Summary of Contents for Christopher Knight Home Hallandale 637162304990
- Page 1 Caution : You must read this before you proceed Table Picture Label Picture Description Table Top Table Leg with pre- attached Levellers Central Support Ring Page 1 OF 6 Noble house Home Furnishings LLC...
- Page 2 Label Picture Description ① Bolt(M8*35mm) ② Washer(8mm) ③ Spring Washer(8mm) ④ Nut(8mm) ⑤ Hex Bolt(M8*30mm) ⑥ Screwdriver ⑦ Spanner ⑧ Rubber Cap Extra Adjustable ⑨ Leveller Page 2 OF 6 Noble house Home Furnishings LLC...
- Page 3 Overview Table Top(A) Central Support Ring(C) Table Leg(B) FRONT FACING This Table has multiple parts and may require up to some 30 minutes to assemble. To give you an overview of the Table parts, the above picture is to help you put the various parts into perspective.
- Page 4 Step 2 Lay the Table Top(A), facedown, onto a flat, soft, clean surface and lock the mounting positions with Bolts(①) by using Screwdriver(⑥). DO NOT OVERTIGHTEN. Step 3 Attach Table Leg with pre-attached Levellers(B) to Table Top(A) using Washers(②), Spring Washers(③) and Nuts(④) with Spanner(⑦). DO NOT OVERTIGHTEN.
- Page 5 Step 4 ⑦ ② ③ ⑤ Loosely attach Central Support Ring(C) to Table Leg with pre-attached Levellers(B) using Washers(②), Spring Washers(③) and Nuts(⑤), using the Spanner(⑦). Tighten all these Nuts and Washers in a sequential manner. DO NOT OVERTIGHTEN. Step 5 Adjust height Adjust low for balance...
- Page 6 Page 6 OF 6 Noble house Home Furnishings LLC...
