  • Page 1 DGT4X Digital weight transmitter with 4 channels USER MANUAL ENGLISH Firmware version 01.19.xx www.diniargeo.com...

  • Page 3: Table Of Contents

    Access to the advanced menu and saving the changes   24 Function of the keys in the menu   25 Block diagram of the menu Mode of use of the DGT4X   27 ADC pre-calibration   27 Theoretical calibration   28  ...
  • Page 4 Quick zero calibration (pre-tare reset)   35 Filter and stability   36   36 Filter adjustment   37 Anti-peak filter   37 Stability detection sensitivity   38 Stability detection time   38 Additional filter for stability detection Gravity   39 Zero functions and parameters  ...
  • Page 5 Serial communication configuration   50   50 Selection of the PC serial port Configuration of the printer port (COM.PRN)   51   51 Transmission mode   52 Baud rate, parity, data bits, stop bits   52 Printer power on mode  ...
  • Page 6 DGT4X_01.19_23.06_EN_U...

  • Page 7: Introduction

    Thank you for purchasing a DINI ARGEO product. This manual contains all the instructions for a correct installation and commissioning of the DGT4X 4-channel digital weight transmitter. While thanking you for purchasing this product, we would like to draw your attention to some aspects of this manual.

  • Page 8: Transmitter Installation

    Transmitter installation Installation requirements Observe the following conditions for correct installation of the transmitter and of the load receiver: • Flat, level support surface. • Stability and absence of vibrations. • Absence of aggressive dusts and vapours. • Absence of draughts. •...

  • Page 9: Electrical Precautions

    Electrical precautions • Use a regulated mains supply within ± 10% of the rated voltage. • The electrical protections (fuses, etc.) are the responsibility of the installer. • Observe the recommended minimum distances between cables of different categories (see table on page 10). •...
  • Page 10 RECOMMENDED DISTANCES AND CABLE CLASSIFICATION Category I Category II Category III Category IV ≥ 100 mm ≥ 200 mm ≥ 500 mm Distance ≥ 100 mm ≥ 500 mm ≥ 500 mm Fieldbus, LAN network (PROFIBUS, Ethernet, Devicenet...). Shielded data cables DC supply cables with (RS232...).

  • Page 11: Earthing Of The System

    Do not connect EARTH and GND terminals together! If you want to use the DGT4X to replace a transmitter without a dedicated earth terminal (e.g. DGT4), you can make the earth connection using only the "GND"...
  • Page 12 GENERAL NOTES: • All earth cables must be of suitable length, so as to obtain an overall resistance of the earthing system of less than 1 Ω. • If the weighing system involves large and/or outdoor structures (weighbridges, silos, etc.): - the earth connection must be made by connecting the earth cables to an earth bar and the earth bar to the earth post with a cable having a cross-section of not less than 50 mm - the thickness of the cables must be greater (50 mm...
  • Page 13 EXAMPLE OF EARTHING OF A WEIGHBRIDGE Weight transmitter Junction box placed on the side wall of the pit Load cell Weighbridge Earth cables Ø 8 - sec. 50 mm Ø 11.3 - sec. 100 mm Drilled copper plate positioned on the side wall Weighbridge Earth post Load cell bypass jumper...
  • Page 14 EXAMPLE OF EARTHING OF A SILO Protective earth by- pass for the load cell Load cell DGT4X_01.19_23.06_EN_U...

  • Page 15: Technical Features

    Technical features POWER SUPPLY 12 - 24 Vdc LPS or with class 2 power supply. MAXIMUM ABSORPTION DGT4X: 4 W (without load cells) DGT4XAN: 4.5 W DGT4XPB: 4.5 W DGT4XETHIP, DGT4XPRONET, DGT4XETHCAT, DGT4XMODTCP: 7.5 W DGT4COPEN, DGT4DEVNET: 4.5 W OPERATING TEMPERATURE From -10°C to +40°C.

  • Page 16: Load Cell Installation

    CELL 3 CELL 2 CELL 1 CELL 4 CELL 4 The DGT4X has a DIP switch (EXC-SEN) located under the cover for Cell 1 and 2 connections. Set the DIP switch to correspond CELL 3 CELL 2 CELL 1 CELL 4 with the type of load cells connected to the transmitter: •...

  • Page 17: Wiring Diagrams

    Wiring diagrams DGT4X 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 LOAD CELL 4 LOAD CELL 3 LOAD CELL 2 LOAD CELL 1 JUMPER J1 RS485 TERM Internal use RS485...

  • Page 18: Dgt4Xan

    DGT4XAN 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 LOAD CELL 4 LOAD CELL 3 LOAD CELL 2 LOAD CELL 1 JUMPER J1 RS485 TERM Internal use ANALOG RS485 RS232 11 12 13 14 15 16 17...

  • Page 19: Dgt4Xpb

    DGT4XPB 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 LOAD CELL 4 LOAD CELL 3 LOAD CELL 2 LOAD CELL 1 JUMPER J1 RS485 TERM PROFIBUS Internal use PORT RS485 16 17 DGT4X_01.19_23.06_EN_U...

  • Page 20: Dgt4Xethip, Dgt4Xethcat, Dgt4Xpronet, Dgt4Xmodtcp

    DGT4XETHIP, DGT4XETHCAT, DGT4XPRONET, DGT4XMODTCP 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 LOAD CELL 4 LOAD CELL 3 LOAD CELL 2 LOAD CELL 1 JUMPER J1 RS485 TERM Internal use RS485 16 17 DGT4X_01.19_23.06_EN_U...

  • Page 21: Dgt4Xcanop

    DGT4XCANOP 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 LOAD CELL 4 LOAD CELL 3 LOAD CELL 2 LOAD CELL 1 JUMPER J1 RS485 TERM Internal use RS485 16 17 DGT4X_01.19_23.06_EN_U...

  • Page 22: Dgt4Xdevnet

    DGT4XDEVNET 35 34 33 32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 LOAD CELL 4 LOAD CELL 3 LOAD CELL 2 LOAD CELL 1 JUMPER J1 RS485 TERM Internal use RS485 16 17 DGT4X_01.19_23.06_EN_U...

  • Page 23: Display And Function Of The Keys

    Display and function of the keys CELL 4 CELL 3 CELL 2 CELL 1 ZERO TARE MODE PRINT INPUT RELA YS ANALOG Symbol Description Symbol Description Semi-automatic zeroing. Gross weight on zero. Decreases the selected digit. Semi-automatic tare. Unstable weight. Increases the selected digit.

  • Page 24: Advanced Programming Menu

    Advanced programming menu The advanced menu contains all the transmitter configuration parameters for the most advanced adjustments. Access to the advanced menu and saving the changes Reboot the transmitter. Press the key when the display shows 888888. HOW TO EXIT THE SETUP AND SAVE CHANGES Press several times, until the display shows “save?”.

  • Page 25: Block Diagram Of The Menu

    Block diagram of the menu Mode of use (page 26). 888888 TYPE Operating mode (page 45). f.mode funct Reactivating printing (page 52). React Date and time (page 66). CloCk Tare (page 40). tare Zero restore (page 40). rs.zero Tare restore (page 41). rs.tare Unbalancing (page 64).
  • Page 26 Full ConfiG setup menu is displayed. ADC converter pre-calibration (page 26). Setup ConfiG pre.Cal Number of channels used. Calibration (page 27 / 28 / 29 / 31). nChan Channel to be configured. Calibration (page 28 / 31). Chan Filter (page 35). param stabil auto-0...

  • Page 27: Mode Of Use Of The Dgt4X

    Mode of use of the DGT4X Smart junction box mode. 888888 TYPE dep.Ch Multi-scale mode. ind.Ch Mode 1 “DEP.CH” Allows you to connect the load cells (from 2 to 4) directly and to equalise them. CELL 4 CELL 3 CELL 2...

  • Page 28: Theoretical Calibration

    Theoretical calibration Dependent channels 888888 TYPE dep.Ch Setup ConfiG pre.Cal nChan Calib deCi u.m. ranGe1 theo.Ca Cel.sen Cel.CAp dead.ld CALIBRATION PROCEDURE: kno.wGt Select mode of use dep.Ch. Set the number of channels used (from 1 to 4). Set the calibration parameters: = Number of decimals.

  • Page 29: Independent Channels

    Independent channels 888888 TYPE ind.Ch Setup ConfiG pre.Cal nChan Chan Calib deCi u.m. ranGe1 theo.Ca Cel.sen Cel.CAp dead.ld kno.wGt CALIBRATION PROCEDURE: Select mode of use ind.Ch. Set the number of connected scales (from 1 to 4). Select the scale to be calibrated (from 1 to 4). Set the calibration parameters: = Number of decimals.

  • Page 30: Calibration With Sample Weights

    Calibration with sample weights Dependent channels (with digital equalisation) 888888 TYPE dep.Ch Setup ConfiG pre.Cal nChan Calib deCi u.m. ranGe1 Calib.p equal n tp Tp 0 ddt1 tp 1 ddt2 Tp 2 ddt3 CALIBRATION PROCEDURE: tp 3 Select mode of use dep.Ch. Set the number of connected scales (from 1 to 4).
  • Page 31 Acquire the calibration points: Display View: Display View: Display View: n tP tp 0 press Press and select the number of calibration Unload the scale. points using the keys To acquire the zero point press (from 1 to 3). To confirm press Display View: Display View: Display View:...

  • Page 32: Independent Channels

    Independent channels 888888 TYPE ind.Ch Setup ConfiG Pre.Cal nChan Chan Calib deCi u.m. ranGe1 Calib.p n tp Tp 0 ddt1 tp 1 ddt2 tp 2 ddt3 tp 3 CALIBRATION PROCEDURE: Select mode of use ind.Ch. Set the number of connected scales (from 1 to 4). Select the scale to be calibrated (from 1 to 4).
  • Page 33 Acquire the calibration points: Display View: Display View: Display View: n tP tp 0 press Press and select the number of calibration Unload the scale. points using the keys To acquire the zero point press (from 1 to 3). To confirm press Display View: Display View: Display View:...

  • Page 34: Equalisation

    Equalisation If the dependent channel mode has been set, you can improve the accuracy of the system by digitally equalising the connected cells. 888888 TYPE dep.Ch Setup ConfiG pre.Cal Calib deCi Visible only if Calib.p equal reset? type = Dep.Ch Display View: Display View: Display View:...

  • Page 35: Manual Calibration

    Manual calibration 888888 TYPE Setup ConfiG pre.Cal Calib deCi man.Cal If you know the number of ADC converter points for a known weight (for example if you want to copy the calibration from one transmitter to another) the calibration points can be entered manually: The display shows mod.pnt, proceed by pressing the key.

  • Page 36: Filter And Stability

    Filter and stability Filter adjustment 888888 TYPE Setup ConfiG pre.Cal Param Stabil Filter Updating frequency (Hz) * Response time (ms) 1 channel 4 channels 1 channel 4 channels 5000 8000 High resolution or Oscillating loads 2500 5000 1000 2000 Simple weighing 1000 Dosing High-speed weight...

  • Page 37: Anti-Peak Filter

    Anti-peak filter The transmitter has an additional filter for the elimination of sudden weight peaks (e.g. shocks or falling material). The following parameters, opportunely configured, allow you to eliminate the peak by blocking the weight for its entire duration. The weight is blocked if it remains within the number of divisions set in PK.LK.DV for the time set in PK.LK.TM and is subsequently unblocked if the weight deviates from the blocking value for a number of divisions greater than PK.DIV (o PK.bn.dv) or if the time set in PK.TIME has elapsed.

  • Page 38: Stability Detection Time

    Stability detection time 888888 F.mode Setup ConfiG pre.Cal param stabil tim.stb If the weight remains within the number of divisions set in DIV.STB for the time set in this parameter, the weight is from 10 to 10000. stable. 500. Enter the value in ms. In case of approved transmitter, the value is fixed at 500 ms. = 500.

  • Page 39: Gravity

    Gravity 888888 TYPE Setup ConfiG pre.Cal From 9.75001 to 9.84999. Grav = 9.80543. This parameter allows you to correct the gravity acceleration value. Before calibration, set the value of the calibration zone. Next, set this value to the value of the zone of use. Any difference between the two values will be automatically compensated.

  • Page 40: Zero Functions And Parameters

    Zero functions and parameters 888888 TYPE Setup ConfiG pre.Cal param stabil % auto-zeroing on start-up. auto.0 % manual zeroing. 0-perC Zero tracking. 0.traCk Zero tracking speed. 0.trk.sp Auto-zeroing on start-up Disabled. auto.0 disab Enabled, enter in C.PERC the % value of the capacity. from 0 to 50%.

  • Page 41: Zero Tracking Speed

    Zero tracking speed from 100 to 5000. It indicates the value of time that elapses from when the instrument detects stability to 0.trk.sp from 1000. when zero tracking takes effect. = 1000. The value is expressed in ms. Restoring zero 888888 Type F.mode...

  • Page 42: Tare Functions And Parameters

    Tare functions and parameters Tare mode 888888 Type F.mode funCt Tare blocked. When the gross weight drops to 0, the tare remains tare loCk engaged. Tare unlocked. When the gross weight drops to 0, the tare is cleared. unloCK Tare disabled. Disab Semi-automatic tare By pressing the...

  • Page 43: Alibi Memory

    Alibi memory The alibi memory allows you to store the weight values transmitted to the computer for further processing and/or data integration. The stored values can then be retrieved from the PC port or directly on the display of the transmitter for later checking. Enabling the alibi memory 888888 Type...

  • Page 44: Reading The Alibi Memory

    Reading the alibi memory FROM THE TRANSMITTER (MANUAL) By pressing the key you can read a saved weight: you will be asked to enter the rewrite number “rew.id” (from 0 to 255) and the ID number “id” (from 0 to 131072). The weighing data are shown.

  • Page 45: Use Functions

    Use functions 888888 Type Not visible if TYPE = IND.CH and NCHAN > 1. F.mode funCt viss peak Conver alibi none High resolution Weight display in high resolution (x10). Press the key to activate or deactivate the function. viss When the weight is displayed in high resolution, the light is lit.

  • Page 46: Input Configuration

    Input configuration The indicator has 2 configurable inputs (bidirectional optocouplers). 888888 TYPE Setup ConfiG Such as inp.02 ( = zero). inputs inp.01 No function. inp.02 NoNE key. zero key. tare key. mode key. print key. Reboots the transmitter. Disable keypad (and re-enable). Dis.key INPUT CONNECTION: The input is activated when there is a potential difference between terminals 4 - 5 (IN1 and...

  • Page 47: Output Configuration

    Output configuration The indicator has 2 programmable outputs (photomosfet). 888888 TYPE Setup ConfiG Such as out.02. output out.01 No function. out.02 funC 0 none Setpoint on gross weight. 1 Gros Setpoint on net weight. 2 net Gross weight on zero. 4 Gro.0 Net weight on zero.

  • Page 48: Analog Output Configuration

    Analog output configuration The DGT4XAN model has an analog output in voltage (0 - 5 / 0 - 10 Vdc) or current (4 - 20 / 0 - 20 mA ). 888888 TYPE Setup ConfiG Analog output for gross weight. an.out mode ao.Gro...
  • Page 49 CALIBRATION PROCEDURE: Press to update the output value on Increase or decrease the D/A points Connect a multimeter to the transmitter. the multimeter. value to reach the desired output. Enter the parameter to be changed: ao 0v ao 10v ao 0ma 100 D/A points ~ 0.015 V - 0.035 mA and set an approximate value.

  • Page 50: Serial Communication Configuration

    Serial communication configuration The transmitter has 3 serial ports (COM1 / 232, COM2 / 485, USB) that can be used indiscriminately to communicate: • In bidirectional mode with the PC / PLC (“PC” port); • In one-directional mode with the PC, thermal printer, repeater (“PRN” port); The USB port always allows quick connection to the PC to change / save / restore the transmitter settings at any time.

  • Page 51: Configuration Of The Printer Port (Com.prn)

    Transmission not enabled. pr.mode pr-no Transmission of the weight value when the key is pressed. prpC.hk Transmission of the weight to DINI ARGEO 6-digit repeater. repe.6 Extended string transmission when the key is pressed. prPC.ex Standard string transmission when the key is pressed.

  • Page 52: Baud Rate, Parity, Data Bits, Stop Bits

    Baud rate, parity, data bits, stop bits 9600 baud.pr 4800 2400 1200 115200 57600 38400 19200 No parity, 8 data bits, 1 stop bit. none prty.pr Even. even Odd. 8 bits. bit.pr 7 bits. 1 stop bit. stop.pr 2 stop bits. Printer power on mode It is possible to set the way the printer is turned on: Printer always on.

  • Page 53: Reactivation Of Printing

    Reactivation of printing 888888 Type F.mode funCt Reactivation of printing after the weight has changed from zero. react zero Printing always active. always Reactivation of printing after the weight has changed from instability. inst LEGEND: Indicates repeated pressing of Parameter visible only Parameter or menu subject Default value of the parameter.

  • Page 54: Configuration Of The Pc Port (Com.pc)

    Data bits. Stop bits. stop Transmission mode Transmission on demand. onde pCmode Transmission of the weight on DINI ARGEO 6-digit repeater. repe.6 Standard string transmission when the key is pressed. Prin.st Extended string transmission when the key is pressed. prin.ex Transmission with 485 protocol (enter the 485 address of the transmitter).

  • Page 55: Baud Rate, Parity, Data Bits, Stop Bits

    Baud rate, parity, data bits, stop bits baud 9600 4800 2400 1200 115200 57600 38400 19200 No parity, 8 data bits, 1 stop bit. none parity Even. even Odd. 8 bits. 7 bits. 1 stop bit. stop 2 stop bits. USB port Configuration of the USB port 888888...

  • Page 56: Communication Protocols

    Communication protocols Standard string [01]ST,GS, 0.0,kg<CR LF> Where: Transmitter code 485 (2 characters), only if communication mode 485 is enabled Scale status (2 characters): US - Unstable weight ST - Stable weight OL - Weight overload (out of range) UL - Weight underload (out of range) Character ASCII 044 Type of weight data (2 characters) GS - Gross...

  • Page 57: Multi-Scale String

    Multi-scale string If type = ind.Ch and nChan ≥ 2 [01]ST, 612,kg,ST, 61.4, t,ST, 6.17, g,ST, 0.617,lb<CR LF> Where: Transmitter code 485 (2 characters), only if communication mode 485 is enabled Scale 1 status (2 characters): US - Unstable weight ST - Stable weight VL - Microvolts RZ - Converter points...

  • Page 58: Serial Commands

    Serial commands By selecting the PC port on demand mode (onde), you can communicate with the transmitter via serial commands. For each command received, the transmitter emits a string containing the response (refer to the command description) or one of the following signals: OK<CR LF>...
  • Page 59 PRESSING A KEY Format <CR LF> Key code. To simulate pressing a key, you must send the KEYP and KEYR commands in succession. If more than 1.5 s pass after the KEYP command is sent, Where the transmitter will execute the function associated with prolonged pressing of the key.
  • Page 60 READING OF MICROVOLTS READING OF CONVERTER POINTS Format Format Response Response Standard string<CR LF>. Standard string<CR LF>. INITIALISING ALIBI MEMORY WEIGHT READING WITH DATE AND TIME Format Format Response ALDLOK / ALDLNO <CR LF> Response Extended string<CR LF>. READING A WEIGHING OPERATION IN THE ALIBI MEMORY Format <CR LF>...

  • Page 61: Modbus Protocol

    Modbus Protocol MODBUS REGISTERS FOR DATA READING (SINGLE SCALE) Data Register DESCRIPTION 30001 Gross Weight Gross weight value. 30002 30003 Net Weight Net weight value. 30004 Bit 15 Active channel. (msb) Bit 14 Active channel. Bit 13 No function. Bit 12 No function.
  • Page 62 MODBUS REGISTERS FOR DATA READING (MULTI-SCALE) Data Register DESCRIPTION Bit 15 Not used. (msb) Bit 14 Not used. Bit 13 Not used. Bit 12 Scale active (0 = “no”; 1 = “yes”). Bit 11 Decimals (00 = 0; 01 = 1; 10 = 2; 11 = 3) Bit 10 Bit 9 Unit of Measure (00 = "g";...
  • Page 63 MODBUS REGISTERS FOR SENDING COMMANDS Data Register DESCRIPTION Main commands available: Value Command 00 Hex No command 01 Hex Zero 02 Hex Tare Command 40001 03 Hex Predetermined tare 0A Hex Setting setpoint 1 0B Hex Setting setpoint 2 19 Hex Setting digital outputs 22 Hex Rebooting the transmitter...

  • Page 64: Diagnostics

    Diagnostics 888888 TYPE diaG Display of firmware release (e.g. 01.06.00). prG.ver Display of firmware libraries (for use by the manufacturer). manuf.d Display of calibration internal divisions. div.int Display of the µV related to the weight on the scale. adC.uv Use the keys to display the different channels (in dep.Ch mode the sum is also visible).

  • Page 65: Unbalancing

    Checking the status of the inputs: inputs value 0 indicates that the input is disabled, value 1 indicates that the input is enabled. Use the keys to display the two inputs. Analog output test. an.out Use the keys to enter the D/A point value of the analog output. Press the key to confirm and update the V / mA value of the analog output.

  • Page 66: Programming The Setpoints

    Example: Condition stored The unbalance condition is signalled via Modbus / Fieldbus or a digital output (func = 31.unb). This function is only available if EXCL.CH = NoNE. Use this function only in systems where the load is evenly distributed. Programming the Setpoints In weighing mode, if the output functions (1 Gross / 2 net) have been set correctly, pressing will enter the setpoint...

  • Page 67: Restoring Factory Settings

    Restoring factory settings 888888 TYPE Setup ConfiG defau The transmitter is initialized and the default parameters (indicated by the symbol) are activated. Pressing the display shows “dflt?” confirm further with or exit by pressing another key. The actual activation of the default parameters is performed by saving the settings (save?) while exiting the menu. Date and time setting 888888 TYPE...

  • Page 68: Alarms

    Alarms Alarm Description Displayed if you try to calibrate a point without first confirming the number of calibration points (n tp). preC Calibration error: unstable weight during point acquisition. er.mot Calibration error: during the acquisition of a calibration point a NULL value was read from the converter. erpnt Error that occurs if the capacity of channel X is not set, or there is an error in the calibration parameters of err.x.1...
  • Page 69 Notes This publication, part reproduced without written permission from Manufacturer. information this manual based data available time publication; Manufacturer reserves right make changes products time, without notice without incurring penalty. therefore recommend that always check updates. person responsible scale must ensure that safety...
  • Page 70 Notes DGT4X_01.19_23.06_EN_U...
