Four Seasons Courtyard Carrington RXTV-1822-ST Assembly Instructions

Item# 242957
Model# RXTV-1822-ST
FS Carrington Side Table
Assembly Instructions
Step 1: Remove protective wrapping and lay all parts on floor. Identify all parts packed in carton against
attached parts list.
Step 2: Lay Table Top Frame (A) upside down on floor, so bottom is facing up. Place a protective soft material
on floor before placing table top face down on floor. Then attach each of Side Legs (B) to the bottom, using
Bolt (D), and Washer (E) and Bolt cover (F) as shown in Diagram 1.
Step 3: Then attach the Bottom Shelf (C) to the legs (B), using Bolt (D), Washer (E) and Bolt Cover (F)
as shown in Diagram 2.
Step 4: Make sure all bolts are aligned properly and tightened securely. Then place bolt covers over bolts and
turn the table over onto it's legs carefully using a flat surface as shown in Diagram 3.
NOTE: IT IS USER'S RESPONSIBILITY TO MAKE SURE ALL PARTS ARE ASSEMBLED AND TIGHTENED
PROPERLY AND SECURELY.
Warning!: TABLE IS NOT MEANT FOR SITTING. DO NOT SIT OR LEAN FULL BODY AGAINST TABLE.
B
F
B
D
F
E
Diagram 1
D
E
A
