Aeropro H2000 Instruction Manual

Air powered spray gun-hvlp spray gun
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Instruction Manual
Air Powered Spray Gun-HVLP Spray Gun
Model:
H2000
H2000B
Read this Instruction Manual carefully and understand it completely, basic
precaution should be strictly followed to prevent the damage to the tool and injury to the
operator. Retain this manual for further reference. And you should pay more attention to
the Technical Data.
CONTAIN:
 Description
 Specification and Technical Data
 Important Safety Instruction
 Instructions for Operation
 Maintenance/Storing
 Troubleshooting/Repairs
 Parts List
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H2000 and is the answer not in the manual?

Questions and answers

Related Manuals for Aeropro H2000

Summary of Contents for Aeropro H2000

  • Page 1 Instruction Manual Air Powered Spray Gun-HVLP Spray Gun Model: H2000 H2000B Read this Instruction Manual carefully and understand it completely, basic precaution should be strictly followed to prevent the damage to the tool and injury to the operator. Retain this manual for further reference. And you should pay more attention to the Technical Data.

  • Page 2: Specifications And Technical Data

    4, Air connection G ¼ outside 5, Adjusting the paint Paint 6, Adjusting the paint volume 7, Adjusting the air inlet volume Specifications And Technical Data  Item No. H2000/H2000B Air Inlet 1/4" Type of Feed Gravity Standard Dia of Nozzle 0.8mm Optional Dia of Nozzle 0.6&0.8mm...

  • Page 3: Important Safety Instructions

     Important Safety Instructions 1. For toxic vapors produced by spraying certain materials can create intoxication and serious damage to health. Always wear safety glasses, gloves and respirator to prevent the toxic vapor hazard, solvent and pointing paint coming into contact your eyes or skin. (see fig 1) 2, Always spray in a well ventilated area to prevent health and fire hazrds.

  • Page 4: Operation

    20.Do not use the tool in explosive condition or face to live parts. 21.Some hazards resulting from contact with and/or breathing of toxic, gases, dusts, mists, vapours etc. may by created by operation of the equipment. Be reminded that the user to be aware of the recommendations of the coating etc.

  • Page 5: Maintenance

    6. Use a piece of cardboard as a shield to catch overspray at the edges of the work to protect other surfaces.  Maintenance Incomplete cleaning could cause function failures and a degradation of the fan form. 1. Remove any remaining paint by pouring it into another container. 2.

  • Page 6: Troubleshooting

     Trouble shooting Symptom Problems Solution Fluttering or 1. Material level too low. 1. Add material into container. spitting 2. Container tipped too far. 2. Hold more upright. 3. Loose fluid inlet connection. 3. Tighten. 4. Loose or damaged fluid tip/seat. 4.
  • Page 7  Explode view & Parts List for H2000 Description Qty. NO. Description Qty. Description Qty. Air Adjustment Knob Air Cap Filter Air Adjustment Seat Nut Sleeve Paint Inlet Plug O-ring 2.5x2.1 O-ring 17*1.5 Needle Gasket Nozzle Needle Spring Air Inlet Spring...
  • Page 8  Explode view & Parts List for H2000B Description Qty. NO. Description Qty. Description Qty. Air Adjustment Knob Nut Sleeve Cup cover Air Adjustment Seat O-ring 17*1.5 Hex nut O-ring 2.5x2.1 Nozzle Needle Gasket Nozzle Gasket Needle spring Air Inlet Spring Guide Bolt Air Valve Stem Needle Sealing Gasket...
