NS-104UT-MAQ, NS-508UT-GAQ
Model
Ethernet
NS-104UT-MAQ 10/100Base-TX
NS-508UT-GAQ 10/100/1000Base-TX 8 Downlink, 2 uplink 20Gbps
Features:
• Provides both Ethernet data and power to
multiple PoE devices including IP cameras,
IP access, IP speakers/intercoms, VOIP, etc.
• Specially designed for video transmission
with fast packet forwarding capability for
clear images and smooth transmission
• Easy plug-and-play installation
Unmanaged PoE Switches
NS-508UT-GAQ shown
Ports
4 Downlink, 2 uplink 1.2Gbps
®
Manual
• Supports 10,100BaseT (NS-508UT-GAQ
supports up to 1000BaseT Gigabit)
• Conforms to IEEE 802.3, IEEE 802.3u,
IEEE 802.3af, IEEE 802.3at
(NS-508UT-GAQ also conforms to
IEEE 802.3ab)
• IEEE 802.3x Flow control
Bandwidth VLAN Power
Yes
No
60W Adapter
120W Built-in
Advertisement
Table of Contents
Related Manuals for SECO-LARM SLI ENFORCER NS-104UT-MAQ
Summary of Contents for SECO-LARM SLI ENFORCER NS-104UT-MAQ
- Page 1 NS-104UT-MAQ, NS-508UT-GAQ Unmanaged PoE Switches Manual NS-508UT-GAQ shown Model Ethernet Ports Bandwidth VLAN Power NS-104UT-MAQ 10/100Base-TX 4 Downlink, 2 uplink 1.2Gbps 60W Adapter NS-508UT-GAQ 10/100/1000Base-TX 8 Downlink, 2 uplink 20Gbps 120W Built-in Features: • Provides both Ethernet data and power to •...
- Page 2 656ft (200m) at 10Mbps with VLAN switch ON NS-104UT-MAQ Overview: 4" (102mm) Downlink ports Uplink ports " Link/Active (75mm) 4-Port PoE Switch LED* VLAN Switch Power input Power Power LED PoE IN " *Flashing green when data is being transmitted (22mm) SECO-LARM U.S.A., Inc.
- Page 3 7. Turn on the display device and ensure that the system is functioning properly. Sample CCTV Application: HD Monitor PoE Switch (NS-104UT-MAQ shown) 4-Port PoE Switch Power Power adapter PoE Cameras or other PoE devices SECO-LARM U.S.A., Inc.
- Page 4 WARRANTY: This SECO-LARM product is warranted against defects in material and workmanship while used in normal service for one (1) year from the date of sale to the original customer. SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if...
