Antenna Cover Pass the LAN Cable through the cut of the Antenna Cover. LAN Cable 10.
  • Page 15 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 3. Wireless LAN Module: B-SA704-WLAN-QM <Country Code Table> Country Country Country Country name Country name Country name code code code U.S.A./Canada Greece Ireland France Sweden U.K. Portugal Hungary Australia Norway Belgium Finland Germany Italy Luxembourg Spain Netherlands...

  • Page 16: Serial Interface Board: B-Sa704-Rs-Qm-R

    INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 4. Serial Interface Board: B-SA704-RS-QM-R 4. Serial Interface Board: B-SA704-RS-QM-R Packing List The following parts are supplied with the kit. Make sure you have all items shown below. SIO PC Board (1 pc.) Locking Support (1 pc.) PCB Support Plate (1 pc.) Serial Interface Cable NOTE: Make sure that the...
  • Page 17 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 4. Serial Interface Board: B-SA704-RS-QM-R 3. Remove the two SMW-3x6 screws which secure the Side Panel. Front Cover Side Panel SMW-3x6 4. Close the Front Cover and remove the Side Panel. Side Panel 5. Remove the two screws to detach the Blind Plate. Blind Plate SMW-3x6 6.
  • Page 18 INSTALLATION PROCEDURE FOR OPTIONAL EQUIPMENT EO15-33001 4. Serial Interface Board: B-SA704-RS-QM-R 7. Fit the Locking Support into the MAIN PC Board. Locking Support MAIN PC Board 8. Connect the Serial Interface Cable of the SIO PC Board to CN12 on the MAIN PC Board. MAIN PC Board CN12 SIO PC Board...
