  • Page 1 DGT1SP Digital weight transmitter USER MANUAL ENGLISH www.diniargeo.com...

  • Page 3: Table Of Contents

    Wiring diagrams   16   16 DGT1SP   17 DGT1SP-AN   18 DGT1SP-PB   19 DGT1SP-ETHIP, DGT1SP-ETHCAT, DGT1SP-PRONET, DGT1SP-MODTCP   20 DGT1SP-CANOP   21 DGT1SP-DEVNET Display and function of the keys   22 Quick menu   22 Advanced programming menu  ...
  • Page 4 Filter and stability   30   30 Filter adjustment   31 Anti-peak filter   31 Stability detection sensitivity Gravity   32 Reset functions and parameters   33   33 Auto-zeroing on start-up   33 Maximum percentage of manual zeroing   33 Zero tracking  ...
  • Page 5 Display   51 Keypad   52 Serial ports   52 Inputs   52 Outputs   52 Analog output (mod. DGT1SP-AN) Programming the Setpoints   52 Restoring factory settings   53 Date and time setting   53 Alarms   54 USER_MAN_ENG_DGT1SP...
  • Page 6 USER_MAN_ENG_DGT1SP...

  • Page 7: Introduction

    Thank you for purchasing a DINI ARGEO product. This manual contains all the instructions for a correct installation and commissioning of the high speed DGT1SP digital weight transmitter. While thanking you for purchasing this product, we would like to draw your attention to some aspects of this manual.

  • Page 8: Transmitter Installation

    Transmitter installation Installation requirements Observe the following conditions for correct installation of the transmitter and of the load receiver: • Flat, level support surface. • Stability and absence of vibrations. • Absence of aggressive dusts and vapours. • Absence of draughts. •...

  • Page 9: Electrical Precautions

    Electrical precautions • Use a regulated mains supply within ± 10% of the rated voltage. • The electrical protections (fuses, etc.) are the responsibility of the installer. • Observe the recommended minimum distances between cables of different categories (see table on page 10). •...
  • Page 10 RECOMMENDED DISTANCES AND CABLE CLASSIFICATION Category I Category II Category III Category IV ≥ 100 mm ≥ 200 mm ≥ 500 mm Distance ≥ 100 mm ≥ 500 mm ≥ 500 mm Fieldbus, LAN network (PROFIBUS, Ethernet, Devicenet...). Shielded data cables DC supply cables with (RS232...).

  • Page 11: Earthing Of The System

    Earthing of the system For correct earthing and optimal system operation, the transmitter, load cells, junction box, if any, and weighing structure must be earthed. TRANSMITTER The earth connection must be made via the appropriate terminal. The cable cross-section must be less than 2.5 mm LOAD CELLS AND JUNCTION BOX The connection must be made by connecting the earth cables to the earth bar (cables that must have a cross-section of at least 16 mm finally, connect the earth bar to the earth post with a cable having a cross-section of at least 50 mm...
  • Page 12 EXAMPLE OF EARTHING OF A WEIGHBRIDGE Weight transmitter Junction box placed on the side wall of the pit Load cell Weighbridge Earth cables Ø 8 - sec. 50 mm Ø 11.3 - sec. 100 mm Drilled copper plate positioned on the side wall Weighbridge Earth post Load cell bypass jumper...
  • Page 13 EXAMPLE OF EARTHING OF A SILO Protective earth by- pass for the load cell Load cell USER_MAN_ENG_DGT1SP...

  • Page 14: Technical Features

    Made of plastic (ABS), suitable for DIN rail mounting (EN 60715 - DIN43880) or wall mounting. SERIAL OUTPUTS 1 half duplex RS485 bidirectional port on terminal (versions DGT1SP, DGT1SP-AN). 1 PROFIBUS port on DB9 connector (DGT1SP-PB* version); 2 ETHERNET ports (versions DGT1SP-ETHIP*, DGT1SP-MODTCP*, DGT1SP-ETHCAT*, DGT1SP-PRONET*);...

  • Page 15: Load Cell Installation

    Load cell installation After carrying out the instructions for the platform or load receiver, the shielded cable from the cell must be properly connected to the terminal block of the transmitter (see section “Wiring diagrams”). The transmitter has one channel for 6-wire connection to load cells (using the REFERENCE). The REFERENCE allows you to compensate for any voltage drop on the section of cable connecting the transmitter to the load receiver.

  • Page 16: Wiring Diagrams

    Wiring diagrams DGT1SP 12 13 14 15 16 17 LOAD CELL Internal use RS485 10 11 USER_MAN_ENG_DGT1SP...

  • Page 17: Dgt1Sp-An

    DGT1SP-AN 12 13 14 15 16 17 18 19 20 21 LOAD CELL ANALOG Internal use OUTPUT RS485 10 11 USER_MAN_ENG_DGT1SP...

  • Page 18: Dgt1Sp-Pb

    DGT1SP-PB 12 13 14 15 16 17 LOAD CELL Internal use PROFIBUS PORT USER_MAN_ENG_DGT1SP...

  • Page 19: Dgt1Sp-Ethip, Dgt1Sp-Ethcat, Dgt1Sp-Pronet, Dgt1Sp-Modtcp

    DGT1SP-ETHIP, DGT1SP-ETHCAT, DGT1SP-PRONET, DGT1SP-MODTCP 12 13 14 15 16 17 LOAD CELL Internal use USER_MAN_ENG_DGT1SP...

  • Page 20: Dgt1Sp-Canop

    DGT1SP-CANOP 12 13 14 15 16 17 LOAD CELL Internal use USER_MAN_ENG_DGT1SP...

  • Page 21: Dgt1Sp-Devnet

    DGT1SP-DEVNET 12 13 14 15 16 17 LOAD CELL Internal use USER_MAN_ENG_DGT1SP...

  • Page 22: Display And Function Of The Keys

    Display and function of the keys  1 2 3 4 5 6 Number Description Symbol Description Semi-automatic zeroing. Gross weight on zero. Decreases the selected digit. Semi-automatic tare. Unstable weight. Increases the selected digit. A tare is active. Activates the function. Selects the digit to be changed.

  • Page 23: Advanced Programming Menu

    Advanced programming menu The advanced menu contains all the transmitter configuration parameters for the most advanced adjustments. Access to the advanced menu and saving the changes Reboot the transmitter. Press the key when the display shows 888888. HOW TO EXIT THE SETUP AND SAVE CHANGES Press several times, until the display shows “save?”.

  • Page 24: Block Diagram Of The Menu

    Block diagram of the menu 888888 f.mode funct Operating mode (page 39). React Reactivating functions. Date and time (page 54). CloCk Tare (page 36). tare rs.zero Zero restore (page 35). Tare restore (page 36). rs.tare setup ConfiG pre.Cal Calibration, filtering and metrological parameters Continued on page 25.
  • Page 25 Full ConfiG setup menu is displayed. ADC converter precalibration (page 30). Setup ConfiG pre.Cal param stabil Filter (page 30). auto-0 0-perC Zero parameters (page 34-35). 0.traCk 0.trk.sp div.stb tim.stb Stability divisions (page 31-32). stb.flt peak.fl Anti-peak filter (page 31). Grav x.xxxxx Gravity of calibration zone / zone of use (page 33).

  • Page 26: Theoretical Calibration

    Theoretical calibration 888888 f.mode Setup ConfiG pre.Cal Calib deCi u.m. ranGe1 theo.Ca Cel.sen Cel.CAp dead.ld kno.wGt CALIBRATION PROCEDURE: Set the calibration parameters: = Number of decimals. deCi = Unit of measurement (kG, G, t, lb). u.m. = Minimum division. ranGe1 = Maximum range. Set the cell data: sen.Cel = Cell sensitivity (given by the average mV/V value of cells).

  • Page 27: Calibration With Sample Weights

    Calibration with sample weights 888888 f.mode Setup ConfiG pre.Cal Calib deCi u.m. ranGe1 Calib.p equal n tp Tp 0 ddt1 tp 1 ddt2 Tp 2 ddt3 tp 3 CALIBRATION PROCEDURE: Set the calibration parameters: = Number of decimals. deCi = Unit of measurement (kG, G, t, lb). u.m.
  • Page 28 Acquire the calibration points: Display View: Display View: Display View: n tP tp 0 press Press and select the number of calibration Unload the scale. points using the keys To acquire the zero point press (from 1 to 3). To confirm press Display View: Display View: Display View:...

  • Page 29: Manual Calibration

    Manual calibration 888888 f.mode Setup ConfiG pre.Cal Calib deCi man.Cal If you know the number of ADC converter points for a known weight (for example if you want to copy the calibration from one transmitter to another) the calibration points can be entered manually: The display shows mod.pnt, and then the last calibration point.

  • Page 30: Adc Converter Precalibration

    ADC converter precalibration 888888 f.mode For manufacturer use only Setup ConfiG pre.CAl Param Filter and stability Filter adjustment 888888 f.mode Setup ConfiG pre.CAl Param Param Stabil Stabil Filter Updating frequency (Hz) Response time (ms) 5000 High resolution or Oscillating loads 2500 1000 Simple weighing...

  • Page 31: Anti-Peak Filter

    Anti-peak filter The transmitter has an additional filter for the elimination of sudden weight peaks (e.g. shocks or falling material). The following parameters, opportunely configured, allow you to eliminate the peak by blocking the weight for its entire duration. The weight is blocked if it remains within the number of divisions set in PK.LK.DV for the time set in PK.LK.TM and is subsequently unblocked if the weight deviates from the blocking value for a number of divisions greater than PK.DIV (or PK.BN.DV) or if the time set in PK.TIME has elapsed.
  • Page 32 Stability detection time 888888 f.mode Setup ConfiG pre.Cal Param stabil tim.stb If the weight remains within the number of divisions set in DIV.STB for the time set in this parameter, the weight is from 10 to 10000. stable. 500. Enter the value in ms. In case of approved transmitter, the value is fixed at 500 ms. = 500.

  • Page 33: Gravity

    Gravity 888888 f.mode Setup ConfiG pre.Cal From 9.75001 to 9.84999. Grav = 9.80390. This parameter allows you to correct the gravity acceleration value. Before calibration, set the value of the calibration zone. Next, set this value to the value of the zone of use. Any difference between the two values will be automatically compensated.

  • Page 34: Reset Functions And Parameters

    Reset functions and parameters 888888 f.mode Setup ConfiG Pre.Cal param stabil % auto-zeroing on start-up. auto.0 % manual zeroing. 0-perC 0.traCk Zero tracking. 0.trk.sp Zero tracking time. Auto-zeroing on start-up Disabled. auto.0 disab from 0 to 50%. Enabled, enter in C.PERC the % value of the capacity. enab C.perC from 0 to 10%.

  • Page 35: Zero Tracking

    Zero tracking This menu allows to set zero tracking, i.e. the compensation parameter of the thermal drift of the scale; the set value corresponds to the number of divisions that is reset to zero in the fixed time of 1 second. tr 10 10 divisions.

  • Page 36: Tare Functions And Parameters

    Tare functions and parameters Tare mode 888888 F.mode funCt Tare blocked. When the gross weight drops to 0, the tare remains tare loCk engaged. unloCK Tare unlocked. When the gross weight drops to 0, the tare is cleared. Disab Tare disabled. Semi-automatic tare By pressing the key, or sending the tare command, the transmitter sets as tare the weight on the scale.

  • Page 37: Alibi Memory

    Alibi memory The alibi memory allows you to store the weight values transmitted to the computer for further processing and/or data integration. The stored values can then be retrieved from the PC port or directly on the display of the transmitter for later checking. Enabling the alibi memory 888888 F.mode...

  • Page 38: Reading The Alibi Memory

    Reading the alibi memory FROM THE TRANSMITTER (MANUAL) By pressing the key you can read a saved weight: you will be asked to enter the rewrite number “rew.id” (from 0 to 255) and the ID number “id” (from 0 to 131072). The weighing data are shown.

  • Page 39: Use Functions

    Use functions 888888 F.mode funCt viss peak Conver alibi No function none High resolution Weight display in high resolution (x10). Press the key to activate or deactivate the function. viss When the weight is displayed in high resolution, the light is lit. In the case of an approved transmitter, the high-resolution weight display is automatically deactivated after 5 seconds.

  • Page 40: Input Configuration

    Input configuration The indicator has 2 configurable inputs (bidirectional optocouplers). 888888 f.mode Setup ConfiG inputs inp.01 Such as inp.02 ( = zero). inp.02 NoNE No function. key. zero tare key. key. mode key. print key. Reboots the transmitter. Disable keypad (and re-enable). Dis.key INPUT CONNECTION: The input is activated when there is a potential difference between terminals 4 - 5 (IN1 and...

  • Page 41: Output Configuration

    Output configuration The indicator has 2 programmable outputs (photomosfet). 888888 f.mode Setup ConfiG output out.01 Such as out.04. out.04 funC No function. 0 none 1 Gros Setpoint on gross weight. Setpoint on net weight. 2 net 4 Gro.0 Gross weight on zero. 5 net.0 Net weight on zero.

  • Page 42: Analog Output Configuration

    Analog output configuration The DGT1SP-AN model has an analog output in voltage (0 - 5 / 0 - 10 Vdc) or current (4 - 20 / 0 - 20 mA ). 888888 f.mode Setup ConfiG an.out mode ao.Gro Analog output for gross weight.
  • Page 43 CALIBRATION PROCEDURE: Press to update the output value on Increase or decrease the D/A points Connect a multimeter to the transmitter. the multimeter. value to reach the desired output. Enter the parameter to be changed: ao 0v ao 10v ao 0ma 100 D/A points ~ 0.015 V - 0.035 mA and set an approximate value.

  • Page 44: Serial Communication Configuration

    Serial communication configuration All models are equipped with a micro-USB port that is always accessible for transmitter configuration and diagnostics. The DGT1SP and DGT1SP-AN models also have an RS485 port. 888888 f.mode Visible only in DGT1SP and DGT1SP-AN models. Setup...

  • Page 45: Configuration Of The 485 Port (Pc Port)

    Configuration of the 485 port (PC port) Transmission mode Transmission on demand. onde pCmode Transmission of the weight on DINI ARGEO 6-digit repeater. repe.6 Standard string transmission when the key is pressed. Prin.st Extended string transmission when the key is pressed.

  • Page 46: Communication Protocols

    Communication protocols Standard string [01]ST,GS, 0.0,kg<CR><LF> Where: Transmitter code 485 (2 characters), only if communication mode 485 is enabled Scale status (2 characters): US - Unstable weight ST - Stable weight OL - Weight overload (out of range) UL - Weight underload (out of range) Character ASCII 044 Type of weight data (2 characters) GS - Gross...

  • Page 47: Serial Commands

    Serial commands By selecting the PC port on demand mode (onde), you can communicate with the transmitter via serial commands. For each command received, the transmitter emits a string containing the response (refer to the command description) or one of the following signals: Command sent when sending a correct command.
  • Page 48 PRESSING A KEY Format <CR LF> Key code. To simulate pressing a key, you must send the KEYP and KEYR commands in succession. If more than 1.5 s pass after the KEYP command is sent, Where the transmitter will execute the function associated with prolonged pressing of the key.
  • Page 49 READING OF MICROVOLTS READING OF CONVERTER POINTS Format Format Response Response Standard string<CR LF>. Standard string<CR LF>. INITIALISING ALIBI MEMORY WEIGHT READING WITH DATE AND TIME Format Format Response ALDLOK / ALDLNO <CR LF> Response Extended string<CR LF>. READING A WEIGHING OPERATION IN THE ALIBI MEMORY Format <CR LF>...

  • Page 50: Modbus Protocol

    Modbus Protocol MODBUS REGISTERS FOR DATA READING (SINGLE SCALE) Data Register DESCRIPTION 30001 Gross Weight Gross weight value. 30002 30003 Net Weight Net weight value. 30004 Bit 15 Active channel. (msb) Bit 14 Active channel. Bit 13 No function. Bit 12 No function.
  • Page 51 MODBUS REGISTERS FOR SENDING COMMANDS Data Register DESCRIPTION Main commands available: Value Command 00 Hex No command 01 Hex Zero 02 Hex Tare Command 40001 03 Hex Predetermined tare 0A Hex Setting setpoint 1 0B Hex Setting setpoint 2 19 Hex Setting digital outputs 22 Hex Rebooting the transmitter...

  • Page 52: Diagnostics

    Diagnostics 888888 TYPE diaG Cells / converter test adC.uv Display of the µV related to the weight on the scale. For correct operation, the value of the µV of each channel must be less than 30000 with a weight equal to the maximum capacity. This value must be stable, and increase if a load is applied to the cell.

  • Page 53: Serial Ports

    Activation of the output shown on the display (rel.1 / rel.2). output Use the keys to activate the two outputs. Analog output (mod. DGT1SP-AN) an.out Analog output test. Use the keys to enter the D/A point value of the analog output.

  • Page 54: Restoring Factory Settings

    Restoring factory settings 888888 f.mode Setup ConfiG defau The transmitter is initialized and the default parameters (indicated by the symbol) are activated. Pressing the display shows “dflt?” confirm further with or exit by pressing another key. The actual activation of the default parameters is performed by saving the settings (save?) while exiting the menu. Date and time setting 888888 F.mode...

  • Page 55: Alarms

    Alarms Alarm Description Displayed if you try to calibrate a point without first confirming the number of calibration points (n tp). preC Calibration error: unstable weight during point acquisition. er.mot Calibration error: during the acquisition of a calibration point a NULL value was read from the converter. erpnt Error that occurs if the capacity of channel X is not set, or there is an error in the calibration parameters of err.x.1...
