Wireless Request-to-Exit

Plate

SD-8202GT-PEQ

Installation Manual

The ENFORCER Wireless RF Request-to-Exit Button is an excellent solution for difficult access

control installations. The RTE plate combines the very best of SECO-LARM, flexible wireless

solutions and reliable access control. The RTE plate is a great option for cement or brick walls, or

any other location where it is difficult to run wires.

• Built-in 315MHz RF transmitter powered by a common 9VDC battery (included)

• Over 68 billion (6.8x10

• Range up to 250 feet (76m)*

• Faceplate LED indicates transmission and low battery

• Stainless steel single-gang faceplate with illuminated green 2" square button

• May be either surface- or flush-mounted using a non-metal backbox

• Interchangeable "Push to Exit" button plates included – English, Spanish, French, and a blank

that you can customize with your own message

• Requires any ENFORCER 315MHz RF receiver

Transmission range may vary depending on installation and operating environment.

) possible codes

Need help?

Do you have a question about the ENFORCER SD-8202GT-PEQ and is the answer not in the manual?

Page 1 The ENFORCER Wireless RF Request-to-Exit Button is an excellent solution for difficult access control installations. The RTE plate combines the very best of SECO-LARM, flexible wireless solutions and reliable access control. The RTE plate is a great option for cement or brick walls, or any other location where it is difficult to run wires.
Page 2 Dimensions Weight 8.1-oz (230g) Range may vary depending on installation and operating environment Overview Wireless transmitter LED Indicator Battery clip PUSH " (114mm) 9V Battery EXIT RTE Button Switch Red=Low Battery " " 2" (70mm) (20mm) (50mm) SECO-LARM U.S.A., Inc.
Page 3 4. Ensure the message plate orientation is Transparent correct. lens 5. Snap the lens assumbly back on and replace the switch assembly. Sample Application 315MHz Wireless Receiver 12VDC ENFORCER Handheld RF Transmitter SD-8202GT-PEQ (Optional) Wireless RTE Wired RTE Plate (Optional) Electromagnetic Lock SECO-LARM U.S.A., Inc.
Page 4 SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepa id, to SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
