Four Seasons Courtyard 258714 Assembly Instructions

5 pc set - chat chair

Advertisement

Item# 258714
Model# RXTV-2007-SET
FS Caranna 5 PC Set - Chat Chair
Assembly Instructions
Step 1: Remove protective wrapping and lay all parts on floor. Identify all parts packed in carton against
attached parts list.
Step 2: Place Chair Base (B) on its legs. Then place Seat Bucket (A) on top of Chair Base (B) positioning the
two tabs on each side of seat to align to the two holes in each side of the Base. Then attach Seat Bucket (A)
to Chair Base, using Bolts (C), Washers (D), and Bolt Covers (E) as shown in Diagram 1.
Step 3: Make sure all bolts are aligned properly and tightened securely. Then place bolt covers over bolts.
NOTE: IT IS USER'S RESPONSIBILITY TO MAKE SURE ALL PARTS ARE ASSEMBLED AND TIGHTENED
PROPERLY AND SECURELY.
A
Diagram 1
B
D
C
E
