INSTRUCTION MANUAL
Mini-Star™
Miniature DC Peristaltic Pump
www.wpiinc.com
080724
080724

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini-Star and is the answer not in the manual?

Questions and answers

Summary of Contents for WPI Mini-Star

  • Page 1 INSTRUCTION MANUAL Mini-Star™ Miniature DC Peristaltic Pump www.wpiinc.com 080724 080724...
  • Page 3: Table Of Contents

    Mini-Star™ CONTENTS ABOUT THIS MANUAL ........................1 Notes and Warnings ......................... 2 Unpacking ........................... 2 INSTRUMENT DESCRIPTION ......................3 MAINTENANCE ..........................8 ACCESSORIES........................... 8 TROUBLESHOOTING ........................8 SPECIFICATIONS ..........................9 DECLARATION OF CONFORMITY ....................10 WARRANTY .............................11 Claims and Returns ........................11 Repairs ............................11...
  • Page 4 World Precision Instruments...
  • Page 5: About This Manual

    The fluid makes contact only with the interior of the flexible tubing and thus cannot contaminate or damage the pump. WPI’s MiniStar™ peristaltic pump is easy to maintain and clean. It is compact and lightweight and can conveniently fit into almost any experimental setup.
  • Page 6: Notes And Warnings

    Concealed damage should be reported at once to the carrier and an inspection requested. Please read the section entitled “Claims and Returns” on page 11 of this manual. Please contact WPI Customer Service if any parts are missing at 941.371.1003 or customerservice@wpiinc.com.
  • Page 7: Instrument Description

    Mini-Star™ INSTRUMENT DESCRIPTION The Mini-Star is a compact pump that can be used as a standalone device or mounted on a post. The pump is powered by a 12 V DC adapter that is connected to a jack on the rear panel. The pump can be controlled either with a handheld remote or with an analog signal from a computer.
  • Page 8 Analog Control (Optional) The analog input control provides precise control over the pump without using the technically advanced RS485 communication. WPI offers an external control module supporting analog signals of 0~5V. The pin connections in the module are enumerated below.
  • Page 9 DB15 plug. The communication protocol for the pump is given in the Appendix (see page 6). Users proficient in creating software applications (with LabView, C++ or similar tools) may wish to write their own control programs, but WPI does not provide support for this activity.
  • Page 10 • addr: one byte, the pump address (1-30). 31 is the broadcast address. • len: one byte, the length of pdu • pdu: command code • fcs: one byte, NOT OR of addr, len, pdu. pdu format: command code • Set the rotation speed (RPM): Call WJ RPM, 2 byte...
  • Page 11: Maintenance

    Mini-Star™ • Read pump addr: Call RID Reply where RID is the ASCII of the number 52H 49H 44H and addr can only be one of the pump address (1-30). Settings • Rotation speed is in the unit of 0.1 rpm. The maximum speed is 50.0 rpm (i.e., 01 F4H = 500)
  • Page 12: Accessories

    NOTE: If you have a problem/issue with that falls outside the definitions of this troubleshooting section, contact the WPI Technical Support team at 941.371.1003 or technicalsupport@wpiinc.com. World Precision Instruments...
  • Page 13: Specifications

    Mini-Star™ SPECIFICATIONS This unit conforms to the following specifications: Number of Rollers Number of Channels Rotor Rotation Clockwise or counterclockwise Rotor Speed Range 1-50 rpm Rotor Speed Resolution 0.1 rpm with RS485, 1 rpm otherwise Tubing OD < 4.8 mm. Wall Thickness 0.8~1.0 Flow Rate Range 0.06-14.0 mL/min...
  • Page 14: Declaration Of Conformity

    DECLARATION OF CONFORMITY World Precision Instruments...
  • Page 15: Warranty

    WPI shall not be liable for any damage to data or property that may be caused directly or indirectly by use of this product.
  • Page 16 W OR LD P RE C I SI O N I NSTR U M E N TS...
