Summary of Contents for Christopher Knight Home 300577
- Page 1 Caution : You must read this before you proceed Please look in the velcro pouch for hardware packs and legs. Bar Stool Label Picture Description Upper Stretcher Page 1 OF 8 Noble House Home Furnishing LLC...
- Page 2 Lower Stretcher Cushion Seat Label Picture Description Bolt ① ( M6 x 45mm ) ② Spring Washer ③ Washer Wood Screw ④ ( M4 x 38mm ) ⑤ Allen Key Screwdriver (Not ⑥ provided) Before Beginning Assembly: Unpack and place all parts for clear visibility Page 2 OF 8 Noble House Home Furnishing LLC...
- Page 3 OVERVIEW Cushion Seat (E) Upper Stretcher (C) Leg (A) Leg (B) Upper Stretcher (C) Leg (A) Leg (B) Lower Stretcher (D) Page 3 OF 8 Noble House Home Furnishing LLC...
- Page 4 This Bar Stool has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Bar Stool parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 5 Step 2 Leg (B) Leg (A) Place the Cushion Seat (E) facedown onto a clean, non-marring surface and carefully remove the Seat Cover. 2.1) Insert the first pair of Legs (A) & (B) into the Cushion Seat (E). Attach Legs (A) & (B) to the Cushion Seat (E) using Bolts (①), Spring Washers (②), and Washers (③) with Allen Key (⑤) as shown above.
- Page 6 3.1) Insert the other pair of Legs (A) & (B) into the Stretchers (D) and Cushion Seat (E). Then attach using Bolts (①), Spring Washers (②), and Washers (③) with Allen Key (⑤) as shown above. Do not fully tighten the Bolts. 3.2) Attach Stretchers (C) to Legs (A) &...
- Page 7 Step 5 Your Bar Stool is now ready for use. This Bar Stool can only be used on a flat, level surface. Page 7 OF 8 Noble House Home Furnishing LLC...
- Page 8 Page 8 OF 8 Noble House Home Furnishing LLC...
