KTI-HD63187
10 TON AIR/HYDRAULIC SERVICE JACK
OWNER'S MANUAL
Capacity ...............................................................................10 Ton
Low Height ......................................................................... 6-3/10"
Raised Height .......................................................................23-3/5"
Length. ............................................................................... 63-4/5"
KTI-HD63187
WARNING:
Cancer and Reproductive Harm-
www.P65Warnings.ca.gov
SPECIFICATIONS
Complies with ASME PASE/2019 Safety Standard
Chassis Width with Swivel Caster Bracket ......................... 18-9/10"
Handle Length ......................................................................... 47"
Saddle Diameter .................................................................. ....5"
Shipping Weight ................................................................ 275 Lbs.
Advertisement
Related Manuals for K Tool International KTI-HD63187
Summary of Contents for K Tool International KTI-HD63187
- Page 1 KTI-HD63187 10 TON AIR/HYDRAULIC SERVICE JACK OWNER'S MANUAL WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov SPECIFICATIONS Capacity ................10 Ton Chassis Width with Swivel Caster Bracket ......18-9/10" Low Height ................. 6-3/10" Handle Length ................. 47" Raised Height ...............23-3/5" Saddle Diameter ..............5"...
-
Page 2: Warning Information
Failure to read this manual completely and thoroughly, failure to understand its OPERATING INSTRUCTIONS, SAFETY WARNINGS, MAINTENANCE INSTRUCTIONS and comply with them, and failure to comply with the METHODS TO AVOID HAZARDOUS SITUATIONS could cause accidents resulting in serious or fatal personal injury and/or property damage. KTI-HD63187... -
Page 3: Preventative Maintenance
4. Inspect the jack before each use. Do not use the jack if any component is cracked, broken, bent, shows signs of damage or leaks hydraulic Do not use the jack if it has loose or missing hardware or components, or is in any way. Take corrective action before using the jack again. KTI-HD63187... -
Page 4: Proper Storage
This warranty does not apply to damage from accident, overload, misuse or abuse, nor does it apply to any equipment which has been altered or used with special attachments other than those recommended. 45255 Five Mile Road Plymouth, MI 48170 www.ktoolinternational.com KTI-HD63187... - Page 5 KTI-HD63187 10 TON AIR/HYDRAULIC SERVICE JACK EXPLODED DRAWING KTI-HD63187...
- Page 6 KTI-HD63187 10 TON AIR/HYDRAULIC SERVICE JACK PARTS LIST REF. # DESCRIPTION QUANTITY REF. # DESCRIPTION QUANTITY Snap Ring Right Side Plate Assembly Washer Front Wheel Washer Bolt M125 Nut M16 Nut M18 Shaft Washer Snap Ring Washer Snap Ring Connecting Bar Assembly...
