EDS SRL
manuale tecnico
RK100
LINEAR OPTICAL SMOKE
BARRIER DETECTOR
RK100-B-EX
RK100-BS-EX
with laser pointer
BLP-100
TECHNICAL MANUAL
TECHNICAL INSTRUCTIONS FOR INSTALLATION,
START-UP AND MAINTENANCE
Attention! The video tutorial regarding the installation of the RK-100-BS-EX detector equipped with
Laser Pointer BLP-100 is available on the website www.eds.eu, under the MEDIA AND TUTORIALS page.
05-04-2024
File: RK100BS-EX_EN_ist_0424
MADE IN ITALY BY
|
|
|
|
|
|
EDS SRL
Via Cà Nova Zampieri 6
37057
San Giovanni Lupatoto (VR)
Tel. 0039045547529
www.eds.eu
eds@eds.eu
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EDS RK100-B-EX
Summary of Contents for EDS RK100-B-EX
- Page 1 TECHNICAL INSTRUCTIONS FOR INSTALLATION, START-UP AND MAINTENANCE Attention! The video tutorial regarding the installation of the RK-100-BS-EX detector equipped with Laser Pointer BLP-100 is available on the website www.eds.eu, under the MEDIA AND TUTORIALS page. 05-04-2024 File: RK100BS-EX_EN_ist_0424 MADE IN ITALY BY EDS SRL Via Cà...
-
Page 2: Table Of Contents
CHAPTER INDEX QUICK INSTALLATION The rules below refer to expert personnel with pre- 1 - Reference Standards vious experience in installing the EDS detector model 2 - Safety Instructions RK100-BS-EX. If you do not have this experience, the 3 - Validity... -
Page 3: Reference Standards
We recommend reading the manual "Eds_Installation Guide_en" available on our website www.eds.eu In case of installation in European Community countries, the rules of EN54-14 (Fire detection and fire alarm sy- stems) must be followed. -
Page 4: Validity
2.4 - Modifications to the product are not allowed 2.5 - The RK100-BS-EX detector must be installed only if completely intact 2.6 - Only EDS spare parts must be used 2.7 - Ordinary and extraordinary maintenance operations must be carried out only by qualified personnel with the approval of "expert"... -
Page 5: Connection Cables
EDS SRL manuale tecnico RK100 6.5 - Bring the cables inside using the 3/4 ”entries and using an ATEX certified cable gland 7- CONNECTION CABLES 7.1 - The reduced consumption of the device (20 mA with alarm relay normally not attracted and 30 mA with at- tracted relay) allows the use of cables with reduced cross-sections. -
Page 6: Operation
10 - OPTICAL ALIGNMENT WITH LASER POINTER BLP-100 10.1 - The pointers are installed on board the EDS linear optical detectors in order to speed up the optical alignment operation between TX and RX (for barrier devices) or between the detector and its optical reflector. - Page 7 EDS SRL manuale tecnico RK100 10.6 - Act on the V1-V2-V3 bolts (fig. 10) for the orientation of the optics of the TX transmitter, so that the laser beam hits the lens of the RX receiver on the opposite wall. When this happens the receiver lens has an intense red spot of light.
- Page 8 EDS SRL manuale tecnico RK100 • Direct the beam of light from the lamp onto the lenses of the Transmitter • Observe the screen located behind the lens inside the Transmitter. You will see a luminous point representing the image of the lamp •...
-
Page 9: Darkening Circuit Calibration
EDS SRL manuale tecnico RK100 11 - DARKENING CIRCUIT CALIBRATION Calibration operations of the electrical signal must be performed according to the following sequence: 11.1 - It is recommended to connect a Tester with a Volt scale between terminal 9 (SIG - signal) and terminal 2 (V- negative) to the RX terminal block for measuring the signal level. - Page 10 EDS SRL manuale tecnico RK100 11.4 - Maximum signal search by orienting the TX transmitter. After finding the maximum signal by adjusting the RX, it is also necessary to search for the maximum by orienting the TX optics as follows: The Laser beam and the axis of the infrared beam emitted by the TX may have an angular error.
-
Page 11: Final Calibration
Adjust the sensitivity according to environmental conditions. 14 - TURBULENCE SENSITIVITY ADJUSTMENT This adjustment must be made only on the model equipped with this particular detection circuit (RK100-B-EX-BLP). To adjust, use the SW1 switch (TURBO). There are 4 levels that can be used: Sensitivity increases from 1 (minimum) to 4 (maximum). -
Page 12: Fault Output
EDS SRL manuale tecnico RK100 16- AUTOCOMPENSATION 16.1 - The internal electronics of the detector is equipped with a special signal autocompensation circuit. If the de- tector is installed in a particularly dusty room, the dust deposited on the front of the TX and RX causes a decrease in the signal. -
Page 13: Maintenance
EDS SRL manuale tecnico RK100 20- MAINTENANCE 20.1 - The device requires simple and periodic maintenance. It can be scheduled or made automatic upon specific detector indication. During normal operation and after a certain time from installation, if maintenance is not performed, the detector, due to the dirt deposited on the front covers, generates a fault signal due to the decrease in the signal beyond the compensation limit. - Page 14 22 - TECNICAL DATA • Models: RK100-BS-EX • Name: linear optical smoke detector • Builder: EDS srl - V. Cà Nova Zampieri 6 - 37057 S.G. Lupatoto - Verona • Nominal power supply: 12/24 Vdc. • Power supply limits: 11-30 Vdc •...
- Page 15 EDS SRL manuale tecnico RK100 Fig. 2 Fig. 4 Fig. 5 Oblò Fig. 3...
- Page 16 EDS SRL manuale tecnico RK100 Fig. 6...
- Page 17 EDS SRL manuale tecnico RK100 JUMPER SETTING Jumper Position Result Alignment procedure not activated Alignment procedure activated Fault relay contact closed - NC Fault relay contact open - NO Alarm memory deactivated - OFF Alarm memory activated - ON Reset...
- Page 18 EDS SRL manuale tecnico RK100 INTERNAL ELEMENTS OF THE RECEIVER P1 - trimmer for adjusting the signal level. It is normally set at 50-60% which corresponds to a 5V signal at maxi- mum distance SW2 - trimmer for adjusting the sensitivity of the darkening sensitive circuit •...
- Page 19 EDS SRL manuale tecnico RK100 Fig. 9...
- Page 20 EDS SRL manuale tecnico RK100 VIEW OF THE INTERNAL PARTS TRANSMITTER Fig. 10 SW3 - selector for adjusting the transmitter power (TX) - the power increases from 1 to 4. The power is maximum in position 4 and minimum in position 1.
- Page 21 EDS SRL manuale tecnico RK100 TRANSMITTER TERMINAL BLOCK DIAGRAM Fig. 12 RECEIVER TERMINAL BLOCK DIAGRAM Fig. 13...
- Page 22 EDS SRL manuale tecnico RK100 Fig. 14 Esempio di collegamento dell’RK100-BS-EX ricevitore con una centrale di controllo a zone. In questo caso il rivelatore occupa una zona della centrale. Lo stato dei relè indicati corrispondono alla condizione di riposo del rivelatore.
- Page 23 4 - Name, registered trade name or registered trademark and contact address of the manufacturer as required pursuant to article 11(5) : EDS srl , Via Cà Nova Zampieri 6, San Giovanni Lupatoto (Verona) , 37057, Italy 5 - Where applicable, name and contract address of the authorised representative whose mandate covers the tasks specified in article 12(2) : Not applicable.
- Page 24 10 - The performance of the product identified in 1 and 2 is in conformity with the declared perfor- mance in 9. This declaration of performance is issued under the sole responsibility of the manufacturer identified in 4. EDS srl, Verona, 01/07/2013 NAME : ENG. POMPOLE GIANCARLO...
- Page 25 1. OBJECT 8. PROCEDURE EDS S.r.l. - Via Cà Nova Zampieri 6, 37057 S. G. Lupatoto - Verona, Italy In the event of a defect covered by this warranty, the purchaser should (hereinafter “EDS”), guarantees its products to be free from defects contact EDS - Via Cà...
- Page 26 The information contained in this document has been thoroughly evaluated and can be considered reliable. However, the firm EDS assumes no responsibility for any inaccuracies. Additionally, the firm EDS reserves the right to make changes to any part of this document and/or product, with the aim of enhancing quality, reliability, or design.
