Summary of Contents for Christopher Knight Home 295650
- Page 1 Caution : You must read this before you proceed DINING CHAIR Picture Label Picture Description Chair Body Leg Frame Page 1 OF 6 Noble house Home Furnishings LLC...
- Page 2 Label Picture Description Bolt (m6x20mm) ① Bolt (m6x16mm) ② M6 Flat washer ③ M6 Spring washer ④ Aluminum pad ⑤ Allen Key ⑥ Before Beginning Assembly: Page 2 OF 6 Noble house Home Furnishings LLC...
- Page 3 Overview: Chair Body (A) Leg Frame (B) FRONT FACING This Dining Chair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Dining Chair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 4 Step 2 Attach the front two mounting positions on Leg Frame(B) to the mounting position on Chair Body (A) using Blot (①), Spring washer (④), Flat washer (③), Aluminum pad (⑤), then tight them by Allen Key (⑥). Do not fully tighten the Bolts. Step 3 Attach the back two mounting positions on Leg Frame(B) to the mounting position on Chair Body (A) using Blot (②) and Spring washer (④), Flat washer...
- Page 5 Step 4 Stand the Chair up and place on flat, level surface. Carefully and gently sit onto the Chair. This will help properly align all parts at all joints and remove any gaps. Carefully get off the Chair and gently turn it over. Tighen all Bolts at all joints.
- Page 6 Page 6 OF 6 Noble house Home Furnishings LLC...
