Four Seasons Courtyard CPTV-2019-SET Assembly Instructions

Item# 258709
Model# CPTV-2019-SET
Coral Bay 4 PC Woven Deep Seating Set - Lounge Chair
Assembly Instructions
Step 1: Remove protective wrapping and lay all parts on floor. Identify all parts packed in carton
against attached parts list.
Step 2: Assemble Right Arm (A), Seat (H), Back Brace Panel (G), Side of Back Seat (F) together with
Long Bolt (BB) and Washer (CC), using Allen Wrench to thread bolts into frame as shown in Diagram 1.
Step 3: Attach Bottom Tabs of Back Seat (F) to Right Arm (A) with Short Bolt (AA) and Washer (CC),
using Allen Wrench to thread bolts in as shown in Diagram 1.
Step 4: Repeat the same when attaching Left Arm to rest of the parts as shown in Diagram 2.
Note: When assembly chair together, loosely thread bolts into all attachment points first to make sure
all parts and bolts fit in proper position. Afterwards, go back and securely tighten all bolts accordingly.
It is user's responsibility to ensure all bolts are tightened securely before turning chair to upright
position and using chair.
F
G
H
DD
AA
CC
Diagram 1
A
DD
BB
CC
