High Volume Low Pressure spray gun
AS1009
Read this Instruction Manual carefully and understand it completely, basic
precaution should be strictly followed to prevent the damage to the tool and injury to
the operator. Retain this manual for further reference. And you should pay more
attention to the Technical Data.
CONTAIN:
Description
Specification and Technical Data
Important Safety Instruction
Instructions for Operation
Maintenance/Storing
Troubleshooting/Repairs
Parts List
RP2005
- 1 -
Advertisement
Table of Contents
Related Manuals for Aeropro AS1009
Summary of Contents for Aeropro AS1009
- Page 1 High Volume Low Pressure spray gun AS1009 Read this Instruction Manual carefully and understand it completely, basic precaution should be strictly followed to prevent the damage to the tool and injury to the operator. Retain this manual for further reference. And you should pay more attention to the Technical Data.
- Page 2 Description High volume low pressure technology applies paint with less force, meaning less "bounce" of the surface into the air, Stainless steel needle and nozzle to accommodate a variety of coatings, The spray gun Capable of very large fan pattern Specifications And Technical Data 1.
-
Page 3: Instructions For Operation
9. Before painting, make inspection for free movement of trigger and nozzle to insure tool can operate well. 10.Never modify this tool for any other applications. Only use parts, nozzles and accessories recommended and accessories recommended by manufactures. Instructions For Operation Preparation 1. -
Page 4: Maintenance
and adjustment of the fluid control knob. 5. Overlap strokes just enough to obtain an even coat. NOTE: Two thin coats of paint will yield better results and have less chance of runs than one heavy layer. 6. Use a piece of cardboard as a shield to catch overspray at the edges of the work to protect other surfaces. -
Page 5: Troubleshooting
Trouble shooting Symptom Problems Solution Fluttering or 1. Material level tool low. 1. Add material into container. spitting 2. Container tipped too far. 2. Hold more upright. 3. Loose fluid inlet connection. 3. Tighten. 4. Loose or damaged fluid tip/seat. 4. -
Page 6: Parts List
Parts List Description Description Description Air Adj. Screw Fluid Nozzle Joint Spring Core Air Adj. Knob Joint Washer Needle Adj. Knob O-ring Direction Screw Pattern Adj. Screw Washer Paint Needle Washer Phillips Screw Air Valve Spring Washer Paint Adj. Knob Air Inlet Valve Spring Pattern Adj.
