- Page 1 Caution: You must read this before you proceed. Bar Chair/Counter Chair Page 1 OF 8...
- Page 2 Part NO. Picture Description Chair Back 1 PC Chair Seat 1 PC Left Front Leg 1 PC Right Front Leg 1 PC Left Side Rail 1 PC Right Side Rail 1 PC Front Rail 1 PC Label Picture Description Bolt(M6x80mm) 4 PCS Bolt(M6x50mm) 4 PCS...
- Page 3 Before Beginning Assembly: Pack A for assembling the Bolt(M6x80mm)+ Seat Frame(B) to the hind Washer legs of Chair Back(A) +Spring Washer Pack B for assembling the Bolt(M6x50mm)+ Seat Frame(B) to the Front Washer Leg Left(C) & Front Leg +Spring Washer Right(D) Pack C for assembling the Bolt(M6x45mm)+...
- Page 4 Chair Back (A) Chair Seat (B) Left side Rail (E) Left Leg (C) Front Rail (G) Right side Rail (F) Right Leg (D) FRONT FACING This Bar Chair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Bookshelf parts, the above picture is to help you put the various Table parts into perspective.
- Page 5 E. Left Side Rail & F. Right Side Rail G. Front Rail Place the Chair Back(A) and Chair Seat(B) on a clean, non-marring surface. Remove the Seat Base Cover from the underside of the Chair Seat(B) and take out all of the Parts and Hardware.
- Page 6 Insert the Front Rail(G) into the oval housing of Left Front Leg (C) & Right Front Leg (D) as shown above. Then, use Hardware Pack F to attach the Front Rail(G) to the Left Front Leg (C) & Right Front Leg (D).
- Page 7 Step 6 Place the chair on a Level Surface to check if it wobbles. If it is wobbles, lift the chair some 30cm to 50cm high from the ground, keep your feet and toes well away from the drop zone, and drop the chair freely and vertically with the four legs, hitting the ground at the same time.
- Page 8 Page 8 OF 8...
