Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
hardware which may have come loose inside the carton during shipment. Identify and count all hardware
and compare with the hardware list below.
When placing furniture on non-carpeted flooring, HMI recommends the use of floor protection such as
an area rug or furniture pads. Area rugs and padding not included with purchase.
No.
1
2
3
No.
A
B
C
D
E
F
STEP 1
-Attach Front leg(2) to Seat Cushion(3),
Do not fully tighten at this moment.
Made In Malaysia
L I V I N G S P A C E S
ASSEMBLY INSTRUCTION
ITEM 305-P380260
Kara Wood Back Side Chair
PARTS LIST
Description
Wooden Chair Back
Front Leg
Seat Cushion
HARDWARE LIST
Description
JCBC Screw M6 x 35mm
JCBC Screw M6 x 60mm
JCBC Screw M6 x 80mm
Spring Washer M6 x 12mm Ø
Flat Washer M6 x 19mm Ø
Allen Key M4 x 65mm
F
D
E
B
Residential Use Only
Sketch
Sketch
4x
3
Quantity
1pc
2pcs
1pc
Quantity
2pcs
4pcs
4pcs
10pcs
10pcs
1pc
2
Page 1 of 3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Living Spaces Kara 305-P380260
Summary of Contents for Living Spaces Kara 305-P380260
- Page 1 L I V I N G S P A C E S ASSEMBLY INSTRUCTION ITEM 305-P380260 Kara Wood Back Side Chair Thank you for purchasing this quality product. Be sure to check all packing material carefully for small hardware which may have come loose inside the carton during shipment. Identify and count all hardware and compare with the hardware list below.
- Page 2 L I V I N G S P A C E S STEP 2 -Place Cushion Seat(3) on a clean flat surface attach with Back Chair(1). COMPLETE Turn the chair upright and place on level surface. Adjust the front legs so that chair is level and does not wobble.
- Page 3 L I V I N G S P A C E S REPLACEMENT PARTS ITEM 305-P380260 Kara Wood Back Side Chair x2 R305-P380260-LEGF x1 R305-P380260-HWKIT Front Leg Hardware Kit x1 R305-P380260-BACK x1 R305-P380260-SEAT Made In Malaysia Residential Use Only Page 3 of 3...
