ROUGH-IN REQUIREMENTS (see figure 2)
1
1. Checkallitemshavebeenreceived.
•
Towel Warmer
•
HardwireKit(plateandtube)
•
BracketPack(4brackets)
2. Y ourtowelwarmerrequires110VGFCIprotectedpower.Thepowerfeedshouldbelocatedin
asinglegangelectricalboxasshowninfigure2.Pleaseensurecorrectlocationoftheelectrical
boxonthebottomright,asthiswilldetermineyourtowelwarmerlocation.Donotinstalltowel
warmerupsidedown.
3. W allstudsorplywoodbackingisrecommendedinthewallatallbracketlocations.Seefigure2
forbracketlocations.
INSTALLATION INSTRUCTIONS (see figure 1)
2
1. F ixwallsupports"A"tothewallusingthescrewsprovidedandin
locationsasshownonfigure2.
2. H angandadjustthetowelwarmerusingsetscrews"B"tolockstud
"C"inthewallbracket"A".Ensurethetowelwarmerisfirmlyand
safelyfixed.
HARDWIRE CONNECTION (see figure 4)
3
TURN OFF POWER SUPPLY BEFORE PROCEEDING
Do not connect the towel warmer to the power supply until all instructions have been read and installa-
tion carried out in accord with them. Your towel warmer is 180W (110V) and conforms to CSA standards
(File ref: 2422531). Please ensure the CSA label is visible.
1. F eedtheelectricalcordlocatedatthebottomofthetowelwarmerfirstthroughtheroundtube
thenthroughthecoverplate.
2. Completeallelectricalconnectionsasshowninfigure3.
3. Pushcoverplateontotubeandscrewtoelectricboxwiththeenclosedscrews.Adjustwhere
necessary-seefigure4.
Warning:Incaseofdamageorfailureofthetowelwarmertheunitshouldbereturnedtothemanufacturerortheirdistributor.
Thewarrantyof2yearsonthetowelwarmerisNOTVALIDincaseofimproperuseorinstallation.Productisdesignedforuse
within Canada and the United States only.
Kontour Square Towel Warmer
Installation Guide
Code: K6053W / K6054W / K6055W
24" x 60" Hardwire
FIGURE1
cs@icobath.com | www.icobath.com
877 757 8930
