Summary of Contents for Lockly Pro LOCKLY GUARD DEADBOLT 728F ZU
Page 1
INSTALLATION GUIDE MANUEL D'INSTALLATION LOCKLY GUARD ™ DEADBOLT 728F ZU DEADBOLT 728 ZU Z-Wave Smart Lock Serrure intelligente Z-Wave For commercial use & professional installation Pour usage commercial et installation professionnelle www.LocklyPRO.com...
WAIT. IMPORTANT NOTES NOTES IMPORTANTES Lockly Guard installs differently from other door locks. Professional installer(s) and locksmiths must read and follow Lockly Guard installation and user manuals to prevent damaging the product. Failure to do so may also result in the smart lock not responding correctly to lock and unlocking commands and will require re-installation.
Page 3
Welcome! This guide will walk you through step-by-step how to install and get your Lockly Guard up and running. ™ Installation generally takes less than 30 minutes. If you have any questions please reference our online support at: LocklyPRO.com/support or call (669) 500-8835 for help.
Page 4
Preparation To complete installation, you would need the following: Phillips Screwdriver Tape measure or ruler Prepare door: remove existing deadbolt or use provided template to bore new holes. 2-⅜" (60mm) Hole for fastener or 2-¾" (70mm) " 12mm " (37mm) to 2"...
Page 5
Step 1 ADJUST DEADBOLT AND INSTALL Deadbolt slot must align to the center of the door hole. Adjust as shown if needed. 2-3/4" (70mm) or 2-3/8” (60mm) The deadbolt comes set to 2-3/4" (70mm). Adjust length to 2-3/8” (60mm) if necessary. (wear gloves to protect from possible pinching).
Page 6
Step 1 ADJUST DEADBOLT AND INSTALL continued Insert the deadbolt into door edge hole, Extend the deadbolt by inserting a flat-head make sure that the right side is up and the screwdriver into the slot and turning clock- slot is in the vertical position. Secure with 2 wise.
Step 2 INSTALLING EXTERIOR ASSEMBLY Using a flat head screwdriver, insert fastener screw bolt to the hole at the back of the exterior assembly . Turn clockwise to tighten the screw bolt. Make sure torque blade is in the vertical position with we the deadbolt extended. Place assembly and torque blade through the deadbolt slot and guide connection cables through the cross-bore hole under the deadbolt as shown.
Step 3 INSTALLING INTERIOR ASSEMBLY 1: Check interior mounting plate 2: Align and secure mounting plate alignment to your door hole before with adhesive strips. Guide connection securing with adhesive strips. cables through the hole and secure to the lower left notched hole. PM4 x 25mm Screw, for door thickness, 1-7/16"~1-2/3"(37~43mm) PM4 x 35mm Screw, for door thickness, 1-2/3"~2"(43~50mm) Select screw F1/F2 accord-...
Page 9
Step 4 INSTALLING THE INTERIOR ASSEMBLY Plug the cable coming through mounting plate into the interior assembly as shown. Tuck cable under eyelet hooks and route to the right on interior assembly Plug into , match red side of plug with red on socket - insert tightly.
Page 10
Step 4 INSTALLING THE INTERIOR ASSEMBLY continued Torque Blade Thumb turn shaft Align torque blade with thumb turn shaft, make sure both are in the vertical position. Before placing the interior Place the interior assembly Use 2 screws to secure assembly onto the mount- against the mounting plate the interior assembly to the...
Step 5 INSTALLING BATTERIES PRESS & HOLD for 10 seconds 1: With door open and deadbolt fully extended, place ribbon inside compartment and insert 4 batteries (note correct -/+ polarity). 2: After all batteries are installed, PRESS and HOLD the program button for 10S. The lock will autmatically start self-check (release program button once check starts).
Page 12
Step 5 INSTALLING BATTERIES continued 3: Once self-check completes ensure the lock operates smoothly by manually locking and unlocking the door using the thumb turn on the interior assembly. The deadbolt should operate smoothly without any interference or binding. If necessary, repeat step 2 and ensure that (a) the deadbolt was extended and (b) the torque blade was inserted vertically while the deadbolt was extended.
Page 13
Step 6 INSTALLING STRIKE PLATE Install the supplied door strike reinforcer and secure with screws . Then install the door strike on top of the reinforcer and secure with screws . Make sure deadbolt operates smoothly without binding or catching. (2X) (2X) Because doors and frames vary in design it may be necessary to make slight adjustments to your door strike and/or dust box in order to ensure...
Page 14
Step 7 DOWNLOAD LOCKLYPRO APP You have completed the Lockly Guard physical lock installation. To enable live monitoring you will need to setup the included Secure Link Wi-Fi hub and pair it with the Lockly Guard deadbolt smart lock. Before connecting Secure Link Wi-Fi hub download the LocklyPRO app on your smartphone. It’s required to finish setup and to set (pair) the connection between hub and lock.
Page 15
Add more Smart to your Home Secure Link Wi-Fi Hub Add the optional Lockly Secure Link Wi-Fi Hub, together with the free LocklyPRO app, it's easier than ever to securely control and manage your door from anywhere, anytime. Real-time, monitoring, & status Monitor open/closed door status with real-time alerts sent to your smart phone, no matter where you are.
Page 16
FCC Warning: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
Page 17
Bienvenue! Ce guide vous explique, étape par étape, comment installer et rendre opérationnel votre Lockly Guard ™ L'installation prend généralement moins de 30 minutes. Si vous avez des questions, veuillez consulter notre soutien en ligne à l'adresse suivante: LocklyPRO.com/support ou appelez le (669) 500-8835 pour obtenir de l'aide. Dépliant de présentation des pièces d'installation au verso...
Page 18
Préparation Pour terminer l'installation, vous aurez besoin des éléments suivants: Tournevis Phillips Mètre ruban ou règle Préparez la porte: retirez le pêne dormant existant ou utilisez le gabarit fourni pour percer de nouveaux trous. 2-⅜" (60mm) Trou pour l'attache or 2-¾" (70mm) "...
Page 19
Étape 1 AJUSTER LE PÊNE DORMANT ET L'INSTALLER La fente du pêne dormant doit être alignée sur le centre du trou de la porte. Ajustez comme indiqué si nécessaire. 2-3/4" (70mm) or 2-3/8” (60mm) Le pêne dormant est réglé à 2-3/4 po (70 mm). Ajustez la longueur à 2-3/8 po (60 mm) si nécessaire.
Page 20
Étape 1 AJUSTER LE PÊNE DORMANT ET L'INSTALLER suite Allongez le pêne dormant en insérant un Insérez le pêne dormant dans le trou du tournevis à tête plate dans la fente et en bord de la porte, assurez-vous que le côté tournant dans le sens horaire.
Page 21
Étape 2 INSTALLATION DE L'ENSEMBLE EXTÉRIEUR À l'aide d'un tournevis à tête plate, insérez le boulon de montage dans le trou situé à l'arrière de l'ensemble extérieur . Tournez dans le sens des aiguilles d'une montre pour serrer le boulon de montage. S’assurer que la lame dynamométrique est en position verticale avec la couche dormante allongée.
Page 22
Étape 3 INSTALLATION DE L'ENSEMBLE INTÉRIEUR 1: Vérifiez l'alignement de la plaque de fixation intérieure par rapport au 2: Alignez et fixez la plaque de montage trou de votre porte avant de la fixer avec les bandes adhésives. Guidez les avec les bandes adhésives.
Page 23
Étape 4 INSTALLATION DE L'ENSEMBLE INTÉRIEUR Branchez le câble qui passe par la plaque de fixation dans l'ensemble intérieur comme ndiqué. Placez le câble sous les crochets de l'œillet et acheminez-le vers la droite sur l'ensemble intérieur Branchez dans , faites corresspondre côté...
Page 24
Étape 4 INSTALLATION DE L'ENSEMBLE INTÉRIEUR suite Arbre de rotation Lame de couple de pouce Alignez la lame de couple avec l'arbre de rotation de pouce, assurez-vous que les deux sont en position verticale. Avant de placer l'ensemble Placez l'ensemble intérieur Utilisez 2 vis pour fixer intérieur sur la plaque de...
Étape 5 INSTALLATION DES PILES Appuyez et maintenez pendant 10 secondes 1: Une fois la porte ouverte et le pêne dormant complètement déployé, placez le ruban à l'intérieur du compartiment et insérez 4 piles (respectez la polarité -/+). 2: Une fois toutes les piles installées, appuyez sur le bouton de programme et maintenez-le enfoncé...
Page 26
Étape 5 INSTALLATION DES PILES suite 3: Une fois l'autovérification terminée, assurez-vous que la serrure fonctionne correctement en verrouillant et déverrouillant manuellement la porte à l'aide de la molette située sur l'ensemble intérieur. Le pêne dormant doit fonctionner en douceur, sans interférence ni blocage.
Page 27
Étape 6 INSTALLATION D'UNE PLAQUE DE GÂCHE Installez le renfort de gâche fourni et fixez-le avec des vis . Installez ensuite la gâche par-dessus le renfort et fixez-la avec des vis . Assurez-vous que le pêne dormant fonctionne en douceur, sans se coincer ni se bloquer. (2X) (2X) Les portes et les cadres étant de conception différente, il peut être nécessaire de procéder à...
Page 28
Étape 7 TÉLÉCHARGER L'APPLICATION LOCKLYPRO Vous avez terminé l'installation de la serrure physique Lockly Guard. Pour activer la surveillance vous devrez configurer le hub Wi-Fi Secure Link inclus et l'associer aux capteurs de porte intelli- gents à pêne dormant Lockly Guard. Avant de connecter le concentrateur Wi-Fi Secure Link, téléchargez l'application LocklyPRO sur votre téléphone intelligent.
Page 29
Ajoutez de l'intelligence à votre maison Secure Link Wi-Fi Hub Ajoutez le hub Wi-Fi Lockly Secure Link en option, ainsi que l'application gratuite LocklyPRO , il est plus facile que jamais de contrôler et de gérer en toute sécurité votre porte de n'importe où, n'importe quand. Temps réel, surveillance et état Surveillez l'état de la porte ouverte/fermée avec des alertes en temps réel envoyées...
Page 30
Avertissement FCC: Cet appareil est conforme à la partie 15 des règles de la FCC. Le fonctionnement est soumis aux deux conditions suivantes: (1) Cet appareil ne doit pas causer d'interférences nuisibles, et (2) cet appareil doit accepter toute interférence reçue, y compris les interférences qui peuvent causer un fonctionnement indésirable.
Page 31
INSTALLATION OVERVIEW AND PARTS LIST Parts List / Liste des pièces APERÇU DE L’INSTALLATION ET LISTE DES PIÈCES Labeled As Description Étiqueté comme Keys / Clés Exterior Assembly / Ensemble extérieur Exterior / Extérieur Outer screw bolt / Boulon à vis extérieur GET THE MOST OUT OF YOUR Mounting Plate / Plaque de fixation KM4 x 8mm screw / Vis KM4 x 8mm...
